Summary of Contents for HANNspree ST19DMSB
-
Page 2: Table Of Contents
2. Setting up your TV ... 21 2.1 Basic Connections ... 21 2.1.1 Power Connection ... 21 2.1.2 Connecting an Antenna or Cable TV ... 21 2.2 Connecting External Devices ... 22 2.2.1 Connecting External Earphones ... 22 2.2.2 Connecting to AV Devices ... 23 2.2.3 Connecting a VCR/ STB/ DVD Player... - Page 3 3.10 Setting up Time menu ... 34 3.11 Closed Caption Setting ... 35 3.12 Using the Parental Controls ... 36 3.13 To Block Unrated Movie or TV Programs ... 38 3.14 To Set Rating Region Table ... 39 3.15 To Change Password ... 39 3.16 To Block by Input Source ...
-
Page 4: Regulatory Information
Regulatory Information FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 5: Description Of Warning Symbols
This symbol is used to alert users to pay attention to important descriptions regarding usage, maintenance (repair), and additional important information related to this TV. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION This symbol is used to alert users... -
Page 6: Safety Notices
Safety Notices Installation Safety Notes Location Avoid allowing the TV to get prolonged exposure to sunlight or other strong sources of heat. Leave sufficient distance between the TV and the wall to provide enough space for the emission of heat. -
Page 7: Important Safety Instructions
Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. - Page 8 Unplug this apparatus during lightning storms or when unused for long periods of time. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
- Page 9 5. If any fluid is sprayed or dropped into the TV, contact an authorized service technician. 6. The screen of the TV is made of glass. Avoid hitting or scraping it. If the screen is broken, do not touch the broken glass.
-
Page 10: Preface
The information in this manual is subject to change without notice. To the extent allowed by applicable law, Hannspree, Inc. (“Hannspree”) shall not be liable for direct, indirect, special, exemplary, incidental or consequential damages arising from any defect or omission in this manual, even if advised of the possibility of such damages in advance. -
Page 11: Recycling Information
Hannspree. The TV described in this manual may include copyrighted software of Hannspree (or other third parties). Hannspree (or other third parties) preserves the exclusive rights for copyrighted software, such as the right to distribute or reproduce the copyrighted software. -
Page 12: Trademark Notice
Trademark Notice Hannspree products incorporate High-Definition Multimedia Interface (HDMI™) technology. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. License Notice and Trademark Acknowledgment Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby... -
Page 13: Getting Started
Getting Started Package Contents Make sure the following components are included in the box. Please contact Hannspree Customer Service immediately if anything is missing or damaged. • • Power cord • Remote control and batteries • User’s manual • Quick start guide •... -
Page 14: Introducing The Tv
HDMI input ports (location of these ports depends on model). You can also use the TV as a monitor for your PC by connecting it through the VGA port. Convenient control buttons located on the TV and a handy remote control let you change channels, adjust the volume, and change display settings through an easy- to-use on-screen display menu system. -
Page 15: Control Panel
Power/ Standby indicator Speakers Function Press to turn the TV on or off. Press to open the input source list or return to the previous screen on the OSD menu. Press to open the OSD menu or confirm a selection on the OSD menu. -
Page 16: Input And Output Jacks
Connect to an external device, such as a VCR, Set-Top-Box, or a DVD player. Connect to earphones or external speakers with built-in amplifiers. Connect to an antenna or cable TV. Connect to an external device, such as S-VIDEO a VCR, Set-Top-Box, or a DVD player. -
Page 17: Remote Control
RETURN Select channel Volume adjust Function Press to turn the TV on or off. Press to open the input source list. Use to select a channel directly. Press 0-9 to enter the program numbers (press 1 and 0 for channel 10). - Page 18 Press to select a programmed Audio Receiver/ Amp/ Home Theatre System. Press to select a programmed Cable TV set-top box or a satellite TV set-top box. Press to enter TV mode. Press to switch to favorite channels. Press to adjust the width-to-height ratio of the image.
- Page 19 • For best results, use the remote control within a proper distance from the front of the TV. Do not exceed an angle of 30 degrees when pointing at TV. • The operational distance may be shortened when the signal sensor is directly exposed to strong light.
-
Page 20: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries 1 Open the battery compartment cover at the back of the remote control (A). 2 Insert the batteries paying attention to the polarity markings inside the battery compartment (B). 3 Close the battery compartment cover (C). - Page 21 CAUTION • If the remote control is not used for a long period, remove the batteries and store them properly. • Handle damaged or leaking batteries carefully, and wash hands with soap if they come in contact with leaked chemical fluids. •...
-
Page 22: Setting Up Your Tv
Basic Connections 2.1.1 Power Connection 1 Connect the power cord to the AC IN input jack on the rear of the TV. 2 Insert the plug at the other end of the power cord into a power outlet. 2.1.2 Connecting an Antenna or Cable TV Connect one end of the VHF/UHF (Antenna) or CATV cable to VHF/UHF jack on the rear of the TV. -
Page 23: Connecting External Devices
Connecting External Devices Connect external devices such as VCRs, Set-Top-Box, DVD players, video game consoles, earphones, or a PC to the TV using the appropriate ports on the rear of the 2.2.1 Connecting External Earphones Note: • External speakers or headphones are not included with the TV. -
Page 24: Connecting To Av Devices
2.2.2 Connecting to AV Devices HDMI 1 HDMI 2 AUDIO AUDIO VIDEO S-Video Audio Cable Video Cable (Optional) (Optional) HDMI Cable Audio/ Video Cable (Optional) (Optional) HDMI L VIDEO S-VIDEO Game Console... -
Page 25: Connecting A Vcr/ Stb/ Dvd Player Using Component Video
2.2.3 Connecting a VCR/ STB/ DVD Player Using Component Video Connect the TV to a VCR/ STB/ DVD player using the component video inputs. 2.2.4 Connecting a VCR/ STB/ DVD Player Using Composite Video Connect the TV to a VCR/ STB/ DVD player using the composite video input. -
Page 26: Connecting A Pc Using Vga
Connect the TV to your PC to use it as the monitor using the VGA port as shown. 1 Connect the VGA port of the TV to the VGA output of the PC. 2 Connect the AUDIO port of your TV to the line out port of the PC to listen to audio from the PC. -
Page 27: Connecting Hdmi
However, it is necessary to do so if a HDMI to DVI cable is connected. 2.2.8 Connecting USB Connect the USB flash drive to the TV using the USB port as shown. The JPEG and MP3 files are supported. Note: The USB HDD is not supported. -
Page 28: Using The Tv
TV source for channel search. Press OK to confirm. 2.3.3 Performing an Automatic Channel Search Before using the TV to view programs, you need to activate the channel search first. 1 Press MENU on the control panel or remote control, then select to enter the Channel menu. -
Page 29: Adjusting The Volume
2.3.5 Adjusting the Volume 1 Press VOL+/ VOL- on the control panel or increase/decrease the volume. MUTE 2 Press to eliminate sounds, and press buttons to restore the original volume. 2.3.6 Editing the Channel List or Favorite List 1 Press MENU on the control panel or remote control, then select to enter the Channel menu. -
Page 30: Adjusting On-Screen Display (Osd) Settings
Settings The On-Screen Display (OSD) menu system provides a quick and simple method to adjust the TV settings. The OSD menu can be accessed through the buttons either on the control panel or the remote control. Before going to details of each OSD item, you may get acquainted with the... -
Page 31: Osd Setting Menus
OSD Setting Menus Follow the instructions indicated on the bottom of the OSD Function Menu. Press on the control panel or through the menus. press VOL+ on the control panel or OK on the remote control to select an item and then press MENU to exit the OSD menu. The following menus can be set by different adjustment methods. -
Page 32: Viewing The Menus
Viewing the Menus Press MENU to display the OSD main menu. There are six top menus on the screen: Picture, Audio, Time, Setup, Lock, and Channel. Press to select your desired top menu. Press to enter the menu you select. to select the control you want to adjust. -
Page 33: Showing/Hiding Channel
Showing/Hiding Channel When the channel is hidden, it will not appear on the screen when you browse the channels with CH CH . To show/hide a channel: Press MENU to display the OSD main menu. Press to select Channel menu, and then press to enter. -
Page 34: Setting Up Picture Options
Setting up Picture Options Press MENU to display the OSD main menu. Press to select Picture menu, and then press to enter. Press to select the control of Picture Mode, Contrast, Brightness, Sharpness, Tint, Color, Backlight, X-Contrast, Color Mode, Screen Mode, Noise Reduction, and then press to adjust the level. -
Page 35: Setting Up Time Menu
3.10 Setting up Time menu Press MENU to display the OSD main menu. Press to select Time menu, and then press to enter. Press to select Sleep Timer, and then press to to set Sleep Timer from 5~240 Min, or Off. Press to select Time Zone, and select the correct time zone of your area with... -
Page 36: Closed Caption Setting
Basic Selection: To set basic analog closed caption options. (CC1~CC4, Text1~Text4, Off) Advanced Selection: To select closed caption signal formats and set up caption modes for digital TV channels. (Service1~6, Basic) For detailed Close Caption setting: Press to select Option, and then press to enter Option setting. -
Page 37: Using The Parental Controls
Y (all children) Y7 (older children) G (general audience) PG (guidance suggested) 14 (strongly cautioned) MA (mature audience) You can also customize the TV ratings for the following content: ALL (All types content) FV (fantasy violence) V (violence) S (sexual situations) - Page 38 G (general programming, suitable for all audiences) PG (parental guidance) 14+ (viewers and older) 18+ (adult programming) Press OK to switch between Lock and Unlock. Press MENU to exit. Lock TV RATING TV-Y TV-Y7 TV-G TV-PG TV-14 TV-HA :Block Move...
-
Page 39: To Block Unrated Movie Or Tv Programs
16 years) 18ans+ (reserved to adults) Press OK to switch between Lock and Unlock. Press MENU to exit. 3.13 To Block Unrated Movie or TV Programs Press to select Unrated Lock, then press to select On or Off. When On is selected all programs that are not rated will be blocked. -
Page 40: To Set Rating Region Table
3.14 To Set Rating Region Table RRT Setting defines the rating standard for a particular geographic region and/or country. Press to select RRT Setting, and then press to enter PRT setting. Select each adjustable setting with press to select the sub-selection. Press MENU to exit. -
Page 41: To Block By Input Source
3.16 To Block by Input Source Press to select Input Block, and then press to enter. Press to select the input source, then to select from Block or UnBlock. Press MENU to exit. 3.17 To Restore Factory Setting Press MEMU to display the OSD main menu. Press to select Setup menu, and then press... -
Page 42: Using Pc Function
When there is no signal in the PC mode, No Signal will be displayed on the screen and the TV will automatically turn into power-saving mode after a few seconds' idleness. Press POWER on the remote control and the TV will return to VGA mode. Picture... -
Page 43: Troubleshooting
Press on the control panel or remote control. • press INPUT to cycle through connected video sources. • Press channel up or channel down to switch to other TV channels. • Make sure all cables are connected properly. • Check the antenna and cable connections. -
Page 44: Specifications
Specifications LCD Panel Size 18.5 inch TFT Screen Format 16:9 Panel Resolution 1366 (H) x 768 (V) TV System ATV: NTSC HDMI Input x 2 YPbPr Input x 1 S-Video Input x1 Video System Composite Input x 1 VGA (PC) Input x 1... -
Page 45: Pc Mode Support Timing
PC Mode Support Timing Mode Resolution (active dot) 640x480@60Hz SVGA 800x600@60Hz 1024x768@60Hz VESA 1152x864@75Hz VESA 1280x720@60Hz VESA 1280x960@60Hz SXGA 1280x1024@60Hz VESA 1366x768@60Hz Video Mode Support Timing Resolution HDMI (active dot) 640x480p@60Hz 720x480i@60Hz 720x480p@60Hz 1280x720p@60Hz 1920x1080i@60Hz 1920x1080p@60Hz 1920x1080p@24Hz 1920x1080p@30Hz Horizontal Vertical Nominal Frequency Frequency... -
Page 46: Appendix: Remote Control Guide
TV button for TV; the corresponding indicator light will come on for 2 seconds then it goes off, and now the current electronic equipment mode has been switched to TV. -
Page 47: Searching Codes
6. During the setting process, only digit keys ‘0’ through ‘9’ are valid inputs, while other buttons are deemed invalid and do not affect the code setting. For example, inputting “02” then pressing RETURN does affect the “02” already input. 6.1.3 Searching Codes If the desired electronic equipment code for setting can not be found on the list in the... -
Page 48: Setting Channel Lock
3. While holding the electronic equipment button, press VOL- twice consecutively to cancel volume lock under current mode (for example, if volume lock was set under TV mode and you wish to transmit code values under current DVD mode, just perform this unlock operation, while those electronic equipment modes not operated still have volume locked up). -
Page 49: Factory Setting Mode
3. During the setting process, releasing the electronic equipment button exits the setting mode immediately without changing the status prior to setting. 4. Pressing any of the electronic equipment buttons to enter factory setting operation mode. 5. The default current electronic equipment is TV upon first power-on. Electronic equipment CABLE... - Page 50 Note: Each re-powering restores factory setting, and all electronic equipment modes transmit TV-mode infrared (IR) signal until being set up through code setting. For example, setting the electronic equipment code of CABLE as ‘0001’ stops transmitting TV code, whereas AUDIO and DVD continue to transmit TV code.
-
Page 51: Description
6.1.7 Description There is no multi-function code setting operation under TV mode but a fixed code for the TV manufacturer. Therefore, code setting and code-searching functions are disabled under this mode; other functions such as volume lock, channel lock and code display are operable. -
Page 52: Component Program Codes
2024, 2015 2013, 2004, Curtis Mathes 2020 Cybernex 2024 CyberPower 2102 2010, 2017, Daewoo 2025 Dell 2102 Denon 2008 Direc TV 2059 Durabrand 2007, 2006 Electrohome 2005 Electrophonic 2005 Emerex 2002 2004, 2005, 2021, 2024, 2010, 2018, Emerson 2009, 2022,... - Page 53 2004, 2020 Radix 2005 Randex 2005 Setup Code for VCR’s 2013, 2004, 2024, 2008, 2077 2004, 2005, Realistic 2012, 2011, 2017 Replay TV 2043 Runco 2007 Sampo 2005, 2012 2024, 2010, Samsung 2026 Sanky 2012, 2007 2014, 2022, Sansui 2027...
- Page 54 Setup Code for VCR’s Tashiko 2005 Tatung 2010, 2014 Technics 2004, 2020 2004, 205, Teco 2012, 2006 Teknika 2004, 2005 2048, Tivo 2044, 2098, 2059 2024 2010, 2008, 2014, Toshiba 2009, 2098, 2079, 2102 Totevision 2005, 2024 Touch 2102 Unitech 2024 Viewsonic 2102...
- Page 55 Setup Code for DVD’s Norcent 2078 2029, 2046, Onkyo 2064 Oritron 2051 Panasonic 2028, 2101 2029, 2036, Philips 2050 Pioneer 2033, 2039 Polarold 2090, 2086 Polk Audio 2036 Portland 2062 Proscan 2032 Qwestar 2051 2032, 2039, 2058, 2072 2076 Rotel 2045 Sampo 2061, 2056...
- Page 56 0051 0047, 0043, Samsung 0042 Sony 0025, 0056 Star Choice 0036 Tivo 0044, 0053 0029, 0057, Toshiba 0032, 0048 Ultimate TV 0056, 0051 Uniden 0028, 0027 US Digital 0055 USDTV 0055 Voom 0036 Zenith 0058 Setup Code for CD Aiwa...
- Page 57 Setup Code for CD Carver 3019, 3022 3001 3019 Electronics Dynamic 3022 Bass Fisher 3022 Garrard 3027 Genexxa 3005 Harman/ 3019, 3020 Kardon Hitachi 3005 Integra 3013 3009 3030, 3003, Kenwood 3007, 3006, 3023 Krell 3019 Linn 3019 Magnavox 3019 3030, 3004, Marantz 3019...
- Page 58 Setup Code for Audio Amp / Tuner’s Carver 3042 Denon 3051, 3040 Fonmix 3051 Harman/ 3014 Kardon Hitachi 3047 Integra 3017 3014 3010 Kenwood 3050, 3056 3053 3042, 3046, Magnavox 3029 Marantz 3042, 3046 Onkyo 3035, 3017 3036, 3029, Optimus 3032, 3039 Panasonic 3055...
-
Page 59: Setting The Tv On The Wall
*Installing the LCD TV requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. Hannspree bears no responsibility for improper mounting or mounting that results in accident or injury. You can ask a qualified service personnel about using an optional bracket to mount the TV to the wall. -
Page 60: Using The Cable Organizer
Using the Cable Organizer Organzie your cables by routing the cables through the cable clamp.
