OWNER’S MANUAL CAR CD/MP3/WMA Receiver Please read this manual carefully before operating your set and retain it for future reference. LCS710BRS / LCS710DAB / LCF810BRS / LCF810DAB www.lg.com.mx...
Page 2
Getting Started To reduce the risk of electric Safety Information shock, do not remove the cover or back of this product. There are CAUTION no user-serviceable parts inside. Refer servicing to qualifi ed service RISK OF ELECTRIC SHOCK personnel. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC To reduce the risk of fi re or electric SHOCK DO NOT REMOVE COVER (OR BACK) NO...
Page 3
You have to set the disc format option to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live File System, you cannot use it on LG players.
Getting Started – Adjusting TUNER settings Listening to the DAB (Only LCS710DAB / Safety Information LCF810DAB) Front panel [LCS710BRS / LCS710DAB] – Storing desired frequencies manually Front panel [LCF810BRS / LCF810DAB] – Listening to a preset station Remote control – Adjusting DAB settings –...
Getting Started Front panel [LCS710BRS / LCS710DAB] [Front unit detached panel] Ejects a disc. - Activates BT function. b SRC / • OFF - Answers a call. - When pressed, selects function sources. - When pressed and held, powers unit on or off .
Getting Started Front panel [LCF810BRS / LCF810DAB] [Front unit detached panel] a SRC / • OFF - When pressed, selects function sources. - Activates BT function. - When pressed and held, powers unit on or off . - Answers a call. Plays and pauses playback.
Getting Started i DISP Remote control • Press it, you can check the clock time. • Press and hold it, you can turn on / off the display window and the light of LED buttons. j RPT Repeats playback. k INT Intro scan.
Detaching the control panel About detachable 1. Press the 6 to open the control panel. control panel [LCS710BRS / LCS710DAB] Attaching the control panel 2. Push the control panel to right. 3. Pull the control panel out of the unit.
Connecting About detachable Detaching the control panel 1. Press the OPEN to open the control panel. control panel [LCF810BRS / LCF810DAB] Attaching the control panel 2. Push the control panel to left. 1. Attach part of the control panel to part of the unit.
Connecting ISO-DIN Installation Installation Basic Installation Before installing, make sure that the ignition-switch is set to OFF and remove the terminal of the car battery to avoid short-circuiting. Bend the claws according to the thickness of the dashboard. Control panel 1.
Connecting Connection Connecting to a car Before installing, make sure that the ignition-switch is set to OFF and remove the terminal of the car battery to avoid short-circuiting. Wired remote input (Black): Hard-wired control adapter can be connected. (Optional) Wired mic (Optional) To Audio out To Audio in Sub-woofer Left...
EQ is to increase or decrease the signal strength of audio frequencies. The function helps you to enjoy sound more plentifully. [LCS710BRS / LCS710DAB] [LCF810BRS / LCF810DAB] Press EQ on the unit. And rotate the volume knob to select the item and press it. The indicator lights up in the following order.
Operating Adjusting the general settings For [SOUND] setting You can adjust sound quality by adjusting the level You can adjust [SOUND], [LIGHT] and [OTHER] of BALANCE (left / right speaker), FADER (front / settings. rear speaker), SW (Subwoofer), SW-F (Subwoofer Frequency) and A-EQ (Auto EQ).
For [OTHER] setting Listening to a CD AUX (Auxiliary) ON / OFF It is possible to use auxiliary equipment with this [LCS710BRS / LCS710DAB] unit. Activate the auxiliary setting when using 1. Insert a CD. auxiliary equipment connected to this unit.
Operating Skipping to another track/ fi le On the Remote Control 1. Press FUNC / • MENU. Press A / D on the unit. Or press c / v on the remote control. 2. Press w / s to select an item and press it. 3.
[Mastered] in order to make the discs prevent radical changes in volume by selecting compatible with the LG players when GAIN 0 / +3 / +6. formatting rewritable discs. When setting the 1.
For auto search, press A / D on the unit until Or press BAND and then press the desired preset “SEARCH” is displayed. (Except MW) button among 1 to 6 on the unit. (Only LCS710BRS Or press c / v on the remote control. / LCS710DAB) 4.
Operating Adjusting TUNER settings RDS (OPTIONAL) AF (Alternative Frequency) ON / OFF When the reception quality drops, the tuner On the unit automatically changes to another station in the 1. Press network, broadcasting a better reception quality, using the PI and AF codes. 2.
Operating 4. Repeat steps 1 to 3 to preset other stations. Listening to the DAB Note (Only LCS710DAB / When a station is stored on the preset numbers on which another station of the same LCF810DAB) band has already been preset, the previously preset station is automatically erased.
DRC (Dynamic Range Control) ON / OFF Automatically adjusts the audio level. ANNOUNCE (Announcement) X / O Provides information on selected contents. [LCS710BRS / LCS710DAB] [LCF810BRS / LCF810DAB] TRFC (Traffi c), TRNSP (Transport), WARN (Service Warning), NEWS, WTHR (Weather), EVNT (Event), Moving to another drive...
Operating Digital camera and mobile phone are not Quick Search of a desired fi le supported. You can select and play a desired fi le regardless of USB Port of the unit cannot be connected to PC. the order in USB device / SD card. The unit cannot be used as a storage device.
"REC ERR MEMORY FULL" [LCF810BRS / LCF810DAB] displays and stops recording. While FM tuner / DAB / Bluetooth Handsfree [LCS710BRS / LCS710DAB] [LCF810BRS / LCF810DAB] recording, the broadcastings are recorded 1. Open the USB cover. as a fi le every 20 minutes.
Operating Playing back tracks / fi les in a Playing back fi les by music way you want menus You can check fi les by music menus and play it On the Unit back. The music menus are as follows. 1.
Apple performance standards. [LCS710BRS / LCS710DAB] [LCF810BRS / LCF810DAB] Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.
Operating Using the buttons for Using a Bluetooth wireless Bluetooth wireless technology technology Disconnecting a phone Go to the menu ( -> CONNECT -> LIST -> Connected device name -> DISCONN). Answering and Ending a call When your unit rings, press to answer a call.
Operating Audio transfer Adjusting the setting It is possible to switch the audio connection 1. Press between your phone equipped with Bluetooth 2. Rotate the volume knob to select an item and wireless technology and this unit. press it. 1. Press to answer the call.
Operating WICS (Wireless Controller & P-BOOK Synchronization) LIST Checks the list of the phone numbers saved by You can control the unit by using the "WICS" phonebook. application. SEARCH 1. Search the “WICS” application and install it. Searches the phone number in the list. ...
Operating Phone compatibility list Bluetooth list and manufacturing H : Hnadsfree P : Phonebook Sync (GET) company applicable. A : Audio Streming (A2DP) Company List Company List Nokia SAMSUNG D900 5200 SGH-U600 SGH-Z240 SGH-F300 SGH-E890 SGH-E950 3250 SGH-F210 6110 SGH-G600 6288 i-900 F330...
Page 29
Operating Bluetooth list and manufacturing H : Hnadsfree P : Phonebook Sync (GET) company applicable. A : Audio Streming (A2DP) Company List Company List SONY P990i BL40 (New Chocolate) ERICSSON W910i KM335 C702i GD510 (POP) G705 GD880 W595 GM730 W705 GS500 (Cookie Plus) W980i GT505...
Page 30
Operating “The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners.” Bluetooth® wireless technology is a system which allows radio contact between electronic devices within a max range of 10 meters.
Troubleshooting Troubleshooting Symptoms Cause Solution Power doesn't turned on. Leads and connectors are not Confi rm once more that all connections properly. are correct. The unit doesn't operate. The fuse is blown. Rectify the problem that caused the fuse to blow, and then replace it. Be very sure to install the correct fuse with the same rate.
Appendix Steering Remote Control Appellation Appellation • Selects function sources. • Answering or ending a call. • Skip/ Search/ Seek/ Tune • Adjusts the volume knob. Note • Press and hold SRC, you can turn the unit off during operation. •...
Page 33
Appendix Note Battery installtation • Use only one CR2025 (3V) lithium battery. • Remove the battery if the remote control is Battery Installation not used for long. • Do not handle the battery with metallic tools. • Do not store the battery with metallic materials.
Page 34
Appendix > Caution Installation • Avoid installing this unit in such a location If you install in place other than installation scope, where the operation of safety devices such as airbags is prevented by this unit. this unit is not operated. Otherwise, there is danger of a fatal accident.
Page 35
Appendix 3. Install the remote control unit in the holder. Installing the unit on a Left- Hand-Drive Car When the unit is installed on a Right-Hand-Drive car, the horizontal position are inverted. 1. Secure Cover holder to the inner circumference of the steering wheel with belt .
Appendix Specifi cations Version : USB 1.1 or USB 2.0 Full Speed Bus Power Supply (USB) : DC 5 V General Output Power : 53 W x 4 CH (Max.) Distortion : 0.1 % Power Source : DC 12 V Speaker impedance : 4 Ω...
Page 37
Av. Sor Juana Inés de la Cruz No 555 Col. San Lorenzo Tlalnepantla, Estado de México CP 54033 Tel. (55) 5321-1919 Lada sin costo 01 (800) 347 1919 LG Electronics México S.A. de C.V.
