To avoid this problem a gap of 0.5mm or more should
be left between the display bezel edges at installation.
Do not take hold of the display in such a way that
your fingers or hands put pressure on the liquid
crystal panel.
Do not put force on the liquid crystal panel, or press
•
or push it, or allow it to make contact with a hard or
sharp object. Applying force to the liquid crystal panel
can distort the screen, make it uneven, and cause
malfunction .
Changes of temperature or humidity may cause the
brightness of the display to be uneven. This is not a
malfunction.
The unevenness will disappear after the display has
•
been running for some time. If the problem persists,
consult the distributor.
Red, blue or green dots on the screen are a liquid
crystal panel-specific phenomenon. This is not a
malfunction.
Although the liquid crystal display is manufactured
•
with high-precision technology, always-lighting dots or
non-lighting dots may appear on the screen. This is
not a malfunction.
Dot omission ratio * : 0.00013% or less
*: Calculated in sub-pixel units according to the
ISO09241-307 standard.
For the detailed installation method, refer to the
following websites.
https://bizpartner.panasonic.net/public/ppr/file_
view/187616
Product Access and Security
When using this product, take safety measures
against the following.
Personal information being leaked via this product.
•
Unauthorized operation of this product by a malicious
•
third party.
Interference or blocking of this product by a malicious
•
third party.
Take sufficient measures to ensure security.
Set a password for the PJLink protocol and restrict
•
access to a few authorized users.
Make your password as difficult to guess as possible.
•
Change your password often.
•
No Panasonic Corporation personnel, or those of
•
an affiliate company, will ever ask for your password
directly. Never divulge your password should you
ever receive such request.
The connecting network must be secured by a
•
firewall, and precautions against malware and viruses
should be taken.
Before disposing of this product, destroy all data
•
[General settings]-[Factory settings].
Notes on Using a Wired LAN
Take the necessary antistatic measures before
setting up the Display in a location prone to
electrostatic interference.
If the Display is used in a place where electrostatic
•
discharge is frequent, such as in a carpeted venue,
disconnection of a wired LAN can become a
nuisance. In such a case, remove the source of the
problem, relocate the LAN cable, and install an anti-
static mat.
In rare cases, a LAN connection can be disabled by
•
static electricity or noise. Turning the power to the
Display and all the connected devices, off and on
again, will most times restore the LAN connection.
The Display may not work properly in the presence
of strong radio waves from a broadcast station or
even a radio.
If there should be a facility or equipment, which
•
outputs strong radio waves near the installation,
move the Display to a place far enough away to avoid
the problem. Or the LAN cable can be shielded by a
wrapping of metal foil that is continuous with the LAN
terminal ground, or by being placed inside a metal
conduit which is properly grounded at both ends.
Cleaning and maintenance
The front of the liquid crystal panel has been
specially treated. Wipe the surface of the liquid
crystal panel gently using only an LCD cleaning
cloth, or other soft lint-free cloth.
If the surface is particularly dirty, wipe with a soft,
•
lint-free cloth which has been slightly damped with
pure water, or water to which one drop of a neutral
detergent has been added. After this wipe with a lint-
free cloth until the surface is dry.
Do not scratch the surface of the panel with a
•
fingernail or other hard object to remove dirt, this may
damage the surface. Furthermore, avoid spraying
insect repellant near the display and also avoid
using any kind of solvent such as thinners near the
screen. These fluids can have an adverse effect on
the surface.
If the housing becomes dirty, wipe it with a soft, dry
cloth.
If the housing should become particularly dirty, wipe
•
it with a cloth slightly damped with water to which a
drop of neutral detergent has been added. Use this
cloth to wipe the cabinet and then wipe it dry with
another cloth.
Do not allow any detergent to come into direct contact
•
with the surface of the Display. Make sure the cloth
is only damp. If water droplets get inside the unit,
operating problems may be the result.
Volatile substances such as insect sprays, solvents
•
and thinners, can harm not only the screen but also
the Display housing. The coating may be adversely
affected and may even peel off. Do not allow articles
made of rubber or PVC to remain in contact with the
Display housing for any length of time.
Using a chemical cloth
Do not use a chemical cloth on the panel surface.
•
Follow the instructions for using the chemical cloth on
•
the Display housing.
Disposal
When you wish to dispose of this product, ask your
local authority or dealer about how this should be
done.
9
English
