Summary of Contents for Lenovo Legion 7 16ACHg6 1
- Page 1 User Guide Lenovo Legion 7 (16″, 6)
- Page 2 • Setup Guide First Edition (March 2021) © Copyright Lenovo 2021. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
-
Page 3: Table Of Contents
The Novo Button menu ... . Call Lenovo ....Open the Novo Button menu .. - Page 4 User Guide...
-
Page 5: About This Guide
About this guide • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) Legion 7 16ACHg6 82N6 82N6 Lenovo Legion 7 16ACHg6 Lenovo Legion 7 16ACHg6 1 82N6 •... - Page 6 User Guide...
-
Page 7: Chapter 1. Meet Your Computer
Capture still and moving images for taking photos, recording videos, and video chatting. 2. Camera light If the light is on, the camera is in use. Display text, graphics, and videos. 3. Screen 4. Microphones Capture or record sound and voice. © Copyright Lenovo 2021... -
Page 8: Base
Base 1. Wireless antennas Send and receive radio waves for the built-in wireless LAN (local area network) and Bluetooth module. Note: The antennas are not visible from the outside of the computer. 2. Charging LED Indicate whether the computer is plugged into a working electrical outlet. -
Page 9: Left
Left 1. Ventilation slots (outlet) Maintain the outgoing airflow to dissipate internal heat. Attention: Do not block the ventilation slots. Otherwise, the computer may overheat. ® 2. USB-C connector A versatile port that supports: • USB data transfer • Power output to supply power to bus-powered devices •... -
Page 10: Right
Right 1. Camera switch Enable/disable the integrated camera. 2. USB-C connector Connect to USB storage or data devices. Note: An appropriate adapter may be needed for connecting external devices. This USB-C port does not support DisplayPort Alt Mode. To connect external display devices through a USB-C port, use the USB- C port on the left or rear side of the computer. -
Page 11: Rear
The always-on function can be turned on or off in the UEFI/BIOS setup utility. Note: If Lenovo Vantage is pre-installed on your computer, you can also set always-on function from within that software. -
Page 12: Bottom
Bottom 1. Ventilation slots (inlet) Maintain the incoming airflow to dissipate internal heat. Attention: Do not block the ventilation slots. Otherwise, the computer might overheat. 2. Speakers Produce sound. User Guide... -
Page 13: Overview Of Leds
Overview of LEDs Your computer is equipped with many LEDs. Among them, some LEDs (1 and 4) provide you with information about the computer’s power and battery status; the rear connector LEDs (2) help you locate connectors when plugging in external devices; the logo (3), ventilation slot (5), side (6), and keyboard (7) LEDs can be customized to create various lighting effects. -
Page 14: The Charging Led
The charging LED The charging LED indicates whether your computer is plugged into a working electrical outlet. If plugged, the color of the LED helps you determine whether the battery is close to being fully charged. LED status Indication Solid white Connected to a working electrical outlet;... -
Page 15: Use An Instant Lighting Effect Of Corsair Icue
Lighting effect Description Ripple The keyboard LEDs are turned off. However, when you type, with the key you pressed as the center, the surrounding keys, from near to far, turn on and off quickly. This simulates ripples produced by throwing a stone in a pond. - Page 16 Step 3. Double-click the newly created profile and type a name for it. Step 4. Click the LIGHTING EFFECTS tab and then click the plus sign next to it. Step 5. On the computer illustration (shown under the DEVICES tab), click an area without LEDs to de- select all LEDs.
-
Page 17: Features And Specifications
Features and specifications Dimensions • Width: 356 mm • Depth: 260 mm • Thickness – Thinnest: 20.1 mm – Thickest: 23.5 mm ac power adapter • Input: 100 V ac–240 V ac, 50 Hz–60 Hz • Output: 20 V dc, 15 A •... -
Page 18: Statement On Usb Transfer Rate
Connectors and slots • Power connector • Combo audio jack • Ethernet connector • HDMI 2.1 connector. Supports maximum output resolution of 7680 x 4320, at 60 Hz frame rate. • USB Type-A connector × 2 • USB Type-A connector (with Always-on function) –... -
Page 19: Operating Environment
USB device Data rate (Gbit/s) 3.2 Gen 1 3.2 Gen 2 Operating environment Maximum altitude (without pressurization) 3048 m (10 000 ft) Temperature • At altitudes up to 2438 m (8000 ft) – Operating: 5°C to 35°C (41°F to 95°F) –... - Page 20 User Guide...
-
Page 21: Chapter 2. Get Started With Your Computer
Add additional user accounts if you need to share your computer with family members or other users. Step 1. Open the Start menu and select Settings ➙ Accounts ➙ Family & other users. Step 2. Select Add someone else to this PC. © Copyright Lenovo 2021... -
Page 22: Windows Desktop
Note: To add family members, you need to sign in with a Microsoft account. Step 3. Set the user name and password for the user account. Windows desktop Change account settings, lock the computer, or sign out of the 1. Account current account. -
Page 23: Windows Updates
To open it, type its name in the Windows Search box and select the matched result. If neither of the apps is pre-installed, you may install one on your own. Lenovo Vantage is available for download free of charge from the Microsoft Store. -
Page 24: Connect To Wired Networks
Connect to wired networks If your computer includes an Ethernet (RJ-45) connector, you can use an Ethernet cable to connect your computer to a wired network. Connect to Wi-Fi networks ® If your computer includes a wireless LAN module, you can connect your computer to Wi-Fi networks. -
Page 25: Open The Novo Button Menu
The Fn key and hotkeys The Fn key Many keys on a Lenovo keyboard have dual functions: a default function and a hidden function. The Fn key is used to modify a dual-function key to activate its hidden function. Note: The Fn key is located in the lower left corner on a Lenovo keyboard. -
Page 26: Dual-Function Keys Without Printed Icons
Press the NumLock key to enable or disable the numeric keypad. Set macro keys If Lenovo Vantage is pre-installed, you can use the app to create macro keys for use in gaming or other apps. Step 1. Open Lenovo Vantage. -
Page 27: Chapter 3. Explore Your Computer
10°C (50°F) and 35°C (95°F). Note: You can check the battery temperature in Lenovo Vantage or Lenovo PC Manager. To maximize the life of the battery, once the battery is fully charged, it must discharge to 94% or lower before it will be allowed to recharge again. -
Page 28: A Power Plan
In another scenario, if you carry your computer around without the included ac power adapter, you may use a capable USB-C charger to provide power through the rear USB-C port. In both scenarios, the output power of a USB-C charger or the USB-C port on a dock or display should be at least 20 V and 2.25 A in order to provide power to your computer. -
Page 29: Change Settings In Uefi/Bios Setup Utility
Ctrl key. For example, you can press either Ctrl + A or Fn + A to select all text in a text editing application. Enable or disable always-on For some Lenovo computers with always-on connectors, the always-on function can be enabled or disabled in the UEFI/BIOS setup utility. -
Page 30: Password Types
Attention: If you forget the administrator password, a Lenovo authorized service personnel cannot reset your password. You must take your computer to a Lenovo authorized service personnel to have the system board replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 31: Set User Password
Lenovo authorized service personnel cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized service personnel to have the hard disk drive replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 32: Reset Or Restore Windows
Step 2. Select Security. Step 3. Change or remove the hard disk password. To change or remove master password, select Change Master Password and press Enter. Note: If you remove the master hard disk password, the user hard disk password is also removed. To change user password, select Change User Password and press Enter. -
Page 33: Reset Windows
Step 1. In the Windows 10 search box, enter Create a restore point and select the matched result. Step 2. Select the System Protection tab and then select Create. Note: System protection must be turned on for the system drive (typically with drive letter C) before you can create restore points. - Page 34 Note: For computers without a USB Type-A connector, you may need to purchase and use an adapter (USB Type-C to Type-A) to use a recovery drive. Step 2. On the Choose an option screen, select Troubleshoot. Step 3. Choose a recovery option. Select Advanced Options ➙...
-
Page 35: Chapter 4. Help And Support
How to access? Use Lenovo Vantage or Lenovo PC Manager to: • Download and install the latest drivers and firmware. • Open the Start menu and select Lenovo Vantage or • Configure hardware settings PC Manager. • Diagnose computer hardware problems. -
Page 36: What Is A Cru
If you intend to install a CRU, Lenovo will ship the CRU to you. You might be required to return the defective part that is replaced by the CRU. When return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU;... -
Page 37: Call Lenovo
Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Record product information and problem details before you contact Lenovo. Product information Problem symptoms and details •... -
Page 38: Purchase Additional Services
Purchase additional services During and after the warranty period, you can purchase additional services from Lenovo at https:// pcsupport.lenovo.com/warrantyupgrade Service availability and service name might vary by country or region. User Guide... -
Page 39: Appendix A. Accessibility And Ergonomic Information
This chapter provides information about accessibility and ergonomics. Accessibility information Lenovo is committed to providing users who have hearing, vision, and mobility limitations with greater access to information and technology. This section provides information about the ways these users can get the most out of their computer experience. - Page 40 keyboard with all the standard keys. You can select keys using the mouse or another pointing device, or you can tap to select the keys if your computer supports multi-touch screen. • High Contrast High Contrast is a feature that heightens the color contrast of some text and images on your screen. As a result, those items are more distinct and easier to identify.
- Page 41 Your computer provides industry-standard connectors that enable you to connect assistive devices. Documentation in accessible formats Lenovo provides electronic documentation in accessible formats, such as properly tagged PDF files or HyperText Markup Language (HTML) files. Lenovo electronic documentation is developed to ensure that visually impaired users can read the documentation through a screen reader.
- Page 42 Many product solutions are available to help you modify and expand your computer to best suit your needs. You can find some of these options at https://www.lenovo.com/accessories Explore your options for docking solutions and external products that provide the adjustability and features that you want.
- Page 43 Note: Selected Lenovo computers are low blue-light certified. These computers are tested with night light turned on and color temperature set to the default value of 48. Avoid constant body contact with specific hot sections CAUTION: When the computer is operating, it should be placed on a hard and flat surface with its bottom area not in contact with user’s bare skin.
- Page 44 User Guide...
-
Page 45: Appendix B. Compliance Information
• Consult an authorized dealer or service representative for help. Lenovo is not responsible for any radio or television interference caused by using cables and connectors other than those recommended by Lenovo or by unauthorized changes or modifications to this equipment. - Page 46 Location for the FCC ID and IC ID If you purchased your computer in the United States or Canada and the computer includes factory- preinstalled wireless modules, a piece of text containing identification strings for these modules (FCC ID and IC ID) is visible on the computer’s bottom cover.
-
Page 47: Appendix C. Notices And Trademarks
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. - Page 48 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
