Summary of Contents for Plustek 783064365338
- Page 1 Installation Usage & Maintenance Troubleshooting...
- Page 2 Trademarks © 2019 Plustek Inc. All rights are reserved. No portion of this document may be reproduced without permission. All trademarks and brand names mentioned in this publication are property of their respective owners. Liability While all efforts have been made to ensure the accuracy of all contents in this...
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION ..........................1 ........................1 OW TO UIDE ......................1 ONVENTIONS OF UIDE ..........................2 OTE ABOUT CONS ..........................2 AFETY RECAUTIONS ........................3 YSTEM EQUIREMENTS ............................4 ONTENTS ’ ........................5 CANNER EATURES .............................6 OLDERS ............................8 OWER .............................8 AINTENANCE CHAPTER I. INSTALLING THE SCANNER ...................9 ..................9 OFTWARE NSTALLATION... -
Page 4: Introduction
Introduction Welcome to the world of Plustek scanners – the ultimate in computer imaging. Your new scanner will improve the professionalism of your day-to-day computing tasks by allowing you to input images into your computer system. Like all of our products, your new scanner is thoroughly tested and backed by our reputation for unsurpassed dependability and customer satisfaction. -
Page 5: A Note About Icons
A Note about Icons This guide uses the following icons to point out information that deserves special attention. Danger: A procedure that must be followed carefully to prevent injury, or accidents. Danger Caution: Information that, if not followed, may result in Caution data loss or damage to the product. -
Page 6: System Requirements
Be sure not to bump or knock the scanner as it is fragile and could break. Before installing the device drivers, please disconnect all other imaging devices (other scanners, printers, digital cameras, web cameras) from the PC. Save the Setup/Application CD, the SilverFast DVD and DVD-ROM case. You may need to reinstall the driver and software in the future. -
Page 7: Box Contents
Box Contents Scanner Padded carrying bag Mounted Slide Holder and Filmstrip Holder USB Cable Power Adapter Quick Guide LaserSoft SilverFast DVD-ROM & Serial Number Setup / Application CD-ROM 35 mm IT-8 Target (35 mm IT-8 Target is not included in all scanner models) The SilverFast serial number is located on the front of the SilverFast DVD-ROM case. -
Page 8: The Scanner's Features
The Scanner’s Features Film Holder Slot: Insert the film holder into the scanner through dust cover. The film holder can be inserted from either side. The film holder will index at each frame using the notches on its side rails. Power LED: It indicates the scanner status. -
Page 9: Film Holders
Film Holders Two film holders are included in the package. They guarantee correct scanning results. A. For scanning 35mm mounted slides (max. 4 slides) B. For scanning 35mm filmstrips (max. 6 frames) Using Mounted Slide Holder Insert mounted slides into slots with emulsion (non-glossy) side down. There are arrows and illustrations on the frame of each slot. - Page 10 For correct scan results, always turn the film with the top of the image facing towards the back of the scanner (where Attention power cord and USB cord are located) and keep emulsion (non-glossy) side down. There is text on the top and bottom of the film, such as manufacturer, frame numbers, film codes, batch numbers...etc.
-
Page 11: Power Save
Power Save To save power consumption, the scanner light source always automatically turns itself off after the scanning process is finished. Maintenance To keep your scanner working smoothly, take a moment to review the following maintenance tips. Caution Avoid using the scanner in a dusty environment. When it is not in use, keep the scanner covered. -
Page 12: Chapter I. Installing The Scanner
Chapter I. Installing the Scanner Before installing your scanner, please verify that you have all of the proper components. A list of the package contents is provided in the Box Contents section of this guide. Software Installation Requirements Your scanner comes with the scanner’s driver, QuickScan Setting and LaserSoft SilverFast software. -
Page 13: Windows Installation
Windows Installation Installing and Setting up the Scanner Please follow the step-by-step procedures described below to install the USB scanner. Step 1. Connecting the Scanner to Your Computer Plug the power adapter into the scanner’s power receptor. Plug the other end of the power adapter into a standard AC power outlet. Plug the square end of the included USB cable to the USB port at the rear of the scanner. - Page 14 Step 2. Installing the Software 1. Insert the Setup/Application CD-ROM, included with your scanner, into your CD-ROM drive. Click [Run install.exe] in the [AutoPlay] window. If the installation does not start automatically, browse your CD-ROM drive and manually run the [install.exe] file. 2.
- Page 15 After software installed, close open applications and click on the [Finish] button to restart your computer. You will find a new QuickScan icon if the installation was successful. The QuickScan icon , located on the Windows system tray, indicates if the scanner software is properly launched and the scanner and computer are communicating with each other.
- Page 16 Manually Installing the Software 1. Insert the Setup/Application CD-ROM, included with your scanner, into your CD-ROM drive. Click [Run install.exe] in the [AutoPlay] window. If the installation does start automatically, browse your CD- ROM drive and manually run the [install.exe] file. Click on the [Yes] button if the [User Account Control] dialog pops up.
-
Page 17: Software Setup Troubleshooting
Follow on-screen instructions to install all software that your new USB scanner requires. 5. After the software is installed, close all open applications and click on the [Finish] button to restart your computer. Software Setup Troubleshooting Carefully review the steps outlined in this guide and the Quick Installation Guide that accompanied your scanner. -
Page 18: Installing Silverfast Software Under Windows
Installing SilverFast Software under Windows Your scanner comes with the advanced and feature rich scanning application SilverFast. Please insert the SilverFast DVD into your optical drive and click on [Run xxxx.exe] to launch the installation assistant, then follow below illustrated guide to install the application: Follow on-screen... - Page 19 4. After the installation finishes, please activate the option you wish to execute, then click on [Finish] to exit the installer. 5. Launch the SilverFast program using the SilverFast shortcut on your Desktop. Verify your [Image Source] and [Language selection], then click on [Start] to launch the program.
-
Page 20: Mac Os X Installation
Mac OS X Installation You do not have to install any scanner drivers when installing the scanner under Mac OS. The scanner drivers are already Attention included within the SilverFast installation. Your scanner comes with the advanced and feature rich scanning application SilverFast. - Page 21 4. After the installation finishes, click on [Close] to exit the installer. 5. Launch the SilverFast launcher using the SilverFast shortcut on your Desktop. Verify your [Image Source] and [Language selection], then click on [Start] to launch the program. 6. Once the program has been launched, enter your [First name], [Last name] and [Serial number], then click on [Unlock] to unlock...
-
Page 22: Chapter Ii. Operating The Scanner
Chapter II. Operating the Scanner Your scanner accepts 35mm slides and negatives. However, some software programs have limitations as to the information they can handle. The capacity of the computer’s memory and free space on your hard drive can also limit the physical size of the document that you scan. -
Page 23: Using Quickscan Button
For detailed settings and features about SilverFast, please refer to SilverFast User’s Manual. Attention Using QuickScan Button The QuickScan button enables you to conveniently scan images and save them automatically to the album. Simply press the QuickScan button on the front of your scanner and the scanner will start scanning your transparencies or negatives. - Page 24 [Auto Crop] feature will apply automatically if [Auto Density] feature is checked. Select [Scanning Attributes] options: You can alter scanning [Mode], [Resolution], [Filter], [Brightness], [Contrast] and [Gamma] settings. Click the [Default] button if you desire to return to the default settings. Click the [Close] button to save the final settings and exit the [QuickScan Setting] window.
- Page 25 Auto Crop When this box is checked, the QuickScan program will identify the dimensions of the image you scanned and crop around the edges. The crop shape will be a square or rectangle and it will not trace the edges of oddly-shaped images. Auto Density Checking this box automatically adjusts the Histogram to make the scanned image clearer.
- Page 26 Preview window This window is only operational if [Enable] and [Confirm] are both checked in [Preview] section. It will open when you press the QuickScan button. Source - Tells the scanner the method you will use to scan images. • Transparency - Use this mode for scanning transparency films. •...
- Page 27 Resolution - Resolution is measured in dots per inch (dpi). The higher the resolution, the more detailed the image, and the more memory and drive space the image will use. Filter - Filters help you improve your scans by allowing you to sharpen images as well as remove excessive dots and distortion.
-
Page 28: Chapter Iii. Basic Scanning
Chapter III. Basic Scanning The QuickScan program allows you to scan many mounted slides or filmstrips in quick succession without having to deal with a complicated user interface or settings every time. The following step-by-step instructions serve as a simple guide for that purpose. -
Page 29: Step 3. Insert The Film Holder
Step 3. Insert the Film Holder Insert the film holder into the scanner through dust cover. The film holder can be inserted from either side. The film holder will index at each frame using the notches on its side rails. Please allow about 40 cm of space on both sides of the scanner to insert and remove the film holder. -
Page 30: Step 4. Press The Quickscan Button
Step 4. Press the QuickScan Button Please make sure the mounted slide or film holder is in an indexed position to ensure proper scan results. Press the QuickScan button to commence scanning. Step 5. Configure QuickScan Settings If you have checked [Enable] and [Confirm] in the [Preview] section of the QuickScan Settings window, a preview window will be opened where you can readjust some of the settings to your needs. -
Page 31: Appendix A: Troubleshooting
Appendix A: Troubleshooting Scanner Connection The first step to take when troubleshooting connection problems with your scanner is to check all physical connections. The QuickScan icon , located on the Windows system tray, indicates if the scanner software is properly launched and the scanner and computer are communicating with each other. -
Page 32: Scanning Problems
If you prefer not to see this reminder message again, you may: Check the box of [Do not show this message again] within this message window, and then click [OK] button. Click on the QuickScan icon located on the Windows system tray. Uncheck [Enable Warning] from the menu that pops up. - Page 33 The scanned image Your video mode is not set to show more than 256 looks grainy on the colors screen We recommend that you set your video mode to 16 bits per pixel (65536 colors) or higher. Please consult your video card, computer or Windows documentation to change the video mode.
- Page 34 A “Disk is full” Your computer is running low in resources. Your error is displayed computer hard disk drive does not have enough space when I click on the to process the image. This may be because you are scan button scanning at too high of a resolution Obtain a larger hard disk or rescan at a lower resolution.
-
Page 35: Appendix B: Specifications
Appendix B: Specifications OpticFilm 8100 Image Sensor Light Source Hardware Resolution 7200 dpi Color: 48-bit input, 24/48-bit output Scan Modes Grayscale: 16-bit input, 8/16-bit output B/W: 1-bit Dynamic Range 3600 dpi: Approx. 36 sec (Multi-Sampling ON) Scanning Speed 7200 dpi: Approx. 113 sec (Multi-Sampling ON) Scanning Area (W x L) 36.8 mm x 25.4 mm (1.45"... - Page 36 OpticFilm 8200i SE Image Sensor Light Source Hardware Resolution 7200 dpi Color: 48-bit input, 24/48-bit output Scan Modes Grayscale: 16-bit input, 8/16-bit output B/W: 1-bit Dynamic Range Infrared Built-in 3600 dpi: Approx. 36 sec (Multi-Sampling ON) Scanning Speed 7200 dpi: Approx. 113 sec (Multi-Sampling ON) Scanning Area (W x L) 36.8 mm x 25.4 mm (1.45"...
- Page 37 OpticFilm 8200i Ai Image Sensor Light Source Hardware Resolution 7200 dpi Color: 48-bit input, 24/48-bit output Scan Modes Grayscale: 16-bit input, 8/16-bit output B/W: 1-bit Dynamic Range Infrared Built-in 3600 dpi: Approx. 36 sec (Multi-Sampling ON) Scanning Speed 7200 dpi: Approx. 113 sec (Multi-Sampling ON) Scanning Area (W x L) 36.8 mm x 25.4 mm (1.45"...
-
Page 38: Appendix C: Customer Service And Warranty
If you encounter problems with your scanner, please review the installation instructions and troubleshooting suggestions contained in this guide. Visit our website www.plustek.com for more customer service information. For further assistance call our customer support phone number listed on the website. One of our... -
Page 39: Statement Of Limited Warranty
If you have any maintenance inquiry, please ask local distributors and suppliers to get the contact information of nearest maintenance center in order to extend the product usage life time. If you want to maintain and clearance the product, please ask local distributors and suppliers to get the right information of nearest stores. -
Page 40: Fcc Radio Frequency Statement
Under no circumstances are we liable for any of the following: Third party claims against you for losses or damages. Loss of, or damage to, your records or data; or Economic consequential damages (including lost profits or savings) or incidental damages, even if we are informed of their possibility.
