Conformity is indicated by the CE marking affixed to the product. Conformity Information For more information regarding CE marking and Declaration of Con- formity (DoC), please contact your local VIPA customer service organization. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
VIPA GmbH, Ohmstraße 4, 91074 Herzogenaurach, Germany Tel.: +49 9132 744-1150 (Hotline) EMail: support@vipa.de 1.2 About this manual Objective and contents This manual describes the Touch Panel 62E-MDC0-... from VIPA. It contains a description of the structure, project engineering and deployment. Product Order number...
This device is not certified for applications in – in explosive environments (EX-zone) Documentation The manual must be available to all personnel in the project design department installation department commissioning operation HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 7
– The national rules and regulations of the respective country must be satisfied (installation, safety, EMC ...) Disposal National rules and regulations apply to the disposal of the unit! HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Instruments must be grounded. Modifying electrostatic sensitive modules you should only use sol- dering irons with grounded tips. CAUTION! Personnel and instruments should be grounded when working on electrostatic sensitive modules. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
2 RJ45 jack for Ethernet communication 3 "Host"-USB-A interface 4 Slot for DC 24V voltage supply Please make sure that the Touch Panel always has to be supplied with external voltage! 2.3.2 Interfaces HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 13
DC 24V (20.4 ... 28.8V). For this you find an according DC 24V slot at the back. The power supply is pro- tected against inverse polarity and overcurrent. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
SDMMC Card at My Device. 2.4 Dimensions Installation dimensions For the installation of the Touch Panel in control cabinets and desks the following dimensions are necessary: HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 15
– The deviation from the plane for the panel cut-out is 0.5mm. This condition must be fulfilled for the mounted HMI device. – Permissible surface roughness in the area of the seal: £ 120µm (friction coefficient 120) HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
272 x 480 / 480 x 272 Aspect ratio 16:9 Type of display TFT color (64K colors) MTBF Backlights (25°C) 30000 h System properties Processor ARM11 533 MHz Operating system Windows CE 6.0 Core HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 18
Ethernet 10/100 MBit Ethernet connector RJ45 Integrated ethernet switch Technical data power supply Power supply (rated value) DC 24 V Power supply (permitted range) DC 20.4...28.8 V Reverse polarity protection ü HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 19
2.5 mm Maximum front panel thickness 6 mm Weight 500 g Environmental conditions Operating temperature 0 °C to 50 °C Storage temperature -20 °C to 60 °C Certifications UL certification KC certification HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
For the cabling of the DC 24V power supply a green plug is used. The connector is a plug with screw contacts. The plug has the following assignment: + DC 24V DC 0V HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Store respectively send the interface module always in the corresponding ESD packaging! Installation Remove the cover plate of the COM3 port by removing the screws and pulling the plate. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 22
Now press the interface module downwards until the holding plate snaps into the lugs. Please make sure that the holding plate always snaps to the lugs, otherwise the holding plate can not be screwed! HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
– Signal cables must not be let within the same cable shaft as high voltage cables. 3.3.1 VIPA Startup-Manager As soon as the Touch Panel is provided by power supply, the VIPA Startup-Manager will be loaded. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 24
With [Search Image] a list of all the firmware images is shown, which are available on the panel and connected storage media. These images will be listed with create data and version number. Choose your new image. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 25
At "Delay Time" you can adjust a delay time > 0 by using the buttons [+] and [-]. 5 seconds are default. Via "Rotation" the orientation of the panel can be changed. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
After an image update it is necessary to re-install Movicon and Startup-Manager. The current data can be found in the service area of www.vipa.com. For the Panel 62E-MDC0-... the directory VIPA and the file AutoRun- Maker.cfg is necessary of the following zip file: 62E-MDC0-..._install_SD_Card_Vxxx.zip...
Page 27
ð After start-up the following window appears. Click [Make]. ð All the necessary files are copied and the registry is accord- ingly adjusted. The progress is displayed in a new window. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
During operation your operating device communicates with the according PLC and reacts to the application courses in the PLC according to the configured processes. Via dialogues configured before, process values may be monitored graphically, altered and evaluated. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Please note that for the deployment of Windows CE a profound Ò Ò standard Windows knowledge of operating Windows is assumed. Here are only shown operation Ò the differences to a "standard" Windows operating system. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 30
Please note that changes are stored automatically after 30 seconds. For manual storage, please use the "suspend" function, to be found in the start menu. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
This area shows the time that you may change via double click. Show desktop All windows are minimized and the desktop is shown. Software keyboard This button displays a keyboard at the screen. "Hide Input Panel" hides the keyboard again. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 32
At the moment the following standard keyboards are imple- mented: Keyboard At pushed Shift key: At pushed [a´ü] key: Please note that äöü can exclusively be entered via the software keyboard "Keyboard". Large KB At pushed Shift key: HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 33
Click [OK] to accept the value. The calibration of the touch screen is completed via the register Calibration by following the instructions. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 34
Startup-Manager the tool "MPI/DP Slave Configuration". Default: MPI - Address 1 The following settings are only required if not communicate via Movicon. Via mode the interface could be set up on "DP slave". HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Depending on the ftp client your PC must have the following condi- access tions for a ftp connection. If there are still problems with the ftp access please ask your system administrator. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Condition for the VNC communication is, that the VNC server is started on the Touch Panel and a VNC client on the PC. You may download a VNC client as freeware from internet. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 37
[OK] and enter the password vipatp. You can change the pass- word over the configuration file, for this execute vncconfig.exe. Now a VNC connection is established and the screen content of the Touch Panel is monitored within a window. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
My Device at Network. Example: Local_Name: data, network drive: testserver\archive, User- name:guest Input: \> net use data \\testserver\archiv / user:guest The connected network drive is then available via \network\data at the Touch Panel. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 39
You may terminate already assigned network resources via nections \> net use local_name /d Example: \> net use data /d deletes the network connection to the drive "archive" of "test server". HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Depending on the spreading medium (lead bound or lead free) and the distance to the interference cause, interferences to your control occur by means of different coupling mechanisms. There are: galvanic coupling capacitive coupling inductive coupling radiant coupling HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 41
(e.g. walkie-talkie) wave meets a line circuit. The Sparking lines (sparking hit of the wave inducts currents plugs, collector of electric and voltages. motors, welding devices) HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
A correctly done grounding sup- inactive metal parts ports an unambiguous reference potential for the control and reduces the impact of coupled interferences. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
>400V Group D Lines for H1 respectively TCP/IP Combination of groups Following the table you may see the conditions for the cabling of the line groups by combining the single groups: HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 44
– Install these protective elements at the location where the cables enter the building. Any lightning protection system must be based on an indi- vidual assessment of the entire plant. For questions please contact VIPA GmbH. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 45
The one-sided grounding of screens may provide advantages when: It is not possible to install an equipotential bonding conductor Analogue signals (a few mV or mA) must be transmitted Foil-type screening (static screening) is employed. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
(e.g. relay contacts). In this case the integrated suppressors on the module are also disabled. You can connect diodes to suppress back-emc, varis- tors or RC-networks to the inductors. HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Page 47
Suppression of fluores- cent lamps in cubicles 1 Fluorescent lamp 2 Screen above the lamp 3 Screened cable 4 Switch with metallic cover 5 Line filter or screened power cable HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
Have the screens been connected by means of large-surface and low- impedance cable clamps? Cable screens grounded both-sided where possible? Inductors Have the coils of contactors controlled by means of contacts been connected to snubber networks? HB160 | TP-ECO | 62E-MDC0 | GB | 16-02...
