ViewSonic ViewPanel VP181 User Manual page 15

Bass/Treble adjusts the high (treble) and low (bass) frequency audio output.
Press [M] or [L] to adjust treble.
Press [2] button to select bass adjustment.
Press [M] or [L] to adjust bass.
Advanced Menu
E
N
G
L
I
S
H
Scaling adjusts the video input signal to the screen size using the following
options. Press [M] or [L] to select from the following options:
for different resolutions.
Sharpness adjusts the clarity of a non-SXGA (1280 x 1024) RGB signal.
Press [M] or [L] to adjust.
Picture in Picture allows the user to review a composite video signal within
the primary screen image.
Press [M] or [L] to adjust the size of the picture from the following options:
Small, Medium, or Large.
PIP Position allows the user to place the Picture-in-Picture window anywhere
on the screen. Press [M] or [L] to select from the following options:
ViewMeter
from the graphics card in your computer.
NOTE: See your graphics card user guide for more information about
changing the resolution and refresh rate.
14
Operation
To save changes and exit Main Menu, press the [1] button
1:1 adjusts the video signal so that the height and width of the
picture are the same.
Fill all adjusts the video signal to fill the screen.
Fill Aspect Ratio maintains the correct video signal proportions
NOTE: Sharpness control option is only available with non-SXGA
resolutions.
H. Adj moves the second video signal horizontally.
[M] moves second signal to left, [L] moves second signal to right.
V. Adj moves the second video signal vertically.
[M] moves second signal down, [L] moves second signal up.
®
displays information regarding the current input signal coming
ViewSonic VP181 ViewPanel ®
