- Page 1 Next >> << Previous Installing Your Multifunction to Your Network for the First Time PIXMA MG4220 Macintosh OS...
- Page 2 << Previous Next >> Installing Your Multifunction to Your Network for the First Time PIXMA MG4220 Windows OS Preparing to Connect My Multifunction to My Network Network Requirements Notes on Wireless Connection Installing the Drivers...
-
Page 3: Preparing To Connect My Multifunction To My Network
Preparing to Connect My Multifunction << Previous Next >> To My Network Network Requirements Before connecting the machine to the network, make sure that configuration of the computer and access point or router is complete, and that the computer is connected to the network. Wireless Connection Before connecting the machine to the network, the computer needs to be connected to the network. - Page 4 Preparing to Connect My Multifunction << Previous Next >> To My Network An "Ad-hoc connection," which establishes a direct connection to the computer over a wireless connection without using an access point, is not supported. Notes on Network Connection • The configuration, router functions, setup procedures and security settings of the network device vary depending on your system environment.
-
Page 5: Installing The Drivers & Software
Setup CD-ROM during restarting. The installation resumes once your computer has restarted. • If the firewall function of your security software is turned on, a warning message may appear that Canon software is attempting to access the network. If such a warning message appears, set the security software to always allow access. - Page 6 Installing the Drivers << Previous Next >> Installing the PIXMA MG4220 on Your Wireless Network If you are installing your printer on your network for the first time, a step-by-step walk through of the wireless setup is built in to the installation routine of the software that shipped with your PIXMA. Simply insert the Setup CD-ROM that came with your printer into your CD-ROM drive and proceed through the easy to follow instructions.
- Page 7 Installing the Drivers << Previous Next >> 1. Insert the CD-ROM into the computer. IMPORTANT If the USB cable is already connected, unplug it. If a message appears on the computer, click Cancel. 2. Double-click the [Setup] icon in the CD-ROM folder, then click [Download] in the subsequent window.
- Page 8 Installing the Drivers << Previous Next >> REFERENCE •When the CD-ROM folder does not open automatically, double-click the CD-ROM icon displayed on the desktop. •The screen below is displayed while downloading.
- Page 9 Installing the Drivers << Previous Next >> If you click [Cancel] while downloading, you will see the following screen. - If you click [No], you will return to the screen displayed while downloading. - If you click [Yes], the download is cancelled. In this case, the files under the download are deleted. When the download fails, the screen below is displayed.
- Page 10 Installing the Drivers << Previous Next >> 3. When the download is complete, the screen below is displayed. Click [Next]. REFERENCE Select "Save a file for setting up the software again to the download folder after the installation is complete," and the file will be saved to the download folder.
- Page 11 Installing the Drivers << Previous Next >> You can perform the setup later using this file. 4. In the subsequent screen, enter the administrator name and password. Then click [OK].
- Page 12 Installing the Drivers << Previous Next >> 5. Click Next 7. Follow any instructions and Click Connect to the Network when the Printer Setup window appears . 6. Click Wireless Connection for Connection Method. 8. Follow any instructions. Pay particular attention to the instruction in the Setup Procedure Selection if setup detects a WPS access point.
- Page 13 Next displayed. Network connection setting is complete. Click Next *MP Drivers and Canon IJ Network Tool which are pre-selected are required for wireless network connection. We recommend also installing ScanGear and Quick Menu to enjoy all the features of the...
- Page 14 Installing the Drivers << Previous Next >> Add the Printer 1. Click Add Printer on the Add Printer Screen...
- Page 15 -The computer is connected to the access point. CAUTION If you will be installing the Canon printer driver on Mac OS X and using the printer through a network connection, you can select [Bonjour] or [Canon IJ Network] in the [Add Printer] dialog.
- Page 16 Installing the Drivers << Previous Next >> 4. Click Next. 5. Click Next. Setup is complete...
- Page 17 Installing the Drivers using downloaded files << Previous If you can’t find your CD-ROM, you can set up the printer by downloading and installing the MG4200 series Mini Master Setup, which includes the same step-by-step installation as the CD-ROM. Follow the instructions below: Click here to access the MG4220 Drivers &...
- Page 18 Installing the Drivers using downloaded files << Previous 5. Once the download is complete, double-click the file from its download location to begin the installation. 6. Click the Setup icon beginning with Step 5. Follow the same instructions as installing from the CD-ROM...
