Blackberry 7510 Getting Started Manual

Wireless handheld
Hide thumbs Also See for 7510:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Earpiece
Headset jack
USB port
Alt key
Type the alternate
character on a key
How do I navigate?
Roll the trackwheel
highlight items on the screen.
Click (press) the trackwheel
menu on most screens and to select items on
the screen.
Press the Escape button
cancel an action, or go back one page in the
browser.
Hold the Escape button
BlackBerry Wireless Handheld™
Push To Talk button
Respond to a direct connect call
Microphone
Left Shift key
to move the cursor and
to view the
to exit a screen,
to end a phone call.
Getting Started Guide
Notification LED
Trackwheel
Select or click an item
Escape button
Exit a screen
Backspace key
Enter key
Symbol key
Open the symbol list
Power button
Backlighting
Right Shift key
How do I use the
Push to Talk button?
Hold the Push to Talk
button to speak during
a direct connect call.
Release the Push to talk
button to listen during
a direct connect call.

Advertisement

Table of Contents
loading

Related Manuals for Blackberry 7510

Summary of Contents for Blackberry 7510

  • Page 1 Press the Escape button cancel an action, or go back one page in the browser. Hold the Escape button BlackBerry Wireless Handheld™ Getting Started Guide Push To Talk button Respond to a direct connect call Microphone Right Shift key...
  • Page 2 Tips Phone Open the phone Press Make a phone call Type a phone number from the Home screen End a call from the Hold the Escape button Active Call screen Change the volume Roll the trackwheel during a call Dial a letter in a phone Press number Call voice mail...

  • Page 3: Typing And Editing

    Navigating your handheld Lock the handheld Set a password > Click the Lock icon Lock the keyboard Click the Keyboard Lock icon (only available if you have not set a password) Roll the trackwheel or Move the cursor Press trackwheel Return to previous screen Press the Escape button Click an item...

  • Page 4: Add A Contact

    How do I... Make a direct connect alert 1. In the phone, type a direct connect number (AreaID*NetworkID*MemberID). 2. Click Alert. 3. Press the Push to Talk button. Respond to an alert 1. Press the Push to Talk button. 2. Hold the Push to Talk button to speak to your contact.

  • Page 5: Table Of Contents

    On the Help menu, click Desktop Help • Handheld User Guide Contents to view the BlackBerry Desktop Software Online Help In your BlackBerry Web Client account using a desktop browser On the menu bar, click Help to view the • BlackBerry Web Client Online Help...

  • Page 6: Setting Up Your Handheld

    Press the battery cover release button. Slide off the battery cover. If the battery is inserted, remove it. Slide the SIM card holder toward its hinge to unlock it. Lift the SIM card holder. Remove your SIM card from its packaging. Insert the SIM card into the holder so that the notches align.

  • Page 7: Turn Wireless On

    When your SIM card is inserted and the battery is charged, turn on the radio in an area of wireless coverage. Note: If you use BlackBerry Web Client, the account setup process might begin automatically the first time that you turn on the wireless radio.

  • Page 9: Setting Up For Email Using Blackberry Enterprise Server

    Software If enterprise activation does not appear on your Home screen, or if your handheld is not enabled on a BlackBerry Enterprise Server version 4.0, you can install the desktop software to integrate your handheld with your email account. Insert the BlackBerry Desktop Software Installation CD into your CD-ROM drive.

  • Page 10: Setting Up For Email Using Blackberry Web Client

    Insert the BlackBerry Desktop Software Installation CD into your CD-ROM drive. Complete the on-screen instructions. Select BlackBerry Web Client as your • email integration option. Connect your handheld to your computer. On the Windows taskbar, click Start.

  • Page 11: Frequently Asked Questions

    Frequently asked questions Verify that you have integrated your handheld with an email account. See “Setting up for email using BlackBerry Web Client” on page 6. How do I connect my handheld to the BlackBerry Desktop Software? If the desktop software is installed on your...
  • Page 12 Select BlackBerry Desktop Redirector as • your email redirection option. Connect your handheld to your computer. On the Windows taskbar, click Start. Click Programs > BlackBerry > Desktop Manager. When you are prompted to generate an • encryption key, follow the on-screen instructions.
  • Page 13 © 2005 Research In Motion Limited. All Rights Reserved. The BlackBerry and RIM families of related marks, images, and symbols are the exclusive properties of, and trademarks of, Research In Motion Limited (RIM). All other brands and marks are the properties of their respective owners.
