Greenlee Fairmont H4665A Service Manual
Submersible pump
Hide thumbs
Also See for Fairmont H4665A:
- Specifications and parts list (14 pages) ,
- Instruction manual (38 pages)
Related Manuals for Greenlee Fairmont H4665A
Summary of Contents for Greenlee Fairmont H4665A
- Page 1 SERVICE MANUAL H4665A/42191 SUBMERSIBLE PUMP Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 999 1606.1 REV 7 © 1999 Greenlee Textron 7/99...
-
Page 2: Table Of Contents
Greenlee Textron / Subsidiary of Textron Inc. Purpose This manual is intended to familiarize all personnel with the safe service procedures for the H4665A/42191, serial code FTY Submersible Pump. Keep this manual available to all personnel. Replacement manuals are available upon request at no charge. -
Page 3: Important Safety Instructions
MAY result in injury or property damage. Before operating this tool, see the safety information and operating instructions in the Operation Manual. Greenlee Textron / Subsidiary of Textron Inc. Do not operate the pump if the impeller blades are exposed. After assembly, install the inlet screen before operating the pump. - Page 4 Hot hydraulic fluid can cause serious burns. Greenlee Textron / Subsidiary of Textron Inc. Hydraulic oil can cause skin irritation. • Handle the tool and hoses with care to prevent skin contact with hydraulic oil.
-
Page 5: Disassembly
(39, 40). 2. Remove the other three socket head cap screws (25) to remove motor assembly from volute (24). Greenlee Textron / Subsidiary of Textron Inc. Retainer Serial Number 97720 and after: 1. Remove six socket head cap screws (22) to remove retainer (18) from motor assembly. -
Page 6: Inspection
2. Use a blind-hole bearing puller to remove the bearings from the motor cap or motor body. Greenlee Textron / Subsidiary of Textron Inc. Inspection Clean all parts with solvent and dry them thoroughly. Inspect each component as described in this section. -
Page 7: Assembly
Motor Cap Needle Bearing Surface A Motor Body O-ring Seal Greenlee Textron / Subsidiary of Textron Inc. Motor 1. Serial Number before 97720: Install O-ring (H) below bearing in motor body (1) using an O-ring tool. Be careful not to damage O-ring during installation. -
Page 8: Assembly
(30). Follow the manufacturer’s instructions for curing. Secure impeller and shims to shaft with left- handed acorn nut (30) by tightening counterclockwise. Greenlee Textron / Subsidiary of Textron Inc. Impeller Clearance 1. To check impeller (29) clearance, install shims (31) and inlet (32) on volute (24) using six hex head cap screws (not provided). -
Page 9: Exploded Views And Parts List
H4665A/42191 Submersible Pump Exploded View H4665A/42191 Submersible Pump Serial Number 97720 and After 12,13 26,27 Apply locking compound to threads. SECTION A-A Greenlee Textron / Subsidiary of Textron Inc. 35,36,37 4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070... - Page 10 41547 F015482K1 42104 F024472 Repair Parts 41122 139028 Greenlee Textron / Subsidiary of Textron Inc. PART DESCRIPTION Motor Body (includes item 2) ... 1 Needle Bearing, .439 x .625 x .500" ... 2 Drive Shaft ... 1 Bearing ... 1 Retaining Ring, Two Piece External, .594"...
- Page 11 H4665A/42191 Submersible Pump Exploded View H4665A/42191 Submersible Pump Motor Serial Number Before 97720 Greenlee Textron / Subsidiary of Textron Inc. 1, 2, H, J 4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070...
- Page 12 42751 42741 42646 42836 41503 41872 Repair Kits 41122 Greenlee Textron / Subsidiary of Textron Inc. PART DESCRIPTION L080038 O-ring, .125 x .250 x .062"–70 ... 2 L060305 Seal Retainer Housing ... 1 F015679 O-ring, .875 x 1.00 x .062"–70 ... 1 L080060 Quad Ring, .562 x .687 x .062"–70 ...
-
Page 13: Accessories
