- Page 1 BC2604DL BC2604DW BC2604DL / BC2604DW 848JB593A1 (704) OWNER’S MANUAL BRUSHCUTTERS GB-1...
- Page 2 BC2604DL / BC2604DW EXPLANATION OF SYMBOLS AND SAFETY WARNINGS MODEL BC2604DL 25.4 cm BC2604DW 25.4 cm APPROVAL NUMBER OF CE EXHAUST EMISSION REGULATION GB-2 ZENOAH CO., LTD. BC2604DL BC2604DW 1st April 2007 Masahiko GOUDA WARNING!!! RISK OF DAMAGING HEARING Wear head, eye and ear protection.
-
Page 3: Table Of Contents
4. Symbols on the machine ... 5 5. For safe operation ... 6 6. Set up ... 9 7. Fuel ... 10 8. Operation ... 11 9. Maintenance ... 13 10. Storage ... 15 11. Troubleshooting guide ... 16 BC2604DL BC2604DL / BC2604DW BC2604DW GB-3... -
Page 4: Specifications
According to these indications, please be careful not to make a mistake. GB-4 (when using ZENOAH genuine oil) Never modify your machine. We won’t warrant the machine, if you use the remodeled brushcutter or if you don’t observe the proper usage written in the manual. - Page 5 2. Never use the product, a. when the ground is slippery or when you can’t maintain a steady posture. BC2604DL / BC2604DW b. At night, at times of heavy fog, or at any other times when your field of vision might be...
-
Page 6: For Safe Operation
BC2604DL / BC2604DW 5. For safe operation BEFORE STARTING THE ENGINE 1. The area within a perimeter of 15 m of the person using the product should be considered a hazardous area into which no one should enter. If necessary, yellow... - Page 7 BC2604DL / BC2604DW HANDLING FUEL 1. The engine of the ZENOAH prod- uct is designed to run on a mixed fuel, which contains highly flam- mable gasoline. Never store cans...
-
Page 8: Set Up
2. Put the handle assembly into the bracket and put the upper cap over it. Tighten the cap securely. CONNECTING THROTTLE WIRE (BC2604DW) 1. Remove the air cleaner cover. 2. Connect the end of the throttle wire to the joint on the top of the carburetor. -
Page 9: Fuel
3 m (10 ft) away from the fueling point before starting the engine. • The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant... -
Page 10: Operation
BC2604DL / BC2604DW 8. Operation STARTING ENGINE WARNING The cutting head will start rotating upon the engine starts. 1. Feed fuel into the fuel tank and tighten the cap se- curely. 2. Rest the unit on a flat, firm place. Keep the cutting head off the ground and clear of surrounding objects, as it will start rotating upon starting of the engine. - Page 11 • Replace by a suitable recommended cutting attach- ment according to the object to be cut. • When replacing blade always be sure to use products which have been certified by ZENOAH. WARNING • When sharpening, removing, or reattaching the blade, be sure to wear thick, sturdy gloves and use only proper tools and equipment to prevent injury.
- Page 12 BC2604DL / BC2604DW 8. Operation CUTTING METHOD (a)Use the front left side cutting. (b) Guide the blade from your right to left with it tilted slightly to your left. (c) When mowing a wide area, start working from your left end to avoid interference of cut grass.
- Page 13 1. Hold the unit so the head is off the ground and is tilted about 20 degrees toward the sweep direction. BC2604DL / BC2604DW 2. You can avoid thrown debris by sweeping from your left to the right.
-
Page 14: Maintenance
BC2604DL / BC2604DW 9. Maintenance 9. Maintenance System/components fuel leaks, fuel spillage fuel tank, air filter, fuel filter idle adjusting screw spark plug cylinder fins, intake air cooling vent muffler, spark arrester, cylinder exhaust port throttle lever, ignition switch cutting parts... -
Page 15: Storage
Before storing the unit, empty the fuel tank and run the engine until it uses all the fuel left in the fuel line and the carburetor. Store the unit indoor taking necessary measures for rust prevention. BC2604DL / BC2604DW GB-15... -
Page 16: Troubleshooting Guide
(exhaust port) air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
