Features:
• Up to 320GB in a tiny enclosure
• 7,200 and 5,400 RPM models available
• Seagate SATA II drives used exclusively
• Weighs less than 10 Ounces
• Tested and approved with Digidesign
Pro Tools™ to support over 55 tracks of
24bit / 48k audio, with edits
• Small, portable, aluminum case
• Runs quietly with fanless design
• Applications: Field recording,
storing and exchanging A/V,
graphics, prepress, and desktop
publishing files.
• Includes universal power supply
• Included carrying case
www.glyphtech.com
800-335-0345
Tiny. Bus Powered. Go.
The PortaGig hard drive makes portable recording and ed-
iting easy. With its tiny bus-powered enclosure, it's small
enough to fit into a pocket, and powerful enough to support
high track-count audio sessions. With FireWire 800 and USB
2.0 interfaces, PortaGig 800 is compatible with Mac, Windows
and Linux systems supporting FireWire or USB. Designed with
a fanless, light aluminum enclosure, it allows you to work on
the road easily and reliably. If bus power is not available or is
insufficient, you can use the included power supply.
Specs:
• Capacity (7,200 RPM): 160GB, 250GB, 320GB
• Capacity (5,400 RPM): 160GB, 250GB, 320GB
• Interfaces: (2) FireWire 800 and (1) USB 2.0
• Bridging Chip: Oxford 934
• Average seek time (read): 8 msec
• Max Transfer rate (FireWire 800): 800 Mb/sec (100 MB/sec)
• Sustained transfer rate: up to 44 MB/sec
• Buffer size: 8MB
• Dimensions (HxWxD): .86" x 3.3" x 5.2" inches
• Weight: 0.6 lbs. / 0.3 kg
• Power supply: universal auto switching 100-240V
• Requirements: Mac OS 8.6/9.x/10.x, Windows 2000/XP/Vista
• Format: HFS+, can be formatted for other OS
• Approvals: CE
• Warranty: 3 Years, 1 Year Overnight Advance Replacement
• Includes: FireWire 800 (9pin to 9pin) cable, USB cable, sleeve,
power supply. Manual is downloadable from Glyph web site.
810050-1.2 PortaGig 800 Datasheet
July 31, 2008
