TM
G-MAX
N203 User's Manual
Copyright ©2004
All Right Reserved – Printed in Taiwan
Notebook Computer
N203
User's Manual
Original Issue: 2004/07
This manual guides you in setting up and using your new notebook computer
G-MAX N203. Information in the manual has been carefully checked for
accuracy and is subject to change without notice.
No part of this manual may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical, photocopy,
recording, or otherwise, without prior written consent.
Trademarks
Product names used herein are for identification purposes only and may be the
trademarks of their respective companies.
Microsoft®, MS-DOS, Windows ®, and Windows ® Sound System are
trademarks of Microsoft Corporation.
Intel®, Centrino™, Pentium ® M, Banias, Calexico are registered trademarks
of Intel Corporation.
Sound Blaster, Sound Blaster Pro are trademarks of Creative Technology.
All other brands or product names mentioned in this manual are trademarks or
registered trademarks of their respective companies.
I

Advertisement

Table of Contents
loading

Related Manuals for Gigabyte G-MAX N203

Summary of Contents for Gigabyte G-MAX N203

  • Page 1 Original Issue: 2004/07 This manual guides you in setting up and using your new notebook computer G-MAX N203. Information in the manual has been carefully checked for accuracy and is subject to change without notice. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopy, recording, or otherwise, without prior written consent.

  • Page 2: Safety Instructions

    Safety Instructions Use the following safety guidelines to help protect yourself and your notebook. When Using Your notebook computer G-MAX N203 CAUTION: Do not operate your portable computer for an extended period of time with the base resting directly on your body. With extended operation, heat can potentially build up in the base.
  • Page 3 ready to install the drive in your notebook. Your can put the hard drive through an X-ray security machine, but never put the drive through a metal detector. When traveling, do not place your notebook in overhead storage compartments where it could slide around.

  • Page 4: Regulatory Notices

    G-MAX N203 User’s Manual Regulatory Notices Federal Communications Commission Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 5 (RF) interference, in which case the user may be required to take adequate measures. This notebook computer G-MAX N203 device is classified for use in a typical Class B domestic environment. A "Declaration of Conformity" in accordance with the preceding directives and standards has been made and is on file at Gigabyte Computer Corporation.
  • Page 6 G-MAX N203 User’s Manual This notebook computer G-MAX N203 device is classified for use in a typical Class B domestic environment. U.K. Modem Compliance Information This modem is approved by the secretary of state at the Department of Trade and Industry for...
  • Page 7 G-MAX N203 User’s Manual Macrovision License of Notice This product incorporates copyright protection technology that is protected by methods and claims of certain U.S. patents and other intellectual rights owned by Macrovision Corporation, and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation and is intended for home and other limited viewing uses only unless authorized by Macrovision Corporation.
  • Page 8 G-MAX N203 User’s Manual VIII...

  • Page 9: About Your Notebook Computer

    G-MAX N203. Your notebook computer G-MAX N203 incorporates the strongest features, which integrate the latest technologies available in the notebook industry. Your new notebook computer G-MAX N203 not only drives today multimedia applications but also be ready for tomorrow exciting new software. This Professional Multimedia...
  • Page 10 G-MAX N203 User’s Manual...
  • Page 11 Notebook Computer G-MAX N203 User’s Manual. This manual covers everything you need to know in learning how to use your notebook computer G-MAX N203. This manual also assumes that you know the basic concepts of Windows and the PC. You will start doing a lot of great and fun things with your notebook computer G-MAX N203.

  • Page 12: Table Of Contents

    Unpacking & Packing List…………………………….. 1.1 Feature Highlight…………………………………………………………….. 1.2 Unpacking Your Notebook Computer G-MAX N203………… 1.3 The Inside of Your Notebook Computer G-MAX N203……… Power/Status LED Icons…………………………………………………… The Function of Quick Access Buttons……………………………… 1.4 The Outside of Your Notebook Computer G-MAX N203……...
  • Page 13 6.1 Memory Upgrade Procedures…………………………………………… Installing Memory Module………………………………………………… 6.2 Upgrade Hard Disk…………………………………………………………… Care and Maintenance…………………………………. 7.1 Taking Care of Your Notebook Computer G-MAX N203……. Taking Care of Your AC Adapter……………………………………….. Taking Care of Your Battery Pack...….……………………………… 7.2 Clean and Serving……………………………………………………………. 7.3 Maintaining the LCD Quality……………………………………………..
  • Page 14 G-MAX N203 User’s Manual System Memory……………………………………………………………….. LCD Display………………………………………………………………………. VGA System……………………………………………………………………… Disk Drives………………………………………………………………………. Audio System…………………………………………………………………… PC Cards………………………………………………………………………….. Glide Pad…………………………………………………………………………… Keyboard…………………………………………………………………….…… Flash BIOS………………………………………………………………………… I/O Ports………………………………………………………………………… Wireless Devices………………………………………………………………. AC/DC Power Supply Adapter…………………………………………… Battery……………………………………………………………………………… Weight and Dimension……………………………………………………… Appendix B Service Centers…………………………….. Service Centers List……………………………………..

  • Page 15: Unpacking & Packing List

    G-MAX N203 User’s Manual 1 Unpacking & Packing List our notebook computer G-MAX N203 is a fully Windows compatible portable personal computer. With the these latest features in mobile computing and multimedia technology, your notebook computer G-MAX N203 makes a natural entertainment companion.

  • Page 16: Feature Highlight

    1.1 Feature Highlight Before we go to identify each part of your notebook computer G-MAX N203, we will first introduce you to other notable features of your notebook computer G-MAX N203. Notebook computer G-MAX N203 uses the platform with certified Intel®...

  • Page 17: Flash Bios

    USB 2.0 Provides three USB 2.0 ports for fastest I/O data transmission. AGP Local Bus Architecture AGP 4X video local bus and 3D Graphic Engine with shared 8/16/32MB VRAM. Rotatable Image Screen Special control combination key can rotate the whole image direction on the screen to 90, 180, 270 degree for special occasion.

  • Page 18: Unpacking Your Notebook Computer G-Max N203

    1.2 Unpacking Your Notebook Computer G-MAX N203 Your notebook computer G-MAX N203 comes securely packaged in a sturdy cardboard shipping carton. Upon receiving your notebook computer G-MAX N203, open the carton and carefully remove the contents. In addition to this User’s Manual, the shipping carton should also contain the following items...

  • Page 19: The Inside Of Your Notebook Computer G-Max N203

    Color LCD Display ➊ Your notebook computer G-MAX N203 comes with a color LCD that you can adjust for a comfortable viewing position. The LCD can be 12.1" TFT color LCD with 1024x768 XGA (Extended Graphics Array) resolution panels. The features of the Color LCD Display are summarized as follows: TFT color LVDS with 12.1"...
  • Page 20 G-MAX N203 User’s Manual Power/Status LED Indicator ➋ Keeps you informed of your notebook computer G-MAX N203’s current power and operating status. Description of the status icons appears in the latter part of this section. ➌➏ Built-in Stereo Speakers Integrated left and right mini stereo speakers for sound and audio output for your multimedia presentations or listening pleasure.

  • Page 21: Power/Status Led Icons

    Power/Status LED Icons The Power/Status LED Panel keeps you informed of the notebook computer G-MAX N203’s current power and operating status. Each LED is marked with an icon to designate the system status. Power Indicator ➊ Wireless LAN access ➌...
  • Page 22 G-MAX N203 User’s Manual Wireless LAN access ➌ Lights in blue indicate that the wireless LAN module is installed. When lights blinking blue indicate that the system is accessing or retrieving data by wireless device. Optical Disk Drive Access ➍ When LED in blue light indicates that the system is accessing the optical disk drive.

  • Page 23: The Function Of Quick Access Buttons

    The Function of Quick Access Buttons Play/Pause Button ➊ Rewind Button ➌ Programmable Button ➎ Play/Pause Button ➊ Press the button to play or pause music. Stop Button ➋ Press the button to stop the music. Rewind Button ➌ Press the button for reverting to previous music. Press and hold this button to fast rewind the audio CD.

  • Page 24: The Outside Of Your Notebook Computer G-Max N203

    G-MAX N203 User’s Manual 1.4 The Outside of Your Notebook Computer G-MAX N203 The Front Side Cover Switch ➊ Cover Switch ➊ The cover (LCD panel) is locked when it is closed. Slide the button right aside to release the latch for opening the cover of your notebook computer G-MAX N203.
  • Page 25 The Rear Side The system ports at the back of your notebook computer G-MAX N203 can connect various devices (like a printer). Each port is described as followings. Headphone jack / SPDIF ➊ USB port ➌ Air-Outlet Vent ➎ LAN port ➐...
  • Page 26 G-MAX N203 User’s Manual TV Out Port ➍ Lets you connect to a RCA TV connector for presentation or VCD, DVD watching. Note: When you use this port, please connect Air-Outlet Vent ➎ Emits the heat out of your computer and keeps it within operating temperature. Monitor Port ➏...

  • Page 27: The Left Side

    The Left Side The left side of your notebook computer G-MAX N203 has the features shown in the following figure. DC Power Port ➊ Air inhalant ➌ PC Card slot ➎ DC Power Port ➊ Lets you connect the AC power adapter in supplying continuous power to your notebook computer G-MAX N203 and recharging the battery.

  • Page 28: The Right Side

    G-MAX N203 User’s Manual The Right Side The right side of your notebook computer G-MAX N203 offers the features shown in the following figure. Optical Disk Drive ➊ Optical Disk Drive ➊ Allows you to load and start programs from a compact disc (CD) or a digital video disc (DVD) and play conventional audio CDs.

  • Page 29: The Underside

    The Underside The bottom of the notebook computer G-MAX N203 offers the following features. Hard Disk Compartment ➊ Memory Compartment ➌ Hard Disk Compartment ➊ Open this cover of this compartment to replace with other Hard Disk Drive. Please refer to Chapter 6 for how to replace it.

  • Page 30: Your Notebook Computer G-Max N203 Accessories

    G-MAX N203 is powered on. Battery Pack Aside from the AC adapter, your notebook computer G-MAX N203 can also be powered through the internal battery pack. The battery pack uses rechargeable Lithium-Ion (Li-Ion) battery cells that provide long computing hours when fully charged and power management enabled.

  • Page 31: How To Start

    This chapter describes the installation steps you should follow to get your notebook computer G-MAX N203 up and running as quickly as possible. Contact your dealer if they have pre-installed all the needed drivers to...

  • Page 32: Using The Battery Pack

    G-MAX N203 User’s Manual Using the Battery Pack Your notebook computer G-MAX N203 is designed to operate with one of the following power sources: • With AC power using the AC adapter connected to an electrical outlet. • With a Lithium-Ion (Li-Ion) battery pack.

  • Page 33: Installing The Battery Pack

    N203 User’s Manual Installing the Battery Pack Your notebook computer G-MAX N203 provides the most convenient way to install the battery pack into your computer. To install the battery, first orient the extended nose directed toward the compartment, then following the sequence as shown in the figure below.

  • Page 34: Replacing The Battery Pack

    AC power or turning off your notebook computer G-MAX N203, or suspending to disk. If you do not do so, the notebook computer G-MAX N203 will automatically suspend to disk and turn off. The contents of the memory will store in the hard disk drive.

  • Page 35: Connecting The Ac Power Source

    2.2 Connecting the AC Power Source The AC adapter provides external power source to your notebook computer G-MAX N203 and charges the internal battery pack at the same time. The AC adapter also has an auto-switching design that can connect to any 100V AC ~ 240V AC power outlets.

  • Page 36: Starting Your Notebook Computer G-Max N203

    After a few seconds, the notebook’s display will turn on and your notebook computer G-MAX N203 will begin to execute the Power On Self Test or POST to check if all system components are running properly. Any error found during the test will be displayed on the screen and may generate short beep sound as well.

  • Page 37: Adjusting The Display Controls

    G-MAX N203 Device Drivers If you already have an operating system installed into your notebook computer G-MAX N203, it is best to install the needed device drivers for using the built-in devices of your notebook computer G-MAX N203. Before installing the drivers, check with your dealer first if they have already installed all the drivers along with the operating system.

  • Page 38: Turning Off Your Notebook Computer G-Max N203

    2.6 Turning off Your Notebook Computer G-MAX N203 If you are not going to use your notebook computer G-MAX N203 for a while, it is best to turn off the power of your notebook computer G-MAX N203 for longer use. Before turning off the power, you need to close first all application programs and shutdown the operating system.

  • Page 39: Introduction To Function

    3 Introduction to Function his chapter describes how to operate the standard built-in features of your notebook computer G-MAX N203 that you normally would use in your day-to-day computer work. If you are new to computers and to your operating...

  • Page 40: Starting Your Operating System

    3.1 Starting Your Operating System The operating system is a must ingredient in using your notebook computer G-MAX N203. Without an operating system, it is like playing chess without the chessboard. It is the platform for all your software application programs to run on.

  • Page 41: Function Keys

    Key features and operations are described below: Function Keys ➊ Function keys are application-driven, like F1 through F12 can be found on the keyboard. These keys work together with the Fn key to activate special functions. Some keys (printed in blue on keypad) are preprogrammed with dual functions.

  • Page 42: Basic Keyboard Functions

    G-MAX N203 User’s Manual Basic Keyboard Functions Keypad <Enter> key. Execute a command. Within many text Enter editing application programs, the <Enter> key inserts a hard carriage return, just like what ordinary typewriter does. <Esc> key. Press this key to cancel or escape from a command or function.
  • Page 43 Keypad <Shift> key. Press this key in combination with Shift alphabet letters to produce uppercase letters in typing. Use this key in combination with those two-character keys (found on the second row of the keyboard) to produce the upper marked keys. Also used in most application program in combination with other keys to execute a certain command.

  • Page 44: Cursor Control Keys

    G-MAX N203 User’s Manual Cursor Control Keys Keypad Up arrow key. Moves the cursor up one line at a time. PgUp Down arrow key. Moves the cursor down one line at a time. PgDn Left arrow key. Moves the cursor to the left one space at a time.

  • Page 45: Windows Hot Keys

    <Right Click> key. Performs a mouse right-click function for Windows system. Special Function Keys Notebook computer G-MAX N203 has special system function keys that activate key serving dual functions. When pressed in conjunction with the <Fn> key, these keys set specific system parameters and are sometimes referred to as "hot keys".

  • Page 46: Special Combination Keys

    Home 3.3 Using the Glide Pad Pointing Device Your notebook computer G-MAX N203 comes with a built-in Glide Pad pointing device that is found on the center of the palm-rest surface. The Glide Pad offers a number of options that let you customize how it functions.
  • Page 47 1. Left Selection Button 3. Scroll Button Here how to use the Glide Pad pointing device: The rectangular surface acts like a miniature duplicate of your display screen. To move the mouse cursor, place the finger lightly on the sensor pad and move in the desired direction.

  • Page 48: Configuring Your Screen Display

    N203 User’s Manual 3.4 Configuring Your Screen Display The VGA display function of your notebook computer G-MAX N203 is based on a high performance AGP local bus controller and is fully IBM VGA compatible. This controller offers a large set of extended functions and higher resolutions especially useful when you are connecting an external high-resolution and high-frequency CRT or LCD.

  • Page 49: Changing The Display Properties Under Windows

    Note: If you cannot configure the display properties, change the display driver first as mentioned on Section 5 "Installing Your Notebook Computer G-MAX N203 Device Drivers" of Chapter 2 in this manual. Consult your dealer for the latest Windows AGP VGA driver.

  • Page 50: Knowing The Power Saving Features

    N203 User’s Manual 3.5 Knowing the Power Saving Features One of the great features in your notebook computer G-MAX N203 aside from its superior performance is the ability to save energy power. Your notebook computer G-MAX N203 is designed to incorporate intelligent and advanced power management functions that turn off power of most components when system is idle or not in use.

  • Page 51: Working With The Built-In Hdd

    SETUP program before formatting the disk drive. Your notebook computer G-MAX N203 supports Auto-detect hard disk type, so you do not need to set it manually. Your dealer should already have done all of this for you. You can refer to Chapter 4 on how to run the BIOS SETUP program.

  • Page 52: How To Access The Optical Disk Drive

    3.7 How to Access the Optical Disk Drive Your system ships with either a DVD-ROM or DVD combo installed on the right side of your notebook computer G-MAX N203. You would normally use the drive for installing operating system and software application programs.
  • Page 53 How to care the CD When you handle CDs, pay attention to the following guidelines: • Always pick up the CD by its edges. • Avoid scratching or soiling either side of the CD. • Do not write with the hard ball-point pen or apply labels on either side of the •...
  • Page 54 G-MAX N203 User’s Manual...

  • Page 55: Setting / Bios

    4 Setting / BIOS our notebook computer G-MAX N203 uses the Phoenix BIOS Setup program that allows you to set several system configuration in changing the way your notebook computer G-MAX N203 performs. This includes your system time and date, disk drive configuration and password setup.

  • Page 56: Using The Xpress Recovery Utility

    G-MAX N203 User’s Manual 4.1 Using the Xpress Recovery Utility Xpress Recovery utility is an utility for backing up and restoring your operating system partition. Your hard drive must conform to the following specifications for this utility to run properly. It must support FAT16, FAT32, and NTFS format.
  • Page 57 G-MAX N203 User’s Manual ：...
  • Page 58 G-MAX N203 User’s Manual...
  • Page 59 G-MAX N203 User’s Manual...
  • Page 60 Recover button. This function will recover your system to factory default or the backup image as you desired. Remove button. Remove the backup image. Exit button. Press Exit button to exit and restart your notebook computer G-MAX N203.

  • Page 61: Running The Bios Setup Program

    4.2 Running the BIOS Setup Program Your notebook computer G-MAX N203 is likely to have been properly setup and configured by your dealer prior to delivery. However, you may find it necessary to use your notebook computer G-MAX N203’s BIOS (Basic Input-Output System) Setup program to change system configuration information, such as the current date and time, or your hard disk drive type.
  • Page 62 G-MAX N203 User’s Manual Press <F2> to Enter SETUP Press the <F2> key to run the BIOS Setup program. The BIOS Setup program is organized into five menus which you can select using the <-- and --> keys. To move from one option to another, you use the up and down arrow keys while using the <F5>...

  • Page 63: Using The Main Menu Setup

    • Allows you to change the system time using the hour:minute:second format of your notebook computer G-MAX N203. Enter the current time for reach field and use the <Tab>, <Shift>+<Tab>, or <Enter> key to move from one field or back to another.
  • Page 64 G-MAX N203 User’s Manual Language • Display the BIOS Setup program in English or Japanese version. Boot Display Device • Lets you select the display device. Primary Master • This field display various parameters for the hard disk drive. If type [Auto] is selected, the system automatically sets these parameters.

  • Page 65: Internal Hdd Sub-Menu

    Use the Type field to select the drive type installed. You can select different drive types as CD-ROM, User, Auto or None by pressing <Space> bar. Set this option to Auto so your notebook computer G-MAX N203 will automatically detect the drive type during power on. Set this option to None when your notebook computer G-MAX N203 is not installed any devices.

  • Page 66: Using The Advanced Cmos Setup

    G-MAX N203 User’s Manual 4.4 Using the Advanced CMOS Setup Phoenix BIOS Setup Utility Main Advanced Num Lock TV Standard Embedded Shared Memory Summary Screen Quiet Boot USB 2.0 PXE OPROM Wireless On/Off Brightness Level (AC-In) Brightness Level (Bat Only) Help Select Item Esc Exit...
  • Page 67 Embedded Shared Memory • Lets you specify the sharing memory size of the Video chip from DDR SDRAM. The Default sharing size can be 8MB, 16MB, or 32MB. You should carefully specify the value, since while the set value is too high, the memory size of your software application will be reduced.

  • Page 68: Security Menu Setup

    • Shows that your notebook computer G-MAX N203 is under controlled by Supervisor Password or not. User Password Is • Shows that your notebook computer G-MAX N203 is under controlled by User Password or not. Security Boot Item Specific Help...
  • Page 69 In this situation, only the supervisor can access the Boot Sector of fixed disk.. Password on Boot • If you set this field to Enabled, your notebook computer G-MAX N203 will always ask for the password every time you boot your notebook computer G-MAX N203. G-MAX...

  • Page 70: Using The Boot Setup

    G-MAX N203 User’s Manual 4.6 Using the Boot Setup This item allows you to set the search drive sequence where the system will try to boot up first. Phoenix BIOS Setup Utility Main Advanced Removable Devices +Hard Drive CD-ROM Drive Network Boot Help Select Item...

  • Page 71: How To Exit The Setup Program

    4.7 How to Exit the Setup Program There are two choices to escape from the Setup program. Phoenix BIOS Setup Utility Main Advanced Exit Saving Changes Exit Discarding Changes Load Setup Defaults Discard Changes Save Changes Battery Refresh Help Select Item F5/F6 Esc Exit -->...

  • Page 72: How To Upgrade The Bios

    N203 User’s Manual 4.8 How to Upgrade the BIOS Your notebook computer G-MAX N203 uses EPROM Flash BIOS chip that allows you to easily upgrade the BIOS program. When you update the BIOS, any customized settings you made are lost. Please go to Gigabyte website at http://www.gigabyte.com.tw...
  • Page 73 Select the operation you desired. “Backup BIOS and Flash BIOS with new settings” will erase all the settings you previously made. Specify the location of your backup file and your new BIOS file. Click Flash BIOS when you are ready to reset your BIOS with new settings. Click OK to start running the flash program.
  • Page 74 The system now will be shut down for the program to be successfully completed. You may press the power button to restart your notebook computer G-MAX N203.
  • Page 75 G-MAX N203 User’s Manual...

  • Page 76: Connecting To Peripherals

    Peripherals his chapter describes how you attach peripheral devices to your notebook computer G-MAX N203. You can attach a printer or mouse; connect an external monitor and keyboard, or any other peripheral device. You will learn how to use these peripheral devices with the step-by-step...

  • Page 77: Using The Usb Port

    USB port. 5.2 Using an External Monitor Port Your notebook computer G-MAX N203 has a 15-pin Monitor port for supporting any external CRT or LCD color monitor. You need a display signal cable (usually provided with the monitor).
  • Page 78 Turn the power of the monitor. Turn on your notebook computer G-MAX N203. Both the LCD panel and the monitor screen will show the display. Your notebook computer G-MAX N203 is set at default to run at simultaneous display mode.

  • Page 79: Using The Tv Port

    5.3 Using the TV Out Port Also found at the back of your notebook computer G-MAX N203 is one RCA port. To display your notebook computer G-MAX N203 screen on the TV, please connect the TV out port of this notebook to the Video Input of the TV set. You can press <Fn>...

  • Page 80: Using The Ieee 1394 Port

    IEEE 1394 port at the left side of your notebook computer G-MAX N203. IEEE 1394 becomes an ideal for devices that need to transfer high speed data in real-time.

  • Page 81: Using The External Audio System

    5.5 Using the External Audio System At the rear side of your notebook computer G-MAX N203, you will find the built-in audio ports. You can connect Microphone jack, earphone or powered speaker. To connect to a audio jack: Locate the audio port (Microphone, Headphone) that you want to use to the target device.

  • Page 82: Using The Wireless Lan

    Your notebook computer G-MAX N203 integrates built-in IEEE 802.11b/g wireless LAN module, with using Intel ® PRO/Wireless network solution by Intel ®...

  • Page 83: Using The Modem Port

    To connect the analog phone cable to your modem: Locate the analog phone cable in the accessories box in your notebook computer G-MAX N203 shipping carton. Each end of the cable has a RJ-11 connector. Connect one end of the cable into a standard wall outlet.

  • Page 84: Using Pc Cards

    32-bit PCI bus master interface from PCMCIA. It runs up to 33MHz clock speed and operates at only 3.3V. Your notebook computer G-MAX N203 incorporates the CardBus inside the PC card slot. Aside from 3.3V CardBus PC cards, you can also insert 5V 16-bit PC cards that can also be detected and used by your notebook computer G-MAX N203.
  • Page 85 Both network PC cards and fax/modem cards can use with your notebook computer G-MAX N203. However, if you use built-in LAN/Modem options of your notebook computer G-MAX N203, it is not necessary to use those cards. If you start the LAN/Modem application without inserting the fax/modem card or had the built-in LAN/Modem options installed, the application typically does not find the card.

  • Page 86: Inserting And Removing A Pc Card

    G-MAX N203 User’s Manual Inserting and Removing a PC Card Your notebook computer G-MAX N203 includes hot swapping capability, that allows you to exchange cards while the computer is turn on and start using it immediately. Inserting PC Cards To insert a PC card into the PCMCIA slot: Locate the PC card slot cover on the left side of your notebook computer G-MAX N203.

  • Page 87: Removing Pc Cards

    Removing PC Cards To remove a PC card from the PCMCIA slot, you should first disable the PC card setting in the system as described followings: Double click the PC card icon on the right bottom side of the task bar. Select the socket from the list that you want to remove, and click Stop button.

  • Page 88: Making Pc Cards Work

    Making PC Cards Work Since PC cards come in different types and brands, making every card work on your notebook computer G-MAX N203 may not that be easy. PC cards like network, SCSI or multifunction cards (MFC) need additional driver installation and configuration in making the card work.
  • Page 89 G-MAX N203 User’s Manual...

  • Page 90: System Upgrade

    G-MAX N203 User’s Manual 6 System Upgrade his chapter describes how to upgrade your system. You can upgrade your memory size to your system for specific requirements. This section provides an easy step in doing system upgrade for your notebook computer G-MAX N203.

  • Page 91: Memory Upgrade Procedures

    512 MB Installing Memory Module Your notebook computer G-MAX N203 comes with standard 128MB, 256 MB or 512MB of synchronous DDR SDRAM. You can increase system memory to a maximum of 1024 MB in the system, by installing one small outline double inline memory modules (SO-DIMMs) with installed base memory in the system.
  • Page 92 G-MAX N203 User’s Manual Remove the screw and open the DIMM cover by your finger. Locate the memory module into the empty memory module sockets. (Your system comes with one memory module already installed in the socket.) Note: Avoid touching the exposed components inside the system. Doing so may damage the system.

  • Page 93: Upgrade Hard Disk

    6.2 Upgrade Hard Disk Your notebook computer G-MAX N203 offers one 2.5" format, 9.5mm height hard disk. If the volume does not fit your need or it is crashed, you can upgrade it by replacing with new hard disk. Please do the following steps to change it.
  • Page 94 G-MAX N203 User’s Manual 7 Cleaning & Maintenance our notebook computer G-MAX N203 will serve you well if you take care of it. This chapter describes some tips and notice about how to care and maintain your notebook computer G-MAX N203.

  • Page 95: Taking Care Of Your Notebook Computer G-Max N203

    7.1 Taking Care of Your Notebook Computer G-MAX N203 • The openings on the enclosure are for air convection hence your notebook computer can be protected from overheating. DO NOT COVER THE OPENINGS. Do not expose your notebook to direct sunlight. Do not place it near sources •...

  • Page 96: Taking Care Of Your Battery Pack

    G-MAX N203 User’s Manual The total ampere ratings of the equipment plugged in should not exceed the • ampere rating of the cord if you are using an extension cord. Also, the total current rating of all equipment plugged into a single wall outlet should not exceed the fuse rating.

  • Page 97: Clean And Serving

    7.2 Cleaning and Serving When cleaning your notebook, follow these steps: 1. Power off your notebook and remove the battery pack. 2. Disconnect the AC adapter. 3. Use a soft cloth moistened with water. Do not use liquid or aerosol cleaners.

  • Page 98: When You Travel

    G-MAX N203 User’s Manual • Never move or raise the computer while the hard disk is being accessed, most especially don't jar the hard disk as this may cause a hard disk crash. • Use hard disk maintenance programs like Disk Defragmenter of Windows. These reorganize your hard disk by eliminating fragmentation and improving your hard disk access time.
  • Page 99 G-MAX N203 User’s Manual...

  • Page 100: Troubleshooting

    Solutions to more serious problems require opening up your notebook computer G-MAX N203. Do not attempt to open and service your notebook computer G-MAX N203 by yourself. Contact your dealer or an authorized service center for assistance.

  • Page 101: Frequently Asked Questions

    Frequently Asked Questions This is a list of possible situations that may arise during the use of your notebook computer G-MAX N203, and it gives easy answers and solutions to these questions. I press the power switch, but my notebook computer G-MAX N203 does not start or boot-up.
  • Page 102 G-MAX N203 either. If headphones, earphones or external speakers are connected to the line-out port on your notebook computer G-MAX N203’s rear panel, the internal speakers automatically turn off. External microphone does not work.
  • Page 103 Make sure the printer cable is connected securely to your notebook • computer G-MAX N203’s port and the corresponding port on the printer. I want to set up my location to use the internal modem. To properly use your communications software (e.g., HyperTerminal), you need to set up your location: Open the Windows Control Panel and double-click on the Modems icon.

  • Page 104: Appendix A System Information

    System Information his appendix gives information on the technical and hardware specifications of your notebook computer G-MAX N203. Please note that the information mentioned here may not be exactly the same with your notebook computer G-MAX N203 as specification is subject to change without notice or modifying this manual.

  • Page 105: System Specification

    One user-upgradeable slot to maximum 1024 MB using 200-pin SODIMM 128MB, 256MB and 512MB module • DDR 333 SDRAM modules Note: We recommend that you should go to your local Gigabyte Service Center for memory upgrading. LCD Display • 12.1" XGA (1024x768) Color TFT LCD Maximum 16M true colors on all LCD display •...

  • Page 106: Disk Drives

    G-MAX N203 User’s Manual Disk Drives • 32-bit PCI Enhanced IDE interface with LBA mode • 9.5mm height Ultra DMA 100 HDD • Enhanced IDE bootable CD-ROM drive module • Optional DVD-RW combo drive that can be replaced with CD-ROM Optional CD-RW/DVD combo drive that can be replaced with CD-ROM •...

  • Page 107: Flash Bios

    Flash BIOS • 512K Flash ROM BIOS for easy BIOS upgrade I/O Ports • 3 x Universal Serial Bus (USB 2.0) • 1 x 15-pin VGA (Monitor) • 1 x RCA TV port • 2 x IEEE 1394 port • 1 x LAN port •...

  • Page 108: Appendix B Service Centers

    G-MAX N203 User’s Manual APPENDIX Service Centers his appendix gives information about Service Centers of your notebook computer G-MAX N203.
  • Page 109 • Address: No.6, Bau Chiang Road, Hsin-Tien, Taipei Hsien, Taiwan, R.O.C. • TEL: +886 (2) 8912-4888 • FAX: +886 (2) 8912-4004 • How to submit a question? Technical Issues about using GIGABYTE products. Non-technical Sales and marketing issues • WEB Address (English): http://www.gigabyte.com.tw/ •...
  • Page 110 Non-technical Sales and marketing issues The Netherlands GIGA-BYTE TECHNOLOGY B.V. • Tel: +31 40 290 2088 • NL Tech.Support : 0900-GIGABYTE (0900-44422983) • BE Tech.Support : 0900-84034 • Fax: +31 40 290 2089 • How to submit a question? Technical Issues about using GIGABYTE products.
  • Page 111 WEB Address: http://www.gigabyte.fr/ Russia Moscow Representative Office Of Giga-Byte Technology Co., Ltd. • How to submit a question? Technical Issues about using GIGABYTE products. Non-technical Sales and marketing issues • WEB Address: http://www.gigabyte.ru/ Poland Representative Office Of Giga-Byte Technology Co., Ltd. POLAND •...

Table of Contents
