Summary of Contents for LG 23LRB
- Page 1 Test Report No.: GETEC-E3-06-025 FCC Class B Certification APPENDIX H : USER’S MANUAL EUT Type: 23” LCD TV/Monitor FCC ID: BEJ23LRB...
- Page 2 LCD TV OWNER’S MANUAL MODELS: 23LC1R Internet Home Page : http://www.lge.com http://www.lg.ca ENERGYSATR is a set of power-saving Please read this manual carefully before operating guidelines issued by the U.S. your set. Environmental Protection Agency(EPA). Retain it for future reference.
-
Page 3: Note To Cable/Tv Installer
CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics Corporation. Unauthorized modification could void the user’s authority to operate this product. U.S.A. only ----------------------------------------------- COMPLIANCE: The responsible party for this product’s compliance is:... -
Page 4: Important Safety Instructions
Safety Instructions Safety Instructions Safety Instructions WARNING : To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or Moisture. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. - Page 5 Safety Instructions Safety Instructions continued Safety Instructions continued 12. Use only with a cart, stand, tripod, bracket, or 14. Refer all servicing to qualified service per- table specified by the manufacturer, or sold sonnel. Servicing is required when the with the apparatus. When a cart is used, use apparatus has been damaged in any way, caution when moving the cart / apparatus such as power supply cord or plug is dam-...
- Page 6 Introduction Introduction Introduction Controls Controls ENTER MENU INPUT On/Off Button Enter Input Button Volume Button Channel Buttons Menu Buttons Button Remote Control Sensor Power/Standby Indicator Glows amber in Standby mode, Glows blue when the TV is turned on.
-
Page 7: Connection Options
Introduction Connection Options Connection Options VIDEO IN2 VIDEO INPUT AUDIO INPUT ANTENNA PC SOUND INPUT PC INPUT JACK INPUT COMPONENT (DTV/DVD IN) AUDIO PC INPUT ANT IN ( 75 ) PC SOUND AC INPUT S-VIDEO VIDEO IN1 AC INPUT S-VIDEO INPUT COMPONENT (DTV/DVD IN) ((480i/480p/720p/1080i), Audio) -
Page 8: Installation
Installation Installation Installation Accessories Accessories Tie Holder Owner’s Manual AAA Batteries Power Cord - Arrange the wires Remote Control with the tie Holder. 2-TV 1-TV Bracket, Audio cable (PC) D-sub cable (PC) 2-Wall Bracket Bracket Bolts Installation Rack Fixing screw 4-Screws for wall 4-Anchor guide... -
Page 9: Please Set It Up Carefully So The Product Doesn't Fall Over
Installation Please set it up carefully so the product Please set it up carefully so the product doesn’t fall over doesn’t fall over Set it up close to the wall so the product doesn’t fall over when it is pushed back- wards. -
Page 10: External Equipment Connections
Installation External Equipment Connections External Equipment Connections Antenna Connection Antenna Connection - For optimum picture quality, adjust antenna direction. Connecting to an Inside Antenna Setup - Typical wall antenna jack used in apartment buildings, connect the antenna cable as shown below. (Use the correct type of antenna cable for the type of wall antenna jack.) Turn clockwise to tighten. - Page 11 Installation DTV Setup DTV Setup COMPONENT (DTV/DVD IN) AUDIO PC INPUT ANT IN ( 75 ) PC SOUND - To watch digitally broadcast programs, purchase and con- nect a digital set-top box. S-VIDEO VIDEO IN1 Connections Connect the digital set-top box video outputs to the COM- PONENT (Y, P ) jacks and connect the digital set-top box audio outputs to the AUDIO jacks.
-
Page 12: Pc Menu Options
Operation PC Menu Options PC Menu Options - After setup, be sure to select PC source to see the PC image on TV screen. H-Position V-Position Clock Phase Auto Configure Reset OK MENU 1. Press the MENU button and then use button to select the menu. -
Page 13: Maintenance
Maintenance Maintenance Maintenance Maintenance - Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you will have your new TV. Be sure to turn the power off and unplug the power cord before you begin any cleaning. -
Page 14: Troubleshooting Checklist
Troubleshooting Checklist roubleshooting Checklist roubleshooting Checklist The operation does not work normally. • Check to see if there is any object between the product and the remote control causing obstruction. The remote control • Are batteries installed with correct polarity (+ to +, - to -)? doesn’t work •... - Page 15 Troubleshooting Checklist The audio function does not work. • Press the VOL (or Volume) button. Picture OK & • Sound muted? Press MUTE button. No sound • Try another channel. The problem may be with the broadcast. • Are the audio cables installed properly? No output from •...
-
Page 16: Product Specifications
Product Specifications Product Specifications Product Specifications Product Specifications Power Requirement/ AC100-240V~ 50/60Hz 1.1A Power Consumption 100W Dimensions including stand 611.6mm x 485.2mm x 272.7mm 24.0inches x 18.0inches x 10.7inches (Width x Height x Depth) excluding stand 611.6mm x 450.1mm x 111.5mm 24.0inches x 17.7inches x 4.3inches including stand 10.8kg (23.8lbs)
