Lenovo
L27m-30
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Lenovo L27m-30

Summary of Contents for Lenovo L27m-30

  • Page 1 Lenovo L27m-30 User Guide...
  • Page 2 © Copyright Lenovo 2021 LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.

  • Page 3: Table Of Contents

    Contents Safety information ............................iii General Safety guidelines ..................................iii Chapter 1. Getting started..........................1-1 Shipping contents ....................................1-1 Notice for use ......................................1-1 Product overview ....................................1-2 Types of adjustments ..................................1-2 Tilt ........................................1-2 Swivel ......................................1-2 Height Adjustment ................................... 1-3 Monitor Pivot ....................................

  • Page 4: Safety Information

    Safety information General Safety guidelines For tips to help you use your computer safely, go to: http://www.lenovo.com/safety Before installing this product, read the Safety Information. DANGER To avoid shock hazard: • Do not remove the covers. • Do not operate this product unless the stand is attached.

  • Page 5: Chapter 1. Getting Started

    This User’s Guide contains detailed information on the your Flat Panel Monitor. For a quick overview, please see the Setup Poster that was shipped with your monitor. Lenovo L27m-30 supports Lenovo Display Control Center - Artery. Shipping contents The product package should include the following items:...

  • Page 6: Product Overview

    Product overview This section will provide information on adjusting monitor positions, setting user controls, and using the cable lock slot. Types of adjustments Tilt Please see the illustration below for an example of the tilt range. Swivel With the base rubber, you can swivel the monitor for the most comfortable viewing angle. -360 Chapter 1.

  • Page 7: Height Adjustment

    Height Adjustment For height adjustment, user needs to press down or lift up the monitor. 150mm Monitor Pivot - Adjust the screen position before rotating the monitor screen. (Make sure that the monitor screen ascent to its highest point, and it inclines backward at 22°.) - then rotate clockwise /counterclockwise until the monitor stops at 90°.

  • Page 8: Monitor Controls

    Monitor controls Your monitor has controls on the front which are used to adjust the display. For information on how to use these controls, please see “Adjusting your monitor image”on page 2-3. Cable lock slot Your monitor is equipped with a cable lock slot located on the bottom of your monitor. Chapter 1.

  • Page 9: Setting Up Your Monitor

    Note: The type of plug & Socket shown here are for illustration only. 2. Connect the cables according to below icon indication. 3. For computer in HDMI connecting. Note:Lenovo recommends that customers who require to use the HDMI input on their monitor purchase the “Lenovo HDMI to HDMI cable OB47070” www.lenovo.com/support/monitoraccessories.
  • Page 10 4. For computer in Analog Signal Cable connecting. 5. Connect the speaker’s audio cable and audio jack of monitor to transfer audio source from Type-C,HDMI. Note: The audio output in Type-C,HDMI modes. Warning note: Excessive sound pressure from earphones and headphones can cause hearing loss.
  • Page 11 6. For computer in USB C-C connecting. Note: Type C Power delivery: 15W: 5V/3.0A; 27W: 9V/3.0A; 45W: 15V/3.0A;20v/2.25A ,75W:20V/3.75A (When smart power is turn on) 7. Connect one end of the USB cable to the USB downstream terminal of the monitor, and connect the other end of the USB cable to an appropriate USB port on your device.
  • Page 12 8. Insert the power cord into the monitor, then plug the monitor power cord and the computer cord into grounded electrical outlets. Note: A certified power supply cord has to be used with this equipment. The relevant national installation and or equipment regulations shall be considered. A certified power supply cord not lighter than ordinary polyvinyl chloride flexible cord according to IEC 60227 (designation H05VV-F 3G 0.75mm or H05VVH2-F2 3G 0.75mm...
  • Page 13 9. Connect the cables with cable clip. 10. Power on the monitor and the computer. Chapter 1.

  • Page 14: Registering Your Option

    Thank you for purchasing this Lenovo product. Please take a few moments to register your Product and provide us with information that will help Lenovo to better serve you in the future. Your feedback is valuable to us in developing product and services that are important to you, as well as in developing better ways to communicate with you.

  • Page 15: Chapter 2. Adjusting And Using Your Monitor

    In addition, use healthy work habits to maximize your performance and comfort while using your computer. For more detailed information on any of these topics, visit the Healthy Computing Web site at: http://www.lenovo.com/ healthycomputing/. Arranging your work area Use a work surface of appropriate height and available working area to allow you to work in comfort.

  • Page 16: Quick Tips For Healthy Work Habits

    Use adequate lighting for the type of work you are performing. Use the monitor brightness, contrast controls, if equipped to optimize the image on your screen to meet your visual preferences. Keep your monitor screen clean so you can focus on the screen’s contents. Any concentrated and sustained visual activity can be tiring for your eyes.

  • Page 17: Adjusting Your Monitor Image

    Adjusting your monitor image This section describes the control features to adjust your monitor image. Using the direct access controls The direct access controls can be used when the On Screen Display (OSD) is not displayed. Table 2-1. Direct access controls Icon Control Description...

  • Page 18: Using The On-Screen Display (Osd) Controls

    Using the On-Screen Display (OSD) controls To adjust the settings, the user controls can be viewed through the OSD. L27m-30 1920x1080 Brightness Contrast Display Mode Scaling Mode Over Drive Input Signal: VGA To use the controls: 1. Press to open the main OSD menu.
  • Page 19 Table 2-2. OSD functions OSD Icon on Controls and Sub menu Description Main Menu Adjustments Brightness Adjust bar Contrast Adjust bar Standard Game Display Mode Standard Movie Picture Basic image Full Screen setting Scaling Mode Full Screen Original AR Over Drive Normal Normal Extreme...
  • Page 20 OSD Icon on Controls and Sub menu Description Main Menu Adjustments Model Refresh Information Firmware Serial Number English/French/Italian/Chinese/Spanish/ Language English Japanese/German/Russian Menu Horizontal Adjust bar Menu Vertical Adjust bar Smart Power Menu setting Cancel Reset All Settings Factory Reset Off/0 Transparency OSD Timeout Adjust bar (5-60)

  • Page 21: Selecting A Supported Display Mode

    Selecting a supported display mode The display mode the monitor uses is controlled by the computer. Therefore, refer to your computer documentation for details on how to change display modes. The image size, position and shape might change when the display mode changes. This is normal and the image can be readjusted using automatic image setup and the image controls.

  • Page 22: Understanding Power Management

    Understanding power management Power management is invoked when the computer recognizes that you have not used your mouse or keyboard for a user-definable period. There are several states as described in the table below. For optimal performance, switch off your monitor at the end of each working day, or whenever you expect to leave it unused for long periods during the day.

  • Page 23: Caring For Your Monitor

    Caring for your monitor Be sure to turn off the power before you perform any maintenance on the monitor. Do not: Apply water or liquid directly to your monitor. Use solvents or abrasives. Use flammable cleaning materials to clean your monitor or any other electrical equipment. Touch the screen area of your monitor with sharp or abrasive items.
  • Page 24 Step 4: Attach the mounting bracket from the VESA compatible wall mounting kit (100mm x100mm distance), VESA Mounting Screw M4 x 10 mm. VESA hole Step 5: Attach the LCD display to the wall, following the instructions in the wallmounting kit. For use only with UL/GS Listed Wall Mount Bracket with minimum weight/load: 12.3 kg.

  • Page 25: Chapter 3. Reference Information

    Chapter 3. Reference information This section contains monitor specifications, instructions to manually install the monitor driver, troubleshooting information, and service information. Monitor specifications Table 3-1. Monitor specifications for type-model 66D0-KAC2-WW Dimensions Depth 214.92 mm (8.46 in.) Height 414.16 mm (16.31 in.) Width 612.49 mm (24.11 in.) Panel...
  • Page 26 Table 3-1. Monitor specifications for type-model 66D0-KAC2-WW Video input (Analog) Interface Input signal Analog Direct Drive, 75 ohm 0.7V Horizontal addressability 1920 pixels (max) Vertical addressability 1080 lines (max) Clock frequency 170 MHz Video input (Type-C) Interface Type-C Input signal VESA TMDS (Panel Link™) Horizontal addressability 1920 pixels (max)

  • Page 27: Troubleshooting

    Troubleshooting If you have a problem setting up or using your monitor, you might be able to solve it yourself. Before calling your dealer or Lenovo, try the suggested actions that are appropriate to your problem. Table 3-2. Troubleshooting Problem...
  • Page 28 Table 3-2. Troubleshooting Problem Possible cause Suggested action Reference One or more of This is a characteristic If there are more than five Appendix A.”Service the pixels appear of the LCD technology pixels missing, contact the Support”on page discolored. and is not an LCD Support Center.

  • Page 29: Manually Installing The Monitor Driver

    Note: On LCD monitors, unlike CRTs, a faster refresh rate does not improve display quality. Lenovo recommends using either 1920 x 1080 at a refresh rate of 60 Hz, or 640 x 480 at a refresh rate of 60 Hz.

  • Page 30: Installing The Monitor Driver In Windows 10

    Color Matching Profiles. Note: On LCD monitors, unlike CRTs, a faster refresh rate does not improve display quality. Lenovo recommends using either1920 x 1080 at a refresh rate of 60 Hz, or 640 x 480 at a refresh rate of 60 Hz.

  • Page 31: Appendix A. Service And Support

    Appendix A. Service and Support The following information describes the technical support that is available for your product, during the warranty period or throughout the life of your product. Refer to the Lenovo Limited Warranty for a full explanation of Lenovo warranty terms.

  • Page 32: Appendix B. Notices

    Web sites. The materials at those Web sites are not part of the materials for this Lenovo product, and use of those Web sites is at your own risk.

  • Page 33: Recycling Information

    Collecting and recycling a disused Lenovo computer or monitor If you are a company employee and need to dispose of a Lenovo computer or monitor that is the property of the company, you must do so in accordance with the Law for Promotion of Effective Utilization of Resources.

  • Page 34: Power Cords And Power Adapters

    Power cords and power adapters Use only the power cords and power adapters supplied by the product manufacture Do not use the ac power cord for other devices. Appendix B.
