PXI
NI PXI-8186 User Manual
NI PXI-8186 User Manual
October 2003 Edition
Part Number 370747A-01

Advertisement

Table of Contents
loading

Related Manuals for National Instruments PXI-8186

Summary of Contents for National Instruments PXI-8186

  • Page 1 NI PXI-8186 User Manual NI PXI-8186 User Manual October 2003 Edition Part Number 370747A-01...
  • Page 2 Thailand 662 992 7519, United Kingdom 44 0 1635 523545 For further support information, refer to the Technical Support and Professional Services appendix. To comment on the documentation, send email to techpubs@ni.com. © 2003 National Instruments Corporation. All rights reserved.
  • Page 3 The reader should consult National Instruments if errors are suspected. In no event shall National Instruments be liable for any damages arising out of or related to this document or the information contained in it.
  • Page 4 These classes are known as Class A (for use in industrial-commercial locations only) or Class B (for use in residential or commercial locations). All National Instruments (NI) products are FCC Class A products. Depending on where it is operated, this Class A product could be subject to restrictions in the FCC rules. (In Canada, the Department of Communications (DOC), of Industry Canada, regulates wireless interference in much the same way.) Digital...

  • Page 5: Table Of Contents

    Description ......................1-2 Functional Overview ..................1-2 National Instruments Software ..................1-4 Chapter 2 Installation and Configuration Installing the NI PXI-8186 ....................2-1 How to Remove the Controller from the PXI Chassis ........2-4 BIOS Setup ........................2-4 Entering BIOS Setup ..................2-4 Main Setup Menu ....................2-5 Advanced Setup Menu ..................2-6...
  • Page 6 Cables and Connections ....................4-2 Software Driver Installation ..................4-3 Chassis Configuration ....................4-4 Upgrade Information ..................... 4-6 PXI Configuration ......................4-8 Chapter 5 Troubleshooting Appendix A Specifications Appendix B Technical Support and Professional Services Glossary Index NI PXI-8186 User Manual ni.com...

  • Page 7: About This Manual

    National Instruments NI PXI-8186 embedded computer kit. How to Use the Documentation Set Begin by reading the NI PXI-8186 Installation Guide, a brief quick-start guide that describes how to install and get started with your controller. This manual contains more details about changing the installation or configuration from the defaults and using the hardware.

  • Page 8: Related Documentation

    PCI Local Bus Specification, Revision 2.2, PCI Special Interest Group • PXI Hardware Specification, Revision 2.1, PXI Systems Alliance • PXI Software Specification, Revision 2.1, PXI Systems Alliance • Serialized IRQ Support for PCI Systems Specification, Revision 6.0, Compaq Computer et al. NI PXI-8186 User Manual viii ni.com...

  • Page 9: Introduction

    Additionally, PXI meets the more specific needs of instrumentation users by adding an integrated trigger bus and reference clock for multiple-board synchronization, a star trigger bus for very precise timing, and local buses for side-band communication between adjacent peripherals. © National Instruments Corporation NI PXI-8186 User Manual...

  • Page 10: Ni Pxi-8186

    NI PXI-8186 embedded computers. NI PXI-8186 Functional Description The NI PXI-8186 is a modular PC in a PXI 3U-size form factor. Figure 1-1 is a functional block diagram of the NI PXI-8186. Following the diagram is a description of each logic block shown.
  • Page 11 PCI Bus Controller Connectors Triggers 10/100BaseT Ethernet Flash LPC Bus SMB to PXI Trigger LPT 1 Super I/O Watchdog COM 1 COM 2 PS/2 Keyboard/ Mouse Figure 1-1. NI PXI-8186 Block Diagram © National Instruments Corporation NI PXI-8186 User Manual...

  • Page 12: National Instruments Software

    Chapter 1 Introduction The NI PXI-8186 consists of the following logic blocks on the CPU module and the I/O (daughter card) module. The CPU module has the following logic blocks: • Socket 478 CPU is the socket definition for the Intel Pentium 4 processor families.
  • Page 13 For information on writing your own PXI instrument driver with NI-VISA, refer to the NI-VISA Getting Started manual and the file in readme.txt directory. NI-VISA You also can use the National Instruments LabVIEW, Measurement Studio, ™ ™ and LabWindows /CVI application programs and instrument drivers to ease your programming task.

  • Page 14: Installation And Configuration

    Consult your PXI chassis user manual for specific instructions and warnings. Plug in your chassis before installing the NI PXI-8186. The power cord grounds the chassis and protects it from electrical damage while you install the module. (Make sure the power switch is turned off.)
  • Page 15 Figure 2-1. Removing Protective Screw Caps Make sure the injector/ejector handle is in its downward position. Align the NI PXI-8186 with the card guides on the top and bottom of the system controller slot. Do not raise the injector/ejector handle as you insert the NI PXI-8186. The...
  • Page 16 What if the NI PXI-8186 does not boot? section of Chapter 5, Troubleshooting. Figure 2-2 shows an NI PXI-8186 installed in the system controller slot of a National Instruments PXI-1042 chassis. You can place PXI devices in any other slot.

  • Page 17: How To Remove The Controller From The Pxi Chassis

    BIOS setup program includes menus for configuring settings and enabling NI PXI-8186 controller features. Most users do not need to use the BIOS setup program, as the NI PXI-8186 controller ships with default settings that work well for most configurations.

  • Page 18: Main Setup Menu

    However, if an IDE/ATA device is not autodetected properly, you can specify it manually by pressing <Enter> on an item. • System Information—This setting displays a screen containing important system information about the NI PXI-8186 controller. © National Instruments Corporation NI PXI-8186 User Manual...

  • Page 19: Advanced Setup Menu

    Yes to force the BIOS to recreate the ESCD on the next reboot. This is rarely necessary. • Integrated Peripherals—Use this setting to bring up the Integrated Peripherals submenu. (Refer to the Integrated Peripherals Submenu section.) NI PXI-8186 User Manual ni.com...
  • Page 20 Integrated Peripherals Submenu Use this submenu to apply nondefault configurations to the front panel peripherals of an NI PXI-8186 controller. Normally, you do not need to modify these settings, as the factory default settings provide the most compatible and optimal configuration possible.

  • Page 21: Pxi Setup Menu

    • INTP Routing—You can route INTP to ISA IRQ 14, for use by a PXI device functioning as a Primary IDE Controller. The default setting is Not Routed. NI PXI-8186 User Manual ni.com...

  • Page 22: Boot Setup Menu

    • Exit Discarding Changes—Any changes made to BIOS settings during this session of the BIOS setup program are discarded. The setup program then exits and boots the controller without rebooting first. © National Instruments Corporation NI PXI-8186 User Manual...

  • Page 23: System Cmos

    System CMOS. The setup program remains active, allowing further changes. System CMOS The NI PXI-8186 contains a backed-up memory used to store BIOS configuration information. Complete the following steps to clear the CMOS contents: Power off the chassis.

  • Page 24: Labview Rt Configuration Switches

    OFF position. The controller reads these switches only after a system reset. You must reboot the controller for any changes to take place. The NI PXI-8186 controller includes the following LabVIEW RT configuration switches: •...
  • Page 25 The switches are shown in the OFF position. 1 Switch 1—Boot LabVIEW RT 3 Switch 3—Disable Startup VI 2 Switch 2—Boot Safe Mode 4 Switch 4—Reset IP Address Figure 2-4. LabVIEW RT Configuration Switches NI PXI-8186 User Manual 2-12 ni.com...

  • Page 26: Drivers And Software

    National Instruments software manuals, all in Adobe Acrobat format. To access any manual, change your directory to and list the contents of that directory.

  • Page 27: Pxi Features

    PXI Features PXI Trigger Connectivity The SMB connector on the NI PXI-8186 front panel can connect to or from any PXI backplane trigger line through software. A trigger allocation process is needed to prevent two resources from connecting to the same trigger line, resulting in the trigger being double-driven and possibly damaging the hardware.

  • Page 28: Hard Drive Recovery

    Installation and Configuration 1 DDR SO-DIMM Module 2 DDR SO-DIMM Socket Figure 2-5. Installing a DDR SO-DIMM in an NI PXI-8186 Controller Hard Drive Recovery NI PXI-8186 controllers include Phoenix Technologies Ltd. Firstware tools, either Recover or Vault, or both. These tools allow you to recover the original factory condition of the hard disk from a small protected area of your hard drive.

  • Page 29: Installing An Os

    Back up any files you want to keep. Installing an OS NI PXI-8186 controllers include a preinstalled OS. In some cases, you may want to reinstall the OS or install a different OS. When doing so, consider the following guidelines.

  • Page 30: Front Panel Connectors

    I/O Information Front Panel Connectors Table 3-1 lists various peripherals and their corresponding NI PXI-8186 external connectors, bus interfaces, and functions. Table 3-1. NI PXI-8186 Peripherals Overview Peripheral External Connector Description Video VGA (15-pin DSUB) Intel Extreme Graphics controller Serial...

  • Page 31: Front Panel

    NI PXI-8186. Dimensions are in inches [millimeters]. 3.93 [99.8] 3.69 [93.7] 3.46 [87.9] 2.79 [70.9] 2.10 [53.3] 1.83 [46.5] 0.89 [22.6] NI PXI-8186 Embedded Controller 0.00 [0] Figure 3-1. NI PXI-8186 Front Panel Layout and Dimensions NI PXI-8186 User Manual ni.com...

  • Page 32: Vga

    I/O Information Figure 3-2 shows the location and pinouts for the VGA connector on the NI PXI-8186. Table 3-2 lists and describes the VGA connector signals. AMP manufactures a mating connector with part numbers 748364-1 (housing) and 748333-2 (pin contact).

  • Page 33: Com1 And Com2

    COM1 and COM2 Figure 3-3 shows the location and pinouts for the COM1 and COM2 connectors on the NI PXI-8186. Table 3-3 lists and describes the COM1 and COM2 connector signal. AMP manufactures a serial port mating connector, part number 745491-5.

  • Page 34: Ethernet

    Clear to Send Ring Indicator Ethernet Figure 3-4 shows the location and pinouts for the Ethernet connector on the NI PXI-8186. Table 3-4 lists and describes the Ethernet connector signals. AMP manufactures a mating connector, part number 554739-1. Ethernet NI PXI-8186 Embedded Controller Figure 3-4.

  • Page 35: Parallel Port

    Differential Receive Parallel Port Figure 3-5 shows the location and pinouts for the IEEE 1284 (parallel) connector on the NI PXI-8186. Table 3-5 lists and describes the IEEE 1284 connector signals. Parallel port adapter cables are available from National Instruments, part number 777169-01.
  • Page 36 Data Bit 3 Data Bit 4 Data Bit 5 Data Bit 6 Data Bit 7 INIT* Initialize Printer STROBE* Strobe SLCTIN* Select Input AUTOFD* Auto Line Feed +5 V 19–35 Ground Not Connected © National Instruments Corporation NI PXI-8186 User Manual...

  • Page 37: Universal Serial Bus

    I/O Information Universal Serial Bus Figure 3-6 shows the location and pinouts for the Universal Serial Bus (USB) connector on the NI PXI-8186. Table 3-6 lists and describes the USB connector signals. AMP manufactures a USB mating connector, part number 787633.
  • Page 38 Figure 3-7 shows the location and pinouts for the PS/2 connector on the NI PXI-8186. Table 3-7 lists and describes the PS/2 connector signals. To connect both a PS/2 keyboard and PS/2 mouse to the NI PXI-8186, use the Y-splitter adapter cable included with your controller (refer to...

  • Page 39: Trigger

    The TRG connector is the software-controlled trigger connection for routing PXI triggers to or from the backplane trigger bus. Figure 3-8 shows the TRG connector location on the NI PXI-8186. Table 3-8 lists and describes the trigger connector signals. NI PXI-8186 Embedded Controller Figure 3-8.

  • Page 40: Gpib (Ieee 488.2)

    I/O Information GPIB (IEEE 488.2) Figure 3-9 shows the location and pinouts for the GPIB connector on the NI PXI-8186. Table 3-9 lists and describes the GPIB connector signals. ITT Canon manufactures a GPIB mating connector, part number MDSM-25SC-Z11-V51. GPIB...

  • Page 41: Front Panel Features

    – The DRIVE LED indicates when an access to the internal hard disk is occurring. Data Storage The NI PXI-8186 has the following data storage features: • Internal IDE hard drive – 2.5 in. notebook hard drive –...

  • Page 42: Common Configuration Questions

    General Questions What do the LEDs on the NI PXI-8186 front panel mean? The green LED indicates the power supplies to/on the NI PXI-8186 are within spec. The supplies monitored are 3.3 V, 5 V, +12 V. The hard drive LED lights when there is hard drive activity on the NI PXI-8186.

  • Page 43: Cables And Connections

    There are some limitations when booting from a USB device. Windows XP can be Note installed from a USB CD-ROM, but earlier versions of Windows cannot. The NI PXI-8186 BIOS configures the USB devices so that they will work in a DOS environment.

  • Page 44: Software Driver Installation

    PS/2 combo connector. However, you cannot use a PS/2 mouse without the Y-splitter, so use a serial or USB mouse. How do I connect a standard 25-pin LPT cable to the NI PXI-8186? The NI PXI-8186 uses a type C LPT connector. Most parallel port devices use a type A connector.

  • Page 45: Chassis Configuration

    Chapter 4 Common Configuration Questions How do I install software from a CD? The compact size of the NI PXI-8186 does not allow for an integrated CD-ROM drive. If you are using Windows XP, you have the following options: •...
  • Page 46 Identify As submenu. Further expanding the PXI System branch shows all devices in the system that can be recognized by NI-VISA. When your controller and all your chassis are identified, the required file is complete. pxisys.ini © National Instruments Corporation NI PXI-8186 User Manual...

  • Page 47: Upgrade Information

    Upgrade Information How do I upgrade system memory? You can change the amount of installed RAM on the NI PXI-8186 by upgrading the DDR SO-DIMM. To upgrade the RAM, remove the NI PXI-8186 from the PXI chassis. Remove the old SO-DIMM module and install the new SO-DIMM in the socket as shown in Figure 4-3.
  • Page 48 Chapter 4 Common Configuration Questions 1 DDR SO-DIMM Module 2 DDR SO-DIMM Socket Figure 4-3. Installing a DDR SO-DIMM in an NI PXI-8186 Controller How do I flash a new BIOS? You need to download the new BIOS from ni.com/support/ .

  • Page 49: Pxi Configuration

    Chapter 4 Common Configuration Questions My NI PXI-8186 does not have an internal floppy drive. Is there a way to use an external drive? Yes. The NI PXI-8186 controller supports and can boot from USB floppy drives. A USB floppy drive will not work with Windows NT4, but will work with Windows 2000 or Windows XP.

  • Page 50: Troubleshooting

    This chapter answers common troubleshooting questions you may have when using the NI PXI-8186 embedded computer. What if the NI PXI-8186 does not boot? Several problems can cause a controller not to boot. Here are some things to look for and possible solutions.
  • Page 51 Remove the controller from the chassis. Move the jumper on W1 from pins 1-2 to pins 2-3 as shown in Figure 5-1. Wait 1 second. Move the jumper back to pins 1-2. Reinstall the controller in the chassis. NI PXI-8186 User Manual ni.com...
  • Page 52 Do not leave the jumper on pins 2-3. Doing so decreases battery life. Also, the Caution controller will not boot. 1 Normal Operation (Default) 2 Clear CMOS Contents 3 Pin 1 Figure 5-1. Clearing the CMOS Contents © National Instruments Corporation NI PXI-8186 User Manual...

  • Page 53: Appendix A Specifications

    Specifications This appendix lists the electrical, mechanical, and environmental specifications of the NI PXI-8186 embedded computer. Electrical Current (A) Voltage (V) Typical Maximum +3.3 6.5 A 0.15 A 0.2 A –12 Physical Board dimensions........PXI 3U-size module 8.1 by 13 by 21.6 cm (3.2 by 5.1 by 8.5 in.)
  • Page 54 Pollution Degree ........2 For indoor or enclosed area use only. Caution Clean the PXI-8186 with a soft nonmetallic brush. Make sure that the device is completely dry and free from contaminants before returning it to service. Storage Environment NI PXI-8186 Ambient temperature range .....–20 to 65 °C (Tested in...
  • Page 55 For UL and other safety certifications, refer to the product label or visit Note , search by model number or product line, and click the ni.com/hardref.nsf/ appropriate link in the Certification column. © National Instruments Corporation NI PXI-8186 User Manual...
  • Page 56 Refer to the Declaration of Conformity (DoC) for this product for any additional Note regulatory compliance information. To obtain the DoC for this product, visit , search by model number or product line, and click the ni.com/hardref.nsf/ appropriate link in the Certification column. NI PXI-8186 User Manual ni.com...
  • Page 57 Technical Support and Professional Services Visit the following sections of the National Instruments Web site at for technical support and professional services: ni.com • Support—Online technical support resources include the following: – Self-Help Resources—For immediate answers and solutions, visit our extensive library of technical support resources available in English, Japanese, and Spanish at .
  • Page 58 You also can visit the Worldwide Offices section of to access the branch ni.com/niglobal office Web sites, which provide up-to-date contact information, support phone numbers, email addresses, and current events. NI PXI-8186 User Manual ni.com...
  • Page 59 Symbols ° Degrees Ω Ohms Percent Amperes Alternating Current ASIC Application-specific integrated circuit Bytes backplane An assembly, typically a printed circuit board, with connectors and signal paths that bus the connector pins © National Instruments Corporation NI PXI-8186 User Manual...
  • Page 60 DRAM Dynamic RAM (Random Access Memory); storage that the computer must refresh at frequent intervals Extended Capabilities Parallel Extended Data Out EEPROM Electronically Erasable Programmable Read Only Memory NI PXI-8186 User Manual ni.com...
  • Page 61 A measure of random vibration; the root mean square of acceleration levels in a random vibration test profile. Hertz; cycles per second Integrated Drive Electronics; hard disk and built-in controller IEEE Institute of Electrical and Electronics Engineers Inches © National Instruments Corporation NI PXI-8186 User Manual...
  • Page 62 A functional part of a PXI device that initiates data transfers on the PXI backplane. A transfer can be either a read or a write. Megabytes of memory MTBF Mean time between failure MTTR Mean time to repair NI PXI-8186 User Manual ni.com...
  • Page 63 NI-DAQ The National Instruments software for data acquisition instruments NI-VISA The National Instruments implementation of the VISA standard; an interface-independent software that provides a unified programming interface for VXI, GPIB, and serial instruments Non-maskable interrupt; high-priority interrupt that cannot be disabled by another interrupt.
  • Page 64 This slot would be used for a module with ST functionality that can provide individual triggers to all other peripherals. Universal Serial Bus Volts Video Graphics Array; the minimum video display standard for all PCs Watts NI PXI-8186 User Manual ni.com...
  • Page 65 (figure), 2-11, 5-3 data storage, 3-12 setting back to default, 5-2 DDR SO-DIMMs COM1 and COM2 connectors from National Instruments (note), 2-14, 4-6 connector locations and pinout (figure), 3-4 installing, 2-14, 4-6 connector signals (table), 3-5 figure, 2-15, 4-7...
  • Page 66 See also configuration Exiting BIOS Setup menu, 2-9 configuration in MAX (figure), 4-5 injector/ejector handle position (caution), 2-2 NI PXI-8186 installed in a PXI chassis files and directories installed on hard (figure), 2-3 drive, 2-13 procedure, 2-1 floppy drive, using external floppy drive, 4-8...
  • Page 67 2-11, 2-12 data storage, 3-12 LabWindows/CVI, 1-5 front panel LEDs, front panel LEDs, 3-12, 4-1 features, 3-12 LPT cable, connecting to NI PXI-8186, 4-3 LEDs, 4-1 system reset pushbutton, 3-12 front panel dimensions, 3-2 functional overview, 1-2 Main Setup menu, 2-5...
  • Page 68 PXI features, 2-14 switches PXI Setup menu, 2-8 LabVIEW RT configuration, 2-11 PXI trigger connectivity, 2-14 LabVIEW RT configuration PXI-8220, using NI PXI-8186 with, 4-8 (figure), 2-12 file, 4-4 pxisys.ini system CMOS, 2-10 system reset pushbutton, 3-12 DDR SO-DIMMs from National...
  • Page 69 4-3 connector function, 1-4 using mouse and keyboard without, 4-3 connector location and pinout (figure), 3-8 using with PS/2 mouse and keyboard, 2-3, 3-9 connector signals (table), 3-8 overview (table), 3-1 © National Instruments Corporation NI PXI-8186 User Manual...
