USER MANUAL
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes to
read carefully through this brief but
comprehensive manual before installing and
switching on the monitor. Please keep this
manual in a safe place for your future
reference.
PLE2208HDS-e-M043C01.P65
1
ENGLISH
DEUTSCH
FRANCAIS
NEDERLANDS
ITALIANO
POLSKI
2008/11/28, 13:24
Advertisement
Table of Contents
Related Manuals for Iiyama ProLite E2208HDSV
Summary of Contents for Iiyama ProLite E2208HDSV
- Page 1 USER MANUAL ENGLISH DEUTSCH FRANCAIS NEDERLANDS Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to ITALIANO read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this...
- Page 2 PLE2208HDS-e-M043C01.P65 2008/11/28, 13:24...
- Page 3 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.
- Page 4 We reserve the right to change specifications without notice. All trademarks used in this user manual are the property of their respective owners. As an E ® Partner, iiyama has determined that this product meets the E ® guidelines for NERGY NERGY energy efficiency.
-
Page 5: Table Of Contents
COMPLIANT TIMING ..................23 We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of different countries from there. -
Page 6: For Your Safety
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock. - Page 7 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
-
Page 8: Special Notes On Lcd Monitors
Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, flickering or not lighting up. Never attempt to replace it by yourself. -
Page 9: Before You Operate The Monitor
CHEKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office. -
Page 10: Fitting And Removal Of Base
FITTING AND REMOVAL OF BASE The monitor is supplied complete with a stand. If you prefer to wall mount the monitor, please follow the instructions below to remove the stand. Be sure to include the stand with the monitor if it is necessary to return the unit. -
Page 11: Controls And Connectors
CONTROLS AND CONNECTORS FRONT PANEL CONTROL <Front> <Back> A Power Indicator Blue: Normal operation NOTE Orange: Power Management The monitor enters into power management mode which reduces the power consumption to less than 2W when receiving no horizontal and/or vertical sync signal. -
Page 12: Connecting Your Monitor
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama office for a suitable adaptor. -
Page 13: Computer Setting
Change to the desired signal timing listed on page 23: COMPLIANT TIMING. Windows 95/98/2000/Me/XP/Vista Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP/Vista by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. -
Page 14: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 23. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 15 for SCREEN ADJUSTMENTS. -
Page 15: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Auto Adjust Only Analog Input Adjustment Item Problem / Option Button to Press Auto Adjust * Adjust H. / V. Position, Pixel Clock and Phase automatically. Direct * For best results, use the Auto Adjust in conjunction with the adjustment pattern. See page 15 for SCREEN ADJUSTMENTS. - Page 16 Geometry Only Analog Input Adjustment Item Problem / Option Button to Press Too left H. Position Too right Too low V. Position Too high Too narrow Pixel Clock Too wide To correct flickering text or lines Phase Color Adjustment Item Problem / Option Button to Press 9300K...
- Page 17 Language Adjustment Item Problem / Option Button to Press Español Spanish English English Français French Nederlands Dutch Japanese Language Deutsch German Italiano Italian Simplified Chinese Polski Polish Russian Recall Adjustment Item Problem / Option Button to Press Factory-preset data is restored. Recall All Return to Menu.
- Page 18 Miscellaneous Adjustment Item Problem / Option Button to Press 1 2 3 4 5 Sharpness You can change the picture quality from 1 to 5 (sharp to soft). Press the Button to change the picture quality in numerical order. Press the Button to change the picture quality in reverse numerical order.
- Page 19 Input Select* Adjustment Item Problem / Option Button to Press D-sub Select the Analog input. Input Select Select the Digital input. When only one of the two signal inputs is connected to the signal source, the one NOTE connected is automatically selected. Input Select function is not available if there is no signal input from the selected connector or during the power management mode.
-
Page 20: Screen Adjustments
If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http:// www.iiyama.com). - Page 21 C C C C C Press the Auto Button. (Auto Adjust) D D D D D Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust.
- Page 22 G G G G G Adjust the Phase to correct horizontal wavy noise, flicker or blur in the zebra pattern. NOTE NOTE In case the strong flicker or blurs remain on a part of the screen, repeat steps F and G because the Pixel Clock may not be adjusted correctly.
-
Page 23: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of E NERGY and VESA DPMS. When activated, it automatically reduces unnecessary power consumption ® of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. -
Page 24: Trouble Shooting
2. Consult the following items if you cannot find an appropriate adjustment item in OPERATING THE MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... -
Page 25: Recycling Information
The Audio Cable is properly connected. A strange noise is heard. RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. TROUBLESHOOTING 20 PLE2208HDS-e-M043C01.P65 2008/11/28, 13:24... -
Page 26: Appendix
APPENDIX SPECIFICATIONS : ProLite E2208HDS Model Name ProLite E2208HDS-B1 ProLite E2208HDS-B2 LCD Panel Driving system a-Si TFT Active Matrix Size / Segment Diagonal: 55cm / 22" Pixel pitch 0.248mm H × 0.248mm V Brightness 300cd/m (Maximum) Contrast ratio 1000 : 1 (Typical), ACR Function Available Viewable angle Right / Left : 85 degrees each, Up:85 degrees, Down: 75 degrees (Typical) Response time... -
Page 27: Specifications : Prolite E2208Hdsv
SPECIFICATIONS : ProLite E2208HDSV LCD Panel Driving system a-Si TFT Active Matrix Size / Segment Diagonal: 55cm / 22" Pixel pitch 0.248mm H × 0.248mm V Brightness 300cd/m (Maximum) Contrast ratio 1000 : 1 (Typical), ACR Function Available Viewable angle... -
Page 28: Dimensions
DIMENSIONS DIMENSIONS 516.5mm/20.3" 60.5mm/2.4" 478.3mm/18.8" 237.3mm/9.3" COMPLIANT TIMING PC Input Horizontal Vertical Dot Clock Video Mode Frequency Frequency 31.469kHz 59.940Hz 25.175MHz 640 × 480 31.500MHz 37.500kHz 75.000Hz 40.000MHz 37.879kHz 60.317Hz SVGA 800 × 600 46.875kHz 75.000Hz 49.500MHz 48.363kHz 60.004Hz 65.000MHz 1024 ×...
