Sony XPERIA G8232 Startup Manual

Device basics
1 2
3
4
5
6
7
1 Charging/Notification light
2 NFC
3 Nano SIM/Memory card slot
4 Power key/Fingerprint sensor
5 Volume/Zoom key
6 Camera key
7 Charger/USB Type-C™ cable port
In addition to using a single SIM card, the combined
SIM/Memory card holder allows you to use either an
additional SIM card or a memory card. It is not possible
to use two SIM cards and a memory card at the same
time.
To insert one nano SIM card and one
memory card
1
Do not cut your SIM cards, for example using a blade or
scissors, as this may damage your device.
1
Using your fingernail, drag out the SIM/Memory card
tray.
2
Firmly place the SIM card in the correct orientation in
position (1) as shown in the illustration.
3
Firmly place the memory card in the correct orientation in
position (2) as shown in the illustration.
4
Gently push the tray back into the slot until it fits into
place.
2
January 13, 2017 16:59:40
To insert one or two nano SIM cards
1
1
Using your fingernail, drag out the SIM/Memory card tray.
2
Firmly place the primary SIM card (SIM 1) in the correct
orientation in position (1) as shown in the illustration.
3
Firmly place the additional SIM card (SIM 2) in the correct
orientation in position (2) as shown in the illustration.
4
Gently push the tray back into the slot until it fits into place.
To turn on the device
It is important to use the USB Type-C™ cable (provided)
when charging your device as other types of USB cables
can damage your device. It is recommended to charge the
battery for at least 30 minutes before you turn on the
device for the first time.
1
Press and hold down the power key
vibrates.
2
Wait a moment for the device to start.
To activate the screen
•
Briefly press the power key
Screen protection
Before using your device, remove the protection film by
pulling up on the protruding tab.
It is recommended to protect your device with a Sony
branded screen cover or a protector intended for your
Xperia™ model. The use of third party screen protection
accessories may prevent your device from working correctly
by covering sensors, lenses, speakers, or microphones and
can invalidate the warranty.
Support for you
Access our support website directly on your device or visit
support.sonymobile.com with any supported browser.
Support options include User guides, downloadable content,
troubleshooting tips and contact information.
Even if you don't have a network connection, you can
access support contact information on your device.
Depending on the country or region where you purchased
your device, you can find this information directly in the
Support application.
To access the Support application
1
From your Home screen, tap
2
Find and tap .
Connect to the internet when using the Support
application for the best available support.
2
until the device
.
.
