Glyph GT103800-1000 Specifications

FIREWIRE 800 FIREWIRE 800
Features:
Capacity of 3TB with 1TB drives
•
• Sustain data rates of 80 MB/sec with
FireWire (IEEE 1394b)
• FireWire connectivity is hot pluggable
and allows 63 devices daisy chained
• Fast 7,200 RPM, ATA/100 Seagate
drives with up to an 8MB cache
• Scratch resistant black powder-coated
aluminum chassis offers excellent heat
transfer properties
• FireWire 400 Port accessible on the
front panel
• Dual internal 70w power supplies, and
dual whisper quiet fans
• Comes complete with Glyph's 24-hour
advance replacement warranty along
with outstanding technical support at
no additional charge.
810031-2.0 GT 103 FW800.pdf
© Glyph Technologies, a division of Ithaca Technologies, LLC
November 30, 2007
Custom Configure Three Drives in a Single Space
Rack with the GT 103 FW800.
Specifically designed for applications requiring multiple drives, the GT 103
FW800 can be configured with three FireWire hot-swap GT Key FW800 drives
of any capacity. Using Integrity™, Glyph's proprietary hot-swap technology, you
can easily shuttle content to other GT Series enclosures with the 7,200 RPM GT
Key. Integrity™ is an advanced FireWire hot-swap interface that provides
greater reliability than existing hybrid ATA-to-FireWire products. Older
FireWire 400 GT Keys are forward-compatible with the FireWire 800 GT 103,
and FireWire 800 GT Keys are backward-compatible with all GT Series FireWire
400 enclosures. Glyph's GT 103 FW800 comes standard with a three-year
warranty, while GT Keys carry an additional overnight advance replacement
warranty in the first year.
GT 103 FW800 Specifications
• Interface: Two IEEE 1394b (FireWire 800) connectors, one FW400 port on front
• Dimensions: H 1.7" x W 19" x D 16"
• Power supply: Universal 100-240v, 50-60 Hz
• Weight (lbs/kg): 16 lbs/7 kg (fully loaded), 11.5 lbs/5.2 kg (empty)
• Compatibility: Mac OS 10.x, Windows 98SE/2000/ME/XP, Linux
• Includes: 2 meter FireWire 800 cable, power cable, rack screws, downloadable manual
• Warranty: 3 years
GT Key FW800 Specifications
• Capacity: 80, 160, 250, 320, 400, 500, 750GB, 1TB
• Rotational speed: 7,200 RPM
• Bridging: Oxford 924 chip on Glyph's own bridge board
• Buffer size (cache): 8MB (160GB - 250GB), 16MB (320 - 750GB), 32MB (1TB)
• Average seek time (read): 8 msec
• Max external transfer rate: 800 Mb/sec (80 MB/sec)
• Dimensions: H 1.1" x W 4.6" x D 9.4"
• Weight (lbs/kg): 2.9 lbs / 1.3 kg
• Power supply: Gets power from enclosure
• Operating Temperature (C/F): 41 - 122/5 - 50
• Warranty: 3 years, Overnight advance replacement warranty in the first year
800.335.0345
glyphtech.com
