This operation manual is dedicated to the end user of the unit and it contains a brief description of all free access
functions of the unit control.
1

USER INTERFACE

The user interface is a LCD display with 4 rows, 20 columns and automatic backlight; the display has 6 function keys,
that are used to navigate the software menu and to set the parameters.
The key functions are described in the following.
This key, called "up arrow"
field, increasing it.
This key, called "down arrow"
mask field, decreasing it.
This key, called "Enter"
parameter that has been modified.
This key, called "alarm", allows to display active alarms and, in case, to reset them.
This key, called "prg"
This key, called "esc"
level.
Original instructions
Installation manual
4
, allows to scroll up the masks and to modify the value of each mask
, allows to scroll up the masks and to modify the value of each
, confirms the selection done to access the menu branches and stores a
, allows to enter the software menu.
, allows to exit the displayed mask and to go back to the previous menu
We reserve the right to make changes without any prior notice.
UATYQ*Y1
Packaged Rooftop
4P522681-1B
