- Page 1 OPERATION MANUAL DAIKIN ROOM AIR CONDITIONER MODELS FTXM50UVMZ FTXM60UVMZ FTXM71UVMZ...
- Page 2 Features Enhanced comfort and energy savings INTELLIGENT EYE The INTELLIGENT EYE sensor detects human movement in a room. If no one is in the room for more than 20 minutes, the operation automatically changes to energy saving operation. Page 15 WEEKLY TIMER Up to 4 timer settings can be saved for each day of the week according to your family’s life style. The WEEKLY TIMER allows you to set on/off times and the desired temperature. Page 22 Other functions COMFORT AIRFLOW OUTDOOR UNIT QUIET The airfl ow direction is upward while in OUTDOOR UNIT QUIET operation COOL operation, and downward while assures a low noise level of the in HEAT operation. This function outdoor unit. This function is useful prevents cold or warm air from blowing to maintain a quiet neighbourhood. directly on your body. Page 14 Page 18...
-
Page 3: Table Of Contents
Contents Read Before Operation Safety Precautions .......... Names of Parts ..........Preparation Before Operation ......Basic Operation AUTO · DRY · COOL · HEAT · FAN Operation ........Adjusting the Airflow Rate ....Adjusting the Airflow Direction ... Useful Functions COMFORT AIRFLOW Operation ..INTELLIGENT EYE Operation ... POWERFUL Operation ...... ECONO / OUTDOOR UNIT QUIET Operation ........... TIMER Operation ON/OFF TIMER Operation ....WEEKLY TIMER Operation ....Care Care and Cleaning . -
Page 4: Read Before Operation
Read Before Operation Safety Precautions Read the precautions in this manual carefully This appliance is filled with R32. before operating the unit. • Keep this manual where the user can easily find it. • The precautions described herein are classified as WARNING and CAUTION. They both contain important information regarding safety. Be sure to observe all precautions without fail. WARNING Failure to follow these instructions properly may result in personal injury or loss of life. Failure to observe these instructions properly may result in property damage or personal injury, CAUTION which may be serious depending on the circumstances. Be sure to follow the Be sure to establish an earth Never attempt. instructions. connection. • After reading, keep this manual in a convenient place so that you can refer to it whenever necessary. If the equipment is transferred to a new user, be sure also to hand over the manual. WARNING • Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. • The appliance must be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater). - Page 5 Read Before Operation • Do not sit on the outdoor unit, put things on the unit, or pull the unit. Doing so may cause accidents, such as falling or toppling down, thus resulting in injury, product malfunctioning, or product damage. • Do not place objects that are susceptible to moisture directly beneath the indoor or outdoor units. Under certain conditions, condensation on the main unit or refrigerant pipes, air filter dirt or drain blockage may cause dripping, resulting in fouling or failure of the object concerned. • After prolonged use, check the unit stand and its mounts for damage. If they are left in a damaged condition, the unit may fall and cause injury. • To avoid injury, do not touch the air inlet or aluminium fins of the indoor or outdoor units. • The appliance is not intended for use by unattended young children or infirm persons. Impairment of bodily functions and harm to health may result. • Children should be supervised to ensure that they do not play with the unit or its remote controller. Accidental operation by a child may result in impairment of bodily functions and harm health. • Avoid impacts to the indoor and outdoor units, or otherwise product damage may result. • Do not place flammable items, such as spray cans, within 1m of the air outlet. The spray cans may explode as a result of hot air from the indoor or outdoor units. • Be careful not to let pets urinate on the air conditioner. Urination on the air conditioner may result in electric shock or fire. • Do not wash the air conditioner with water, as this may result in electric shock or fire. • Do not place water containers (vases, etc.) above the unit, as this may result in electric shock or fire hazards if they should topple over. • Do not insert the batteries in the wrong polarity (+/-) orientation as this may result in short circuiting, fire, or battery leakage. • Do not sit or hang on the panel. The panel may fall, and injury or product malfunctioning may result. • Do not sway the panel. The panel may hit people or objects, and injury or property damage may result. • Do not let children play around the panel. Injury or property damage may result. • Do not pull the wires. The wires may be broken and the panel may fall, and injury or property damage may result.
-
Page 6: Names Of Parts
Read Before Operation Names of Parts Indoor Unit Front panel Air inlet INTELLIGENT EYE sensor Air outlet Flaps (horizontal blades) • Detects the movements of people and automatically switches Page 13 Model name between normal operation and energy saving operation. Louvres (vertical blades) Page 15,16 Room temperature sensor • The louvres are inside of the • Detects the air temperature around air outlet. Page 13 the unit. - Page 7 Read Before Operation „ Open the front panel Air fi lter Titanium apatite deodorizing fi lter Outdoor Unit Air inlet Outdoor temperature sensor (back) (back and side) Refrigerant pipes and inter-unit wire Earth terminal (inside) Air outlet Drain hose...
- Page 8 Read Before Operation Names of Parts Remote Controller Signal transmitter Display (LCD) Receiver • Displays the current settings. (In this illustration, each section is shown with all its displays on for the • To use the remote controller, aim the purpose of explanation.) transmitter at the indoor unit. If there is anything blocking the signals between the unit and the remote controller, such as a curtain, the unit may not operate. • The maximum transmission distance is TEMPERATURE about 7m. adjustment button • Changes the temperature setting. Page 11 FAN setting button • Selects the airfl ow rate setting. Page 12 ON/OFF button • Press this button once to start operation.
- Page 9 Read Before Operation „ Open the front cover MODE selector button • Selects the operation mode. (AUTO/DRY/COOL/HEAT/FAN) Page 11 ECONO/QUIET button • ECONO/OUTDOOR UNIT QUIET operation. Page 18 SENSOR button • INTELLIGENT EYE operation. SWING button Page 15 • Adjusts the airfl ow direction. Page 13 COMFORT button • COMFORT AIRFLOW operation. Page 14 : WEEKLY button : PROGRAMME button OFF TIMER button (NIGHT SET mode)
-
Page 10: Preparation Before Operation
Read Before Operation Preparation Before Operation CAUTION Incorrect handling of batteries can result in injury from battery leakage, rupturing or heating, or lead to equipment failure. Please observe the following precautions and use safely. • If the alkaline solution from the batteries should get in the eyes, do not rub the eyes. Instead, immediately flush the eyes with tap water and seek the attention of a medical professional. • Keep batteries out of reach of children. In the event that batteries are swallowed, seek the immediate attention of a medical professional. • Do not expose batteries to heat or fire. Do not disassemble or modify batteries. The insulation or gas release vent inside the battery may be damaged, resulting in battery leakage, rupturing, or heating. - Page 11 Read Before Operation „ To set the clock Press “ ” appears on the LCD. “ ” and “ ” blink. Press to set the current day of the week. Press “ ” blinks. Press to set the clock to the present time. • Holding down or rapidly increases or decreases the displayed time. Press • Point the remote controller at the indoor unit when pressing the buttons. “ ...
-
Page 12: Basic Operation
Basic Operation AUTO · DRY · COOL · HEAT · FAN Operation The air conditioner operates with the operation mode of your choice. From the next time on, the air conditioner will operate with the same operation mode. „ To start Press and select an operation mode. • Each pressing of the button changes the mode setting in sequence. AUTO COOL HEAT Press • “ ” appears on the LCD. • The OPERATION lamp lights green. Display „ To stop Press again. • “ ” disappears from the LCD. • The OPERATION lamp goes off. „... -
Page 13: Adjusting The Airflow Rate
Basic Operation Adjusting the Airfl ow Rate You can adjust the airfl ow rate to increase your comfort. „ To adjust the airfl ow rate setting Press • Each pressing of changes the airfl ow rate setting in sequence. AUTO Indoor unit quiet Airflow rate 1-5 (Low to High) • When the airfl ow is set to “ ”, quiet operation starts and noise from the indoor unit will become quieter. • In the quiet operation mode, the airfl ow rate is set to a weak level. • In DRY operation, the airfl ow rate setting cannot be changed. -
Page 14: Adjusting The Airflow Direction
Basic Operation Adjusting the Airfl ow Direction You can adjust the airfl ow direction to increase your comfort. CAUTION • Always use a remote controller to adjust the angles of the fl aps and louvres. − I f you attempt to move the fl aps and louvres forcibly by hand when they are swinging, the mechanism may be damaged. − Inside the air outlet, a fan is rotating at a high speed. „ To start auto swing Up and down airfl ow direction Press • “ ” appears on the LCD. • The fl aps (horizontal blades) will begin to swing. Right and left airfl ow direction Press • “ ... -
Page 15: Useful Functions
Useful Functions COMFORT AIRFLOW Operation The fl ow of air will be in the upward direction while in COOL operation and in the downward direction while in HEAT operation, which will provide a comfortable wind that will not come in direct contact with people. COOL operation HEAT operation „ To start Comfort Comfort Press • “ ” appears on the LCD. COOL and DRY HEAT operation FAN ONLY operation operation Flaps direction Goes up Goes down Not available Airfl ow rate AUTO „... -
Page 16: Intelligent Eye Operation
Useful Functions INTELLIGENT EYE Operation The INTELLIGENT EYE operation detects human movement. If no one is detected in the room for more than 20 minutes, the unit automatically enters energy saving operation. CAUTION • Do not place large objects near the INTELLIGENT EYE sensor. Also keep heating units and humidifi ers outside the sensor’s detection area. This sensor can detect undesirable objects. • Do not hit or violently push the INTELLIGENT EYE sensor. This can lead to damage and malfunction. „ To start Sensor Press and select the desired model. Sensor Sensor • Each time “ ” is pressed, a different setting option is displayed on the LCD. • The INTELLIGENT EYE lamp lights green. Display blank Intelligent eye No Setting • The lamp lights when human movement is detected. „ To cancel Sensor Press button. - Page 17 Useful Functions INTELLIGENT EYE operation is useful for energy saving „ People are detected in the sensing area. „ No people are detected in the sensing area. The air conditioner is in normal operation while the The air conditioner will switch to energy-saving mode after sensor is detecting human movement. 20 minutes. Energy saving operation • If no presence detected in the room for 20 minutes, the energy saving operation will start, and the INTELLIGENT EYE lamp goes off. If human movement is detected again, the INTELLIGENT EYE lamp lights up and energy saving operation terminates. • This operation changes the temperature by –2°C in HEAT / +2°C in COOL / +2°C in DRY operation from the set temperature. When the room temperature exceeds 30°C, the operation changes the temperature by +1°C in COOL / +1°C in DRY operation from the set temperature.
-
Page 18: Powerful Operation
Useful Functions POWERFUL Operation POWERFUL operation quickly maximises the cooling (heating) effect in any operation mode. In this mode, the air conditioner operates at maximum capacity. „ To start Press during operation. • “ ” appears on the LCD. • POWERFUL operation ends in 20 minutes. Then the system automatically operates again with the previous settings which were used before POWERFUL operation. „ To cancel Press again. • “ ” disappears from the LCD. NOTE Notes on POWERFUL operation • Pressing causes the settings to be cancelled, and “ ” disappears from the LCD. • POWERFUL operation will not increase the capacity of the air conditioner if the air conditioner is already in operation with its maximum capacity demonstrated. − In COOL, HEAT and AUTO operation To maximise the cooling (heating) effect, the capacity of outdoor unit increases and the airfl ow rate becomes fi xed at the maximum setting. -
Page 19: Econo / Outdoor Unit Quiet Operation
Useful Functions ECONO / OUTDOOR UNIT QUIET Operation ECONO operation enables effi cient operation by limiting the maximum power consumption. This function is useful to prevent the circuit breaker from tripping when the unit operates alongside other appliances on the same circuit. OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit by changing the frequency and fan speed of the outdoor unit. This function is convenient during the night-time operation. „ To start Press and select the desired mode. • Each time is pressed, a different setting option appears on the LCD. blank ECONO OUTDOOR UNIT Combination No Setting QUIET „ To cancel Press until no icon is displayed. NOTE Notes on ECONO operation • This operation is performed with lower power and therefore may not provide a suffi cient cooling (heating) effect. -
Page 20: Timer Operation
TIMER Operation ON/OFF TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off at night or in the morning. You can also use the ON TIMER and OFF TIMER together. [ON TIMER with a 24 hour clock display] (24 HOUR ON/OFF TIMER) „ To set • Check that the clock is correct. If not, set the clock to the present time. Page 10 Press “ ” appears on the LCD. “ ” blinks. • “ ” and day of the week disappear from the LCD. Press until the time setting reaches the point you like. - Page 21 TIMER Operation [OFF TIMER with a 24 hour clock display] (24 HOUR ON/OFF TIMER) „ To set • Check that the clock is correct. If not, set the clock to the present time. Page 10 Press “ ” appears on the LCD. “ ” blinks. • “ ” and day of the week disappear from the LCD. Press until the time setting reaches the point you like. • Each pressing of either button increases or decreases the time setting by 10 minutes. Holding down either button changes the time setting rapidly. Press again.
- Page 22 TIMER Operation ON/OFF TIMER Operation [ON/OFF TIMER with an hours remaining display] (COUNT UP-DOWN ON/OFF TIMER) • Check that the clock is correct. If not, set the clock to the present time. Page 10 Press and hold for about 5 seconds, when signal indicater ( ) blink, release your fi nger from the button. For ON TIMER “ ...
-
Page 23: Weekly Timer Operation
TIMER Operation WEEKLY TIMER Operation Up to 4 timer settings can be saved for each day of the week. This is convenient to adapt the WEEKLY TIMER to your family’s life style. „ Setting example of the WEEKLY TIMER The same timer settings are used from Monday through Friday, while different timer settings are used for the weekend. [Monday] Make timer settings for programmes 1-4. Page 23 Programme 1 Programme 2 Programme 3 Programme 4 25.0°C 27.0°C 6:00 8:30 17:30 22:00 [Tuesday] Use the copy mode to make settings for Tuesday to Friday, because these settings are the same as those for Monday. Page 25 [Friday] Programme 1 Programme 2 Programme 3 Programme 4... - Page 24 TIMER Operation WEEKLY TIMER Operation „ To use WEEKLY TIMER operation Setting mode • Make sure the day of the week and time are set. If not, set the day of the week and time. Page 10 Programme 1 Programme 2 Programme 3 Programme 4 [Monday] 25.0°C 27.0°C 6:00 8:30 17:30 22:00 Setting Displays Day and number ON/OFF Time Temperature Press • The day of the week and the reservation number of the current day will be displayed. • 1 to 4 settings can be made per day.
- Page 25 TIMER Operation Press to select the desired time. • The time can be set between 0:00 and 23:50 in 10-minute intervals. • To return to the ON/OFF TIMER mode setting, press • Proceed to STEP when setting the OFF TIMER. Press • The time will be set. • “ ” and the temperature blink. Press to select the desired temperature. • The temperature can be set between 10.0°C and 32.0°C. Page 11 COOL or AUTO: The unit operates at 18.0°C even if it is set to 10.0°C to 17.0°C. HEAT or AUTO : The unit operates at 30.0°C even if it is set to 31.0°C to 32.0°C. Page 11 • To return to the time setting, press • The set temperature is only displayed when the mode setting is on. Press • The temperature will be set and go to the next reservation setting. • The temperature is set while in ON TIMER operation, and the time is set while in OFF TIMER operation. • The next reservation screen will appear. • To continue further settings, repeat the procedure from STEP Press to complete the setting. • Be sure to direct the remote controller toward the indoor unit and check for a receiving tone and blinking of the OPERATION lamp.
- Page 26 TIMER Operation WEEKLY TIMER Operation Copy mode • A reservation made once can be copied to another day of the week. The whole reservation of the selected day of the week will be copied. Programme 1 Programme 2 Programme 3 Programme 4 [Monday] 25.0°C 27.0°C 6:00 8:30 17:30 22:00 COPY Programme 1 Programme 2 Programme 3 Programme 4 [Tuesday] 25.0°C 27.0°C [Friday] 6:00 8:30 17:30 22:00 Setting Displays Confi rmation...
- Page 27 TIMER Operation „ Confi rming a reservation • The reservation can be confi rmed. Setting Displays Normal Confi rmation Press • The day of the week and the reservation number of the current day will be displayed. Press to select the day of the week and the reservation number to be confi rmed. • Pressing displays the reservation details. • To change the confi rmed reserved settings, select the reservation number and press The mode is switched to setting mode. Proceed to Setting mode STEP Page 23 Press to exit the confi rmation mode.
- Page 28 TIMER Operation WEEKLY TIMER Operation „ To delete a reservation An individual reservation Press • The day of the week and the reservation number will be displayed. Press to select the day of the week and the reservation number to be deleted. Press • “ ” and “ ” or “ ” blink. Press until no icon is displayed. • Pressing changes the ON/OFF TIMER mode in sequence.
-
Page 29: Care
Care Care and Cleaning CAUTION • Before cleaning, be sure to stop the operation and turn off the circuit breaker. • Do not touch the aluminum fi ns of the indoor unit. If you touch those parts, this may cause an injury. „ Quick reference Cleaning parts Front panel • Wipe it with a soft damp cloth. • Only neutral detergent may be used. If dirty Air fi lter • Vacuum dust or wash the fi lter. Once every 2 weeks Page 29 Titanium apatite deodorizing fi lter (included with the air conditioner) and dust collection fi lter (PM2.5) (sold separately) To purchase, contact the dealer where you bought the air conditioner. - Page 30 Care Care and Cleaning „ Air fi lter Open the front panel. Wash the air fi lters with water or clean them with • Hold the front panel by the sides and open it. vacuum cleaner. • It is recommended to clean the air fi lters every 2 weeks. Pull out the air fi lters. • Push the fi lter tab at the centre of each air fi lter a little upwards, then pull it down.
- Page 31 Care „ Titanium apatite deodorizing filter (included with the air conditioner) / dust collection filter (PM2.5) (sold separately) Attaching Clean or replace the titanium apatite deodorizing filters or Open the front panel and dust collection filters (PM2.5). pull out the air filters. Page 29 [Cleaning for titanium apatite Insert the titanium apatite...
- Page 32 Care Care and Cleaning „ Prior to a long period of non-use Operate the FAN mode for several hours on a fine day to dry out the inside. 1) Press and select “ ” . 2) Press and start the operation. After operation stops, turn off the circuit breaker for the room air conditioner.
-
Page 33: When The Need Arises
When the Need Arises Indoor unit The flaps do not start swinging immediately. • T he air conditioner is adjusting the position of the flaps. The flaps will start moving soon. The air conditioner stops generating Different sounds are heard. airflow during HEAT operation. „ A sound like flowing water • T his sound is generated because the refrigerant in • O nce the set temperature is reached, the airflow rate is the air conditioner is flowing. -
Page 34: Troubleshooting
When the Need Arises Troubleshooting Before making an inquiry or a request for repair, please check the following. If the problem persists, consult your dealer. Not a problem Check This case is not a problem. Please check again before requesting repairs. The air conditioner does not operate Case Description / what to check • Has the circuit breaker been tripped or the fuse blown? OPERATION lamp is off. • Is there a power failure? • Are batteries set in the remote controller? • Turn off the power with the circuit breaker and restart operation with the remote controller. If the OPERATION lamp is still blinking, check the error code and consult your dealer. OPERATION lamp is blinking. Page 36 The air conditioner suddenly stops operating Case... - Page 35 When the Need Arises Mist comes out Case Description / what to check • This happens when the air in the room is cooled into mist by the cold airfl ow during COOL Mist comes out of the indoor unit. or other operation. Remote controller Case Description / what to check • The batteries may be exhausted. Replace both batteries with new dry batteries AAA.LR03 (alkaline). For details, refer to “Preparation Before Operation”. Page 9 The unit does not receive signals from the remote controller or has • Signal communication may be disabled if an electronic-starter-type fl uorescent lamp (such...
- Page 36 When the Need Arises Troubleshooting „ Call your dealer immediately WARNING When an abnormality (such as a burning smell) occurs, stop operation and turn off the circuit breaker. • Continued operation in an abnormal condition may result in problems, electric shock or fire. • Consult the dealer where you bought the air conditioner. Do not attempt to repair or modify the air conditioner by yourself. • Incorrect work may result in electric shock or fire.
- Page 37 When the Need Arises „ Fault diagnosis by remote controller • In case the air conditioner is malfunctioning, you can check the error code via the remote controller before consulting with service personnel and informing them of the malfunction code. When is held down for about 5 seconds, “ ” blinks in the temperature display section. Press repeatedly until a long beep is produced. • The code indication changes as shown below, and notifi es you with a long beep. CODE MEANING NORMAL...
- Page 38 MEMO...
- Page 40 Quick Reference On/Off Temp Mode Swing MODE The two-dimensional bar code is a manufacturing code. 3P552666-6B M19N036 (1905) HT...
