Page 1
Roll the trackwheel Click (press) the trackwheel select items on the screen. Press the Escape button page in the browser. Hold the Escape button BlackBerry Wireless Handheld™ BlackBerry Wireless Handheld™ Getting Started Guide Getting Started Guide Headset jack Right Shift key Data/charging port to move the cursor and highlight items on the screen.
Page 2
Tips Phone Open the phone or make a Press the Phone button. phone call End a call from the Hold the Escape button. Active Call screen Mute a call from the Press the Phone button. Active Call screen Change the volume Roll the trackwheel.
Navigating your handheld Lock the handheld Set a password > Click the Lock icon Lock the keyboard Click the Keyboard Lock icon (only available if you have not set a password) Roll the trackwheel or Press Move the cursor + roll the trackwheel Return to previous screen Press the Escape button Click an item...
How do I... Make a phone call 1. In the phone, type a phone number. 2. Click the trackwheel. 3. Click Call. 4. To end the call, hold the Escape button. Add a contact 1. In the contact list, click the trackwheel. 2.
Insert the SIM card Insert the battery Charge the battery Turn wireless on Set up email Setting up for email using BlackBerry Enterprise Server Use enterprise activation Use the BlackBerry Desktop Software Setting up for email using Mobile Email Mobile...
Press the battery cover release button. Slide off the battery cover. If the battery is inserted, remove it. Slide the SIM card holder toward its hinge to unlock it. Lift the SIM card holder. Remove your SIM card from its packaging. Insert the SIM card into the holder so that the notches align.
Handheld Manager must be installed to obtain the required USB driver on your computer. See “Setting up for email using BlackBerry Enterprise Server” on page 4 or “Setting up for email using Mobile Email” on page 6 for more information.
GroupWise Server version 6.5 Service Pack 1 or later Use enterprise activation If your handheld is enabled on a BlackBerry Enterprise Server version 4.0, and your system administrator has provided you with an enterprise activation password, you can integrate your handheld with your account over the wireless network.
Page 9
Select BlackBerry Enterprise Server or • BlackBerry Desktop Redirector as your account integration option. Select BlackBerry Enterprise Server as your • message redirection option. Connect your handheld to your computer. On the Windows taskbar, click Start. Select Programs > BlackBerry > Desktop Manager.
You purchased your handheld in a store. You want to set up a new email account for your handheld. You want to set up an existing email account for your handheld. Verify that your handheld wireless radio is on and that you are in a wireless coverage area. If the Sign In screen does not appear automatically, click Mobile Email Settings.
Verify that your handheld wireless radio is on and that you are in a wireless coverage area. Click Mobile Email Settings. On the Sign In screen, type your account information. User ID: Type the login name for your • account. Password: Type the password for your •...
Outlook or IBM Lotus Notes email account, you might be prompted to install the BlackBerry Mail Connector application on your computer. Follow the on-screen instructions. See "What is the BlackBerry Mail Connector?" on page 11 for more information. Click Submit.
Page 13
Select BlackBerry Internet Service as your • account integration option. Connect your handheld to your computer. On the Windows taskbar, click Start. Click Programs > BlackBerry > Desktop Manager. BlackBerry Desktop Software Online Note: See the Help for more information on PIM...
If your handheld does not connect, open the BlackBerry Desktop Software. Click Options > Connection Settings. In the drop-down list, click the correct port.
If the option still does not appear, contact your service provider. What is the BlackBerry Mail Connector? The BlackBerry Mail Connector is a program that you might have to install on your local computer so that Mobile Email can access your corporate...
Page 16
Log in to your Mobile Email account. See “Log in to your account” on page 7 for more information. Click View/Modify. Note: To follow a link in the browser, click the link. Click Get Link. Edit your account information. Click Submit. Log in to your Mobile Email account.
Page 17
8 for more information. Mobile Email Online Help Vodafone customer support Support web site: United Kingdom: www.vodafone.co.uk/blackberry Netherlands, Ireland: www.office.vodafone.com Australia: www.vodafone.com Hungary: www.vodafone.hu Sweden: www.vodafone.se/200.jsp Portugal: www.vodafone.pt Belgium: corporate.proximus.be/fr/index.html corporate.proximus.be/nl/index.html corporate.proximus.be/en/index.html South Africa: www.vodacom.co.za/blackberry BlackBerry support web site: www.blackberry.com/support for information...
