4.- OPTIONAL ACCESSORIES:

Note:
- Consult the dealer or retailer for information about options available.
5.- INSTALLATION OF ACCESSORIES:
5.1.- INSTALLING THE ANTENNA:
Install the antenna as shown in the figure below and turn it clockwise until it stops.
Note:
- When installing the antenna, don't rotate it by its top,
holding it by its base and turn.
- If you use an external antenna, make sure the 'SWR' is
about 1.5:1 or less, to avoid damage to the transceiver's
final transistors.
- Do not hold the antenna with your hand or wrap the outside
of it to avoid bad operation of the transceiver.
- Never transmit without an antenna.
5.2.- INSTALLING THE BELT CLIP:
If necessary, install the belt clip at the rear of the battery compartment cover as
shown in the figure below.
Note:
- Do not use any kind of glue to fix the screw on the belt clip.
The solvents Glue may damage the battery casing.
5.3.- MICRO-HEADSET INSTALLATION OF EXTERNAL:
