LCD TV
OWNER'S MANUAL
LCD TV MODELS
20LS7D
20LS7DC
23LS7D
23LS7DC
Please read this manual carefully before operating
your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote
this information to your dealer
when you require service.
