- Page 1 32” CLASS RAZOR LED LCD HDTV ™ E321MV – user manual...
- Page 2 SRS TruSurround HD and SRS TruVolume are trademarks of SRS Labs, Inc. TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc. This product qualifies for ENERGY STAR in the “factory default” setting and this is the setting in which power savings will be achieved.
- Page 3 Thank You for Choosing VIZIO And congratulations on your new VIZIO HDTV. To get the most out of your new VIZIO product, read these instructions before using your product and retain them for future reference. Be sure to inspect the package contents to ensure there are no missing or damaged parts.
- Page 4 • Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of your TV and to protect it from overheating, be sure these openings are not blocked or covered. Do not place your TV in a bookcase or cabinet unless proper ventilation is provided. • Never push any object into the slots and openings on your TV cabinet. Do not place any objects on the top of your TV. Doing so could short circuit parts causing a fire or electric shock. Never spill liquids on your • Your TV should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. • Do not apply pressure or throw objects at your TV. This may compromise the integrity of the display. The manufacturer’s warranty does not cover user abuse or improper installations. • The power cord must be replaced when using different voltage than the voltage specified. For more information, contact your dealer. • Your TV is equipped with a three-pronged grounded plug (a plug with a third grounding pin). This plug will fit only into a grounded power outlet. This is a safety feature. If your outlet does not accommodate the three-pronged, have an electrician install the correct outlet, or use an adapter to ground your TV safely. Do not defeat the safety purpose of the grounded plug. • When connected to a power outlet, power is always flowing into your TV. To totally disconnect power, unplug the power cord. • The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of un-isolated, dangerous voltage within the inside of your TV that may be of sufficient magnitude to constitute a risk of electric shock to persons. E321MV...
- Page 5 E321MV • Do not overload power strips and extension cords. Overloading can result in fire or electric shock. • The wall socket should be installed near your TV and easily accessible. • Only power of the marked voltage can be used for your TV. Any other voltage than the specified voltage may cause fire or electric shock. • Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power cord during electrical storms. • Unplug your TV during a lightning storm or when it will not be used for long period of time. This will protect your TV from damage due to power surges. • Do not attempt to repair or service your TV yourself. Opening or removing the back cover may expose you to high voltages, electric shock, and other hazards. If repair is required, contact your dealer and refer all servicing to qualified service personnel. • WARNING: Keep your TV away from moisture. Do not expose your TV to rain or moisture. If water penetrates into your TV, unplug the power cord and contact your dealer. Continuous use in this case may result in fire or electric shock. • Do not use your TV if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your dealer immediately. Do not try to repair your TV yourself. • Avoid using dropped or damaged appliances. If your TV is dropped and the housing is damaged, the internal components may function abnormally. Unplug the power cord immediately and contact your dealer for repair. Continued use of your TV may cause fire or electric shock. • Do not install your TV in an area with heavy dust or high humidity. Operating your TV in environments with heavy dust or high humidity may cause fire or electric shock.
- Page 6 Antenna Lead In Wire List of US Television Stations: www.high-techproductions.com/usTVstations.htm Antenna Discharge Unit (NEC Section 810-20) Grounding Conductors (NEC Section 810-21) Ground Clamps Your TV comes with a built-in tuner capable of processing digital broadcasts. No extra converter box is needed. E321MV...
-
Page 7: Table Of Contents
Setting the Date and Time ... 17 Adjusting the TV Settings for Use with A PC ... 18 Turning the VIZIO Light On or Off ... 18 Using the Other Menu Settings ... 19 Navigating the On-Screen Menu ... 19 Setting the Sleep Timer ... - Page 8 Personal Data ... 36 Zero Bright Pixel Defect Guarantee ... 36 Legal & Compliance ... 37 FCC Class B Radio Interference Statement ... 37 Notice ... 37 FCC warning ... 37 Caution ... 37 Open Source Software Notice ... 37 E321MV...
-
Page 9: Installing The Tv
Before installing your new TV, take a moment to inspect the package contents. Use the images below to ensure nothing is missing or damaged. When you have completed your inspection, install the TV. VIZIO LCD HDTV with Stand User Manual and Quick Start Guide... -
Page 10: Installing The Tv On A Wall
1. Disconnect any cables connected to your TV. 2. Place the TV face-down on a clean, flat, stable surface. Be sure the surface is clear of debris that can scratch or damage the TV. E321MV E321MV 15mm 200mm x 200mm... - Page 11 E321MV 3. Turn the attached thumbscrew until it is completely loosened. 4. Gently remove the stand neck. 5. Attach your TV and wall mount to the wall, carefully following the instructions that came with your mount. Use only with a UL-listed wall mount bracket rated for the weight/load of...
-
Page 12: Controls And Connections
Rear Panel Cable/Antenna 3.5mm PC Audio In HDMI (1,2,3): Connect HDMI devices. Component: Connect component device. Composite: Connect composite device. 3.5mm Stereo Out: Connect 3.5mm audio device. Cable/Antennal: Connect RF/Coaxial connector from cable, antenna, or HDMI (1,2,3) Component Optical Digital Composite RGB PC 3.5mm Stereo... -
Page 13: Right Side Panel
VIZIO Light Menu Channel Up Remote Control Sensor: When using the remote, point it directly at this Channel Down VIZIO Light: This light is white when the TV is on. Volume Up Volume Down Input Right Side Panel Remote Control... -
Page 14: Remote Control
Dash (-) Number Pad: Use the number pad to manually enter a Dash (-): Use with number pad to manually enter a Wide: Switch between display modes. Remote Control E321MV devices only). guide. only). tions. Change the channel. With each press of the button, the channel will increase or decrease by one. -
Page 15: Table Of Contents
E321MV Replacing the Batteries 1. Remove the battery cover by pressing gently on the “V” and pushing the cover away from the remote. 2. Insert two AAA batteries into the remote control. Make sure that the (+) and (-) symbols on the batteries match the (+) and (-) symbols inside the battery compartment. -
Page 16: Connecting Your Devices
Your HDTV can be easily connected to an external device: • DVD or Blu-Ray player • Video game console • Cable box • External antenna • Or other device Before You Begin To connect a device to the HDTV: 1. Verify that the device has one of the following types of video ports available: HDMI Component... - Page 17 E321MV Select one of the connection types. Use the cable(s) shown to connect the TV to your device. BEST BETTER GOOD HDMI COAXIAL COMPONENT COMPOSITE Select One: DIGITAL DIGITAL / ANALOG ANALOG ANALOG ANALOG Device Connection Chart...
-
Page 18: Completing The First-Time Setup
The first time you turn on the TV, the Setup App will guide you through each of the steps necessary to get your TV ready for use. Before you begin the first-time setup: • Your TV should be installed and the power cord should be connected to an electrical outlet. • Have your remote ready. Ensure the batteries are inserted. • Your devices should be connected. To complete the first-time setup: 1. -
Page 19: Adjusting The Tv Settings
• Change the on-screen menu language • Change the TV’s date and time • Adjust the TV settings for use with a PC • Turn the VIZIO light on or off Navigating the On-Screen Menu To open the on-screen menu, press the OK or MENU button on the remote. Use the Arrow buttons to highlight a menu option, and press the OK button to select that option. -
Page 20: Customizing Input Names
7. Use the Arrow and OK buttons to spell the custom input name. When you are finished, highlight OK and press OK. 8. Press EXIT. Setting Up Channels From the channel menu you can: • Change the signal source • Start a new channel scan • Scan for new/additional channels • Remove channels from the master list • Change the audio language • Customize channel names E321MV... -
Page 21: Changing The Signal Source
E321MV Changing the Signal Source Using this option, you can change the signal source for the coaxial (TV) input. To change the signal source: 1. Press the MENU button on the remote. The on-screen menu is displayed. 2. Use the Arrow buttons on the remote to highlight the TV icon and press OK. -
Page 22: Scanning For New Or Additional Channels
To add all available channels to the list, highlight Mark All and press OK. To remove all available channels from the list, highlight Unmark All and press To include only digital channels in the list, highlight Skip Analog Only and press OK. 6. Press EXIT. E321MV... -
Page 23: Changing The Audio Language
E321MV Changing the Audio Language Some digital free-to-air and cable channels broadcast programs in more than one language. The TV’s MTS (Multichannel Television Sound) feature allows you to listen to audio in your preferred language. Not all programs are broadcast in multiple languages. The MTS feature only works when the program being viewed is being broadcast in the language you select. -
Page 24: Changing The On-Screen Menu Language
3. Use the Arrow buttons to highlight Date & Time and press OK. 4. Use the Arrow buttons to highlight Time Zone and press OK. 5. Use the Arrow buttons to highlight your time zone and press OK. 6. Press EXIT. E321MV... -
Page 25: Adjusting The Time For Daylight Savings
E321MV Adjusting the Time for Daylight Savings When enabled, this setting will automatically adjust the time for zones which recognize daylight savings time. To enable or disable the daylight savings adjustment: 1. Press the MENU button on the remote. The on-screen menu is displayed. -
Page 26: Adjusting The Tv Settings For Use With A Pc
Auto Sync and press OK. Turning the VIZIO Light On or Off This setting allows you to turn off the back-lit VIZIO logo on the front bezel of your To turn the VIZIO Light on or off: 5. Press the MENU button on the remote. -
Page 27: Using The Other Menu Settings
Using the Other Menu Settings Your TV features an easy-to-use on-screen menu. Using this menu, you can: • Set the sleep timer • View a USB photo slideshow • Set the screen aspect ratio • Adjust the audio settings • Adjust the picture settings • Adjust the parental controls • Get system info or reset to factory defaults • Set up closed captions Navigating the On-Screen Menu To open the on-screen menu, press the OK button on the remote. -
Page 28: Viewing A Usb Photo Slideshow
• Sort by - Change the display order of photos. Choose Original, Title .jpeg A-Z, Title Z-A, Oldest First, or .jpg Newest First. • View - Choose Folders (individual folders and their contents), Favorites, or All. • Slide Settings - Change the slideshow settings. Available options are Repeat, Shuffle, Full Screen (this may distort some photos to fill the screen), and Speed (Slow or Fast). • Picture Settings - Change the display settings. See Adjusting the Picture Settings on page 25. • Thumbnail Size - Move the on-screen slider to change the size of displayed thumbnail images. Choose Large or Small. E321MV... -
Page 29: Using The Modify Photo Menu
E321MV Using the Modify Photo Menu This menu allows you to zoom in and out, mark your favorite photos, rotate photos, and see your image metadata. To open the Modify Photo menu: 1. When you are viewing a photo in fullscreen, press the OK button on the remote. -
Page 30: Screen Aspect Ratio Table
E321MV Screen Aspect Ratio Table Original Content Format 480p/480i (4:3) 720p (16:9) 1080p/1080i (16:9) RGB (4:3) RGB (16:9) Normal Wide Zoom Panoramic Stretch... -
Page 31: Adjusting The Audio Settings
E321MV Adjusting the Audio Settings Using the Audio Settings menu, you can adjust the following: • Enable or disable SRS TruSurround HD ™ • Enable or disable SRS TruVolume ® • Adjust the equalizer settings • Adjust speaker balance • Enable or disable the built-in speakers • Select the digital audio output mode • Adjust bass and treble levels • Reset the audio settings Enabling or Disabling SRS TruSurround HD... -
Page 32: Adjusting The Speaker Balance
TV. If you are unfamiliar with audio formats, or your TV is not connected to an audio receiver, VIZIO recommends you set this option to Auto. This option only affects audio output from the optical port. -
Page 33: Adjusting Bass And Treble Levels
E321MV Adjusting Bass and Treble Levels The bass and treble levels for your TV’s built-in speakers can be adjusted to your liking. To adjust the bass and treble levels, SRS TruSurround HD must be set to Off. To adjust the bass and treble levels: 1. -
Page 34: Changing The Picture Mode
2. Use the Arrow buttons to highlight Picture and press OK. 3. Use the Arrow buttons to highlight Noise Reduction and press 4. Use the Arrow buttons to highlight Off, Low, Medium, or High, then press 5. Press EXIT. E321MV... -
Page 35: Adjusting The Color Temperature
E321MV Adjusting the Color Temperature Color temperature changes the “warmness” or “coolness” of the white areas of the picture. To adjust this setting, Picture Mode must be set to Custom. To adjust the color temperature setting: 1. Press the OK button on the remote. -
Page 36: Enabling Or Disabling Dcr (Dynamic Contrast Ratio)
To manage program content according to its rating, you must enable the Program Rating feature. To enable or disable the Program Rating feature: 1. From the Parental Controls menu, highlight Rating Enable and press OK. The Rating Enable menu is displayed. 2. Select On or Off and press OK. E321MV... -
Page 37: Locking And Unlocking Channels
E321MV Locking and Unlocking Channels When a channel is locked, it will be inaccessible. Locking a channel is a good way to prevent children from viewing inappropriate material. To lock or unlock a channel: 1. From the Parental Controls menu, highlight Channel Locks and press OK. -
Page 38: Setting The Tv Button Locks
1. From the Parental Controls menu, highlight More and press OK. The Change PIN menu is displayed. 2. Highlight RESET LOCKS and press OK. The TV displays, “Are you sure you want to RESET ALL LOCKS SETTINGS to the factory defaults?” 3. Highlight Yes and press OK. E321MV... -
Page 39: Viewing System Info And Resetting To Factory Defaults
E321MV Viewing System Info and Resetting to Factory Defaults You can use the TV’s Help menu to: • Display system information • Restore the TV to its factory default settings • Restart the Setup Wizard Displaying System Information To display a summary of the TV settings: 1. Press the MENU button on the remote. The on-screen menu is displayed. -
Page 40: Setting Up Closed Captioning
• BG Color - Change the background color. • BG Opacity - Change the transparency of the background. • Window Color - Change the edge color. • Window Opacity - Change the edge type. • Reset Default - Restore closed caption settings to factory defaults 4. When you are satisfied with the appearance of the closed captions, press the EXIT button on the remote. E321MV... -
Page 41: Troubleshooting & Technical Support
If you are experiencing a problem when using your TV, try to fix the issue using this troubleshooting guide. If, after using this troubleshooting guide, you are still experiencing an issue with your TV, contact VIZIO’s Support Department. Quality customer support and service are integral parts of VIZIO’s commitment to service excellence. Phone:... -
Page 42: The Picture Is Distorted
• The TV remembers the viewing mode on each input source. If the viewing mode on the new input source differs from the one on the input source you switch from, the difference may be noticable. • See Viewing a USB Photo Slideshow on page 19 . E321MV... -
Page 43: Specifications
Specifications Screen Size: Diagonal Viewable: Dimensions w/ Stand: 30.39 x 20.79 x 6.34” w/o Stand: 30.39 x 19.21 x 2.13” Weight w/ Stand: w/o Stand: TV Type: Refresh Rate: Maximum Resolution: Pixel Pitch: 0.3635 mm x 0.3635 mm Dynamic Contrast Ratio: Viewing Angle: Response Time: Brightness:... -
Page 44: Limited Warranty
Covers units purchased as new in United States and Puerto Rico Only. VIZIO provides a warranty to the original purchaser of a new Product against defects in materials and workmanship for a period of one (1) year of non-commercial usage and ninety (90) days of commercial use. -
Page 45: Legal & Compliance
Open Source Software Notice Your VIA device may contain GPL executables and LGPL libraries that are subject to the PL2.0/LGPL2.1 License Agreements. VIZIO offers to provide source code to you on CD-ROM for a processing fee covering the cost of performing such distribution, such as the cost of media, shipping and handling upon request made to VIZIO at www.VIZIO.com. - Page 46 Notes...
- Page 48 © 2011. All rights reserved. the v, viZiO, viZiO internet Apps, theAter 3d, Full ArrAy truled, edge lit rAZOr led, 240hZ sps, 480hZ sps, entertAinment FreedOm And entertAinment FreedOm FOr All nAmes, lOgOs And phrAse Are registered Or unregistered trAdemArks OF viZiO, inc.
