Oven Racks (cont.)
To Remove An Extension Rack:
To Replace An Extension Rack:
Traditional Flat Racks
To Remove a Rack
To Replace a Rack
CAUTION:
Aluminum Foil and Oven Liners
CAUTION:
Do not use any type of foil or oven liner to cover the oven bottom. These items can trap
heat or melt, resulting in damage to the product and risk of shock, smoke or fire. Damage from improper use
of these items is not covered by the product warranty.
49-80707-1
Use caution when removing a rack from lowest position as door may be hot.
Handle
Left to unlock
from the rack
support
Install Feature
Hold the upper front rail and lower
handles and push the rack all the
way in until the install feature locks
on the fron support
Locating
Post
Rack
Support
Handle
Upper Front Rail
Front Rack
Lock
Flat Rack
Stopper
11
