Summary of Contents for Chauvet Work Light
-
Page 1: User Manual
Snapshot Use on Dimmer Outdoor Use Sound Activated Master/Slave Auto-ranging Power Supply Replaceable Fuse User Serviceable Duty Cycle User Manual 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
LAIMS ... 14 ECHNICAL PECIFICATIONS CHAUVET®, 2010, All Rights Reserved Information and specifications in this User Manual are subject to change without notice. CHAUVET® assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. -
Page 3: Before You Begin
Manual Conventions CHAUVET® manuals use the following conventions to differentiate certain types of information from the regular text. ONVENTION [10] <Menu>... -
Page 4: Safety Instructions
Safety Instructions Please read these instructions carefully. It includes important information about the installation, usage and maintenance of this product. Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Always make sure that you are connecting to the proper voltage, and that the line voltage you are connecting to is not higher than that stated on the decal or rear panel of the fixture. -
Page 5: Introduction
2. I NTRODUCTION Features Complete LED wash system Includes footswitch with 16 ft cable, tripod with bag and transport case for lights Safely mounts to truss with clamps Independent positioning of each light Low-profile lights are 1.2 in deep Adjustable stand from 54 in to 85 in Built-in automated programs Built-in sound activated programs Features (footswitch) -
Page 6: Product Overview
Product Overview Tripod Stand Microphone Sensitivity Securing Knob Adjustment Knob Back Panel Microphone Fuseholder Lights (4) Tripod Stand Mini 4BAR™ Carrying Case Foot Switch 2. Introduction 5/7/2010 1:21 PM... -
Page 7: Setup
3. S ETUP AC Power This fixture runs on 100~240 VAC, 50/60 Hz. Before powering on the unit, make sure the line voltage to which you are connecting it is within the range of accepted voltages. Always connect the fixture to a switched circuit. Never connect the fixture to a rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer channel is used only as a 0 to 100% switch. -
Page 8: Orientation
Orientation This fixture may be mounted on the included tripod stand, in any location, provided there is adequate room for ventilation. Rigging There are two methods of mounting this fixture. Using the included tripod stand Using a clamp on the two clamp hanging bolts Adjust the angle of the each of the four lights on the fixture by loosening both knobs and tilting the fixture. -
Page 9: Tripod Stand
Tripod Stand This fixture may be mounted on the included tripod stand. Setup the Tripod stand on a sturdy platform that is capable of holding at least 10 times the weight of the stand with Mini 4BAR™. Use the Tripod Legs Adjustment Knob to slide open the legs and set the tripod to a safe operating level. -
Page 10: Operating Instructions
4. O PERATING NSTRUCTIONS Pedal #1 (Auto Program Selection) Footswitch operation The included footswitch provides quick access to preset colors, color change programs, and sound triggering via the onboard microphone on the Mini 4BAR™. Please see the chart, along with the set of instructions, below for further explanation. -
Page 11: Appendix
5. A PPENDIX General Maintenance To maintain optimum performance and minimize wear, fixtures should be cleaned frequently. Usage and environment are contributing factors in determining frequency. As a general rule, fixtures should be cleaned at least twice a month. Dust build up reduces light output performance and can cause overheating. -
Page 12: General Troubleshooting
Device does not power up Fixture is not responding to Loss of signal If you still have a problem after trying the above solutions, please contact CHAUVET® Technical Support. Contact Us W o r l d W i d e General Information... -
Page 13: Returns Procedure
Package must be clearly labeled with a Return Merchandize Authorization Number (RMA #). Products returned without the RMA # will be refused. Call CHAUVET® and request an RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 14: Technical Specifications
Technical Specifications WEIGHT & DIMENSIONS Length ... 3 in (76 mm) Width... 38 in (965 mm) Height (light fixture only, NOT mounted on the included stand) ... 9 in (229 mm) Height (using the stand) ... 54~85 in (1,372~2,159 mm) Weight (includes the light fixture, footswitch, and tripod stand) ...
