Cateye RAPID MICRO TLLD620R Manual

Manual
Before using the light, read this manual
thoroughly and keep it for future reference.
Design Pat. Pending
Copyright© 2021 CATEYE Co., Ltd.
TLLD620R-211006 3
WARNING!!!
• Check periodically to ensure that the light unit
is attached securely. Do not use a damaged
rubber band.
• Always attention to the remaining battery power
by checking the indicator periodically while using.
CAUTION!
• Stop your bicycle to operate the switch.
• Do not place it within children's reach.
• This unit is not totally waterproof. Please wipe
and dry it completely after using in rain.
Otherwise, it may cause failure.
• If the light unit or parts become dirty with mud,
etc., clean with a soft cloth which is moistened
with mild soap. Never apply paint thinner,
benzine or alcohol; damage will result.
LITHIUM-ION BATTERIES
Cautions on recharging
• We recommend using 500+mAh (USB2.0)
USB battery charger.
• Avoid charging in direct sunlight or in a
vehicle parked under direct sunlight, and
make sure to charge only when the ambient
temperature is between 41°F and 104 °F (5
and 40°C).
• Before charging, be sure that no dust or other
foreign objects attach to the USB plug.
• Do not subject the light to vibrations while
charging.
• When your PC is in sleep state, the unit
cannot be charged.
• Once charging is complete, be sure to
disconnect the USB plug.
• Charging time is approximate values, and will
vary depending on the environmental and
usage conditions.
Cautions in use
• Charging, discharging, and storing in high
temperatures will cause the rechargeable
battery to deteriorate faster. Do not place the
light inside a vehicle or near a heater.
• If the illumination time is significantly reduced
even after proper charging, the rechargeable
battery may be nearing the end of its service
life. Dispose of the battery as described in
"Cautions for dispose".
Cautions on storage
Cool and dry storage is recommended. For long
period storage, it is important to charge the
battery 30 minutes every 6 months.
Cautions for dispose
When disposing of the light unit, remove the
internal rechargeable battery and dispose of it
according to local regulations.
ENG
TL-LD620-R
Light unit
1
HOW TO CHARGE
Always charge the product before use.
2
HOW TO MOUNT
Attach securely in the mounting position.
Bracket rubber pad
1
Bracket
OPTION : Clip (C-2)
Clip
Bracket rubber pad
(SP-14-R)
Bracket
1
USB cable
2
To PC or USB battery charger
Rubber band
3
ø
21.5 – 32 mm
2
1
Clic
(MICRO USB)
USB cable
Rubber band
Switch (Indicator)
Charging Charging is
completed
Standard
Approx.
charging time
Horizontal
2
4
Vertical
4
2 h
(USB 2.0)
Clic
Clic
