- Page 1 Order Number : GETEC-C1-12-051 FCC Part 15 subpart B Test Report Number : GETEC-E3-12-024 Page 1 / 1 APPENDIX G : USER’S MANUAL EUT Type: LED LCD TV/Monitor FCC ID.: BEJM2382D...
- Page 2 OWNER’S MANUAL CINEMA 3D TV / LED LCD TV Please read this manual carefully before operating the your TV and retain it for future reference. CINEMA 3D TV MODEL LED LCD TV MODEL DM2382D M2382D M2482D www.lg.com...
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS CINEMA 3D TV LICENSES LED LCD TV INSALLATION PROCE DURE CUSTOMIZING SETTINGS Accessing main menus ASSEMBLING AND PREPARING USING THE USER GUIDE Unpacking - CINEMA 3D TV Accessing User Guide menu. - LED LCD TV - Using the TV menu Parts and buttons - Using the Remote Control... - Page 4 TABLE OF CONTENTS EXTERNAL CONTROL DEVICE SETUP (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) RS-232C Setup Type of connector; D-Sub 9-Pin Male RS-232C configurations Communication Parameters Command reference list Transmission / Receiving protocol...
-
Page 5: Licenses
LICENSES LICENSES Supported licenses may differ by model. For more information of the licenses, visit www.lg.com. Manufactured under license from Dolby Laboratories. “Dolby “and the double-D symbol are trademarks of Dolby Laboratories. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. -
Page 6: Insallation Proce Dure
INSTALLATION PROCE DURE INSALLATION PROCE DURE Open the package and make sure all the accessories are included. Attach the stand to the TV. Connect an external device to the TV. NOTE Image shown may differ from your TV. Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. The available menus and options may differ from the input source or product model that you are using. -
Page 7: Assembling And Preparing
ASSEMBLING AND PREPARING ASSEMBLING AND PREPARING Unpacking Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. -
Page 8: Cinema 3D Tv
ASSEMBLING AND PREPARING CINEMA 3D TV DM2382D Remote control. CD (Owner's Manual). RGB Cable. Batteries (AAA). Cards. (See p.32) (See p.31) Power Cord. AC-DC Adapter. Cable Tie. (See p.12) (See p.12) (See p.13) Stand Base. Stand Body. Screws for Assembly. -
Page 9: Led Lcd Tv
ASSEMBLING AND PREPARING LED LCD TV M2382D M2482D Remote control. CD (Owner's Manual). RGB Cable. Batteries (AAA). Cards. (See p.34) (See p.31) Power Cord. AC-DC Adapter. Cable Tie. (See p.12) (See p.12) (See p.13) Stand Base. Stand Body. Screws for Assembly. 2 EA (See p.11) (See p.11) -
Page 10: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons PCMCIA Card Slot Standby Light Lighting On: Turned off Lighting Off: Turned on Remote Control Touch Buttons Sensor AV IN 2 (MONO) Connection panel (See p.19) Touch button Description Scrolls through the saved programmes. Adjusts the volume level. -
Page 11: Lifting And Moving The Tv
ASSEMBLING AND PREPARING When holding the TV, the screen should face Lifting and moving the TV away from you to prevent the screen from scratches. When moving or lifting the TV, read the following to prevent the TV from being scratched or damaged and for save transportation regardless of its type and size. -
Page 12: Setting Up The Tv
ASSEMBLING AND PREPARING Setting up the TV Secure the TV and the Stand Body with the 2 screws. Attaching the Stand If you are not mounting the TV to a wall, use the following instructions to attach the stand. Place the TV with the screen side down on a flat and cushioned surface. -
Page 13: Mounting On A Table
ASSEMBLING AND PREPARING Mounting on a table WARNING When you adjust the angle, do not hold Lift and tilt the TV into its upright position on a the buttom of the TV frame as shown on table. the following illustration, as may injure your Leave a 10 cm (4 inches) (minimum) space fingers. -
Page 14: Tidying Cables
ASSEMBLING AND PREPARING Using the Kensington security system NOTE Tilt from +20 to -5 degrees up or down to The Kensington security system connector is adjust the angle of the TV to suit your view. located at the back of the TV. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit http://www.kensington.com . -
Page 15: Detaching The Stand
ASSEMBLING AND PREPARING Detaching the Stand Remove 2 screws and pull out the Stand Body from the TV. Place the TV with the screen side down on a flat and cushioned surface. CAUTION Lay a foam mat or soft protective cloth on the surface to protect the screen from damage. -
Page 16: Mounting On A Wall
If you use improper screw, the product might be damaged and drop from mounted position. In this case, LG Electronics is not responsible for it. VESA compatible only with respect to screw mounting interface dimensions and mounting... - Page 17 If you install the TV on a ceiling or slanted wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. Do not over tighten the screws as this may cause damage to the TV and void your warranty.
-
Page 18: Watching Tv
WATCHING TV WATCHING TV Turning the TV on for the first time When you access the TV for the first time, the initial setting screen appears. Select a language and customize the basic settings. Connect the power cord to a power outlet. Press on the TV or power button on the remote control to turn the TV on. - Page 19 WATCHING TV NOTE For those countries without confirmed DTV broadcasting standards, some DTV features might not work, depending on the DTV broadcasting environment. When France is selected for Country, the initial password is not ‘0’ , ‘0’ , ‘0’ , ‘0’ but ‘1’ , ‘2’ , ‘3’ , ‘4’ . To display images in the best quality for your home environment, select Home Use mode.
-
Page 20: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS Connect various external devices to the TV and switch input modes to select an external device. For more information about an external device’s connection, refer to the manual supplied with each device. Available external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, camcorders or cameras, gaming devices, and other external devices. -
Page 21: Connecting To A Hd Receiver, Dvd, Vcr Player Or Gaming Device
MAKING CONNECTIONS Connecting to a HD receiver, DVD, VCR player or Gaming device Connect a HD receiver, DVD, VCR player or Gaming device to the TV and select an appropriate input mode. HDMI connection HDMI is the best way to connect a device. Transmits the digital video and audio signals from an external device to the TV. -
Page 22: Dvi To Hdmi Connection
MAKING CONNECTIONS DVI to HDMI connection Transmits the digital video signal from an external device to the TV. Connect the external device and the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an optional audio cable. -
Page 23: Component Connection
MAKING CONNECTIONS Component connection Transmits the analog video and audio signals from an external device to the TV. Connect the external device and the TV with the component cable as shown on the following illustration. To display images by using progressive scan, make sure to use the component cable. NOTE If cables are installed incorrectly, it could case the image to display in black and white or with distorted color. -
Page 24: Composite Connection
MAKING CONNECTIONS Composite connection Transmits the analog video and audio signals from an external device to the TV. Connect the external device and the TV with the composite cable as shown on the following illustration. NOTE Check to ensure the cable are matched with the corresponding color connection. AV IN 2 (MONO) (Not Provided) -
Page 25: Euro Scart Connection
MAKING CONNECTIONS Euro Scart connection Transmits the video and audio signals from an external device to the TV. Connect the external device and the TV with the Euro Scart cable as shown on the following illustration. To display images by using progressive scan, make sure to use the Euro Scart cable. -
Page 26: Connecting To An Audio System
MAKING CONNECTIONS Connecting to an audio system Use an optional external audio system instead of the built-in speaker. NOTE If you use an external audio device instead of the built-in speaker, set the TV speaker feature to off Digital optical audio connection Transmits the digital audio signal from the TV to an external device. -
Page 27: Headphone Connection
MAKING CONNECTIONS Headphone connection Transmits the headphone signal from the TV to an external device. Connect the TV with the headphone as shown on the following illustration. AV IN 2 (MONO) (Not Provided) Headphone... -
Page 28: Connecting To A Usb
MAKING CONNECTIONS Connecting to a USB Connect a USB storage device such as s USB flash memory, external hard drive, MP3 player or a USB memory card reader to the TV and access the USB menu to use various multimedia files. AV IN 2 (MONO) (Not Provided) -
Page 29: Connecting To A Pc
MAKING CONNECTIONS Connecting to a PC Your TV supports the Plug & Play* feature and has the built-in speakers with Infinite Surround that reproduces sound clearly with a rich bass. * Plug & Play: The function when a PC recognizes a connected device that users connect to a PC and turn on, without device configuration or user intervention. -
Page 30: Hdmi Connection
MAKING CONNECTIONS HDMI connection Transmits the digital video and audio signals from your PC to the TV. Connect the PC and the TV with the HDMI cable as shown in the following illustrations. You should set PC as an input label to connect the PC to the TV with an HDMI connection. -
Page 31: Dvi To Hdmi Connection
MAKING CONNECTIONS DVI to HDMI connection Transmits the digital video signal from your PC to the TV. Connect the PC and the TV with the DVI to HDMI cable as shown the following illustrations. To transmit an audio signal, connect an optional audio cable. NOTE If you want to use HDMI-PC mode, you must set the input label to PC mode. -
Page 32: Rgb Connection
MAKING CONNECTIONS RGB connection Transmits the analog video signal from your PC to the TV. Connect the PC and the TV with the D-sub 15 pin cable as shown the following illustrations. To transmit an audio signal, connect an optional audio cable. NOTE If you do not use an optional external speaker, connect the PC to the TV with the optional audio cable. -
Page 33: Remote Control
REMOTE CONTROL REMOTE CONTROL CINEMA 3D TV DM2382D The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching ends to the label inside the compartment, and close the battery cover. - Page 34 REMOTE CONTROL INFO Views the information of the Q.MENU currently program and the Accesses the quick menus. screen. 3D OPTION(Only 3D Mode) View for 3D Mode setting. SETTINGS MUTE Accesses the main menus 3D OPTION or saves your input and exit Navigation buttons menus.
-
Page 35: Led Lcd Tv
REMOTE CONTROL LED LCD TV M2382D M2482D The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching ends to the label inside the compartment, and close the battery cover. - Page 36 REMOTE CONTROL GUIDE Shows programme guide. Q.MENU Accesses the quick menus. SETTINGS Accesses the main menus MUTE or saves your input and exit menus. Navigation buttons SETTINGS GUIDE Q.MENU Scrolls through menus or options. Selects menus or options and confirms your input. SIMPLINK Accesses the AV devices connected to the TV;...
-
Page 37: Customizing Settings
CUSTOMIZING SETTINGS CUSTOMIZING SETTINGS Accessing main menus Press SETTINGS to access the main menus. Press the Navigation buttons to scroll to one of the following menus and press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. When you are finished, press EXIT. -
Page 38: Using The User Guide
USING THE USER GUIDE USING THE USER GUIDE 8VHU *XLGH Accessing User Guide menu. 7R XVH LQSXW GHYLFH Using the TV menu 7R XVH (QHUJ\ 6DYLQJ IHDWXUH 352*5$00( 6HWWLQJ 7R XVH 683(5 (QHUJ\ 6DYLQJ IHDWXUH 3,&785( 6281' 6HWWLQJ 7R VHW WLPH RSWLRQV Press SETTINGS to access the main menus. -
Page 39: Imaging(Only Cinema 3D Tv)
3D IMAGING(ONLY CINEMA 3D TV) 3D IMAGING(ONLY CINEMA 3D TV) 3D Technology This TV can display in 3D via 3D broadcasting or when the TV is connected to a compatible device, such as a Blu-ray 3D Player. The viewer must wear compatible 3D glasses in order to see these images in 3D format. -
Page 40: Maintenance
MAINTENANCE MAINTENANCE Cleaning Your TV Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. When the TV is left unattended and unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges. -
Page 41: Preventing "Image Burn" Or "Burn-In" On Your Tv Screen
MAINTENANCE Preventing “Image burn” or “Burn-in” on your TV screen If a fixed image displays on the TV screen for a long period of time, it will be imprinted and become a permanent disfigurement on the screen. This is “image burn” or “burn-in” and not covered by the warranty. -
Page 42: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING General Problem Resolution y Check the remote control sensor on the product and try again. Cannot control the TV with the remote control. y Check if there is any obstacle between the product and the remote control. y Check if the batteries are still working and properly installed ( y Check if the product is turned on. -
Page 43: Specifications
SPECIFICATIONS SPECIFICATIONS DM2382D Panel Screen Type 584.2 mm Wide (23 inch) IPS(In-Plane Switching technology) Panel. Visible diagonal size : 584.2 mm Pixel Pitch 0.265 mm (H) x 0.265 mm (V) Video Signal Max. Resolution 1920 × 1080 @ 60 Hz Recommended Resolution 1920 ×... - Page 45 SPECIFICATIONS M2482D Panel Screen Type 609.7 mm Wide (24 inch) LED(light-emitting diode) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 609.7 mm Pixel Pitch 0.276 mm (H) x 0.276 mm (V) Video Signal Max. Resolution 1920 × 1080 @ 60 Hz Recommended Resolution 1920 ×...
- Page 46 SPECIFICATIONS Component supported mode RGB (PC) / HDMI (PC) supported mode Horizontal Vertical Horizontal Vertical Resolution Resolution Frequency(kHz) Frequency(Hz) Frequency(kHz) Frequency(Hz) 720 x 480 15.730 59.940 720 x 400 31.468 70.080 720 x 480 15.750 60.000 640 x 480 31.469 59.940 720 x 576 15.625...
- Page 47 SPECIFICATIONS NOTE Avoid keeping a fixed image on the set’s screen for prolonged periods of time. The fixed image may become permanently imprinted on the screen. Use a screen saver when possible. There may be interference relating to resolution, vertical pattern, contrast or brightness in PC mode. Change the PC mode to another resolution or change the refresh rate to another rate or adjust the brightness and contrast on the menu until the picture is clear.
- Page 48 SPECIFICATIONS 3D video input format supported. (Only CINEMA 3D TV) Signal Resolution Horizontal Vertical Playable 3D video format Frequency Frequency (kHz) (Hz) 720p 1280 x 720 Top & Bottom, Side by Side 89.9 59.94 HDMI Frame Packing 37.5 Top & Bottom, Side by Side HDMI Frame Packing 1080i 1920 x 1080...
-
Page 49: Ir Code
IR CODE (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) IR CODE (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) This feature is not available for all models. Code (Hexa) Function Note R/C BUTTON (POWER ON/OFF) (POWER) Energy Saving (... -
Page 50: Like A Hotel)
EXTERNAL CONTROL DEVICE SETUP (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) EXTERNAL CONTROL DEVICE SETUP (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) RS-232C Setup Type of connector; D-Sub 9-Pin Male Connect the RS-232C (serial port) input jack to an external control device (such as a computer or an A/V control system) to control the product’s... -
Page 51: Rs-232C Configurations
EXTERNAL CONTROL DEVICE SETUP (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) RS-232C configurations Set ID Set ID number. "Real Data Mapping" on See p.56 7-Wire Configuration 6(77,1*6 Press to access the main menus. (Serial female-female NULL modem cable) Press the Navigation buttons to scroll to 237,21 and press 2.. -
Page 52: Communication Parameters
EXTERNAL CONTROL DEVICE SETUP (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) Communication Parameters Baud rate: 9600 bps (UART) Data length: 8 bits Parity : None Stop bit: 1 bit Communication code: ASCII code Use a crossed (reverse) cable. Command reference list DATA COMMAND1... -
Page 53: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) Transmission / Receiving protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV.(j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the set ID to choose desired TV ID number in option menu. - Page 54 EXTERNAL CONTROL DEVICE SETUP (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) 01. Power (Command: k a) 03. Screen Mute (Command: k d) To control Power On/Off of the set. To select screen mute on/off. Transmission Transmission [k][a][ ][Set ID][ ][Data][Cr] [k][d][ ][Set ID][ ][Data][Cr]...
- Page 55 EXTERNAL CONTROL DEVICE SETUP (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) 07. Brightness (Command: k h) 11. OSD Select (Command: k l) To adjust screen brightness. To select OSD (On Screen Display) on/off when You can also adjust brightness in the PICTURE controlling remotely.
- Page 56 EXTERNAL CONTROL DEVICE SETUP (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) 15. Balance (Command: k t) 18. Auto Configure(Command: j u) To adjust balance. To adjust picture position and minimize image You can also adjust balance in the AUDIO menu. shaking automatically.
- Page 57 EXTERNAL CONTROL DEVICE SETUP (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) 20. Programme Add/Skip (Command: m b) 21. Key (Command: m c) To set skip status for the current Programme. To send IR remote key code. Transmission Transmission [m][b][ ][Set ID][ ][Data][Cr]...
- Page 58 EXTERNAL CONTROL DEVICE SETUP (ONLY APPLIED TO B2B MODEL USED IN A PLACE LIKE A HOTEL) 24. 3D(Command: x t) (only 3D model) 25. Extended 3D(Command: x v) (only 3D model) To change 3D mode for TV. To change 3D mode for TV. Transmission Transmission [x][v][ ][Set ID][ ][Data01][ ] [Data02][Cr]...
- Page 59 Make sure to read the Safety Precautions before using the product. Keep the Owner’s Manual (CD) in an accessible place for future reference. The model and serial number of the TV is located on the back and one side of the TV. Record it below should you ever need service.
- Page 60 Regulatory Information cont. respecte toutes les exigences du Règlement sur le FCC Compliance Statement matériel brouilleur du Canada. This equipment has been tested and found to comply NOTICE within the limits of a Class B digital device pursuant to Part The regulations are applied only to the products with the 15 of the FCC Rules.
- Page 61 Regulatory Information cont. Why do we have environmentally labelled computers? visual ergonomics. In many countries, environmental labelling has become an established method for encouraging the adaptation of Below you will find a brief summary of the ecological goods and services to the environment. With the growing requirements met by this product.
