Toto WH172AAT Series Installation Instructions Manual
Auto-function concealed cistern
Hide thumbs
Also See for WH172AAT Series:
- Installation instruction (20 pages) ,
- Installation manual (20 pages) ,
- Instruction manual (24 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for Toto WH172AAT Series
Summary of Contents for Toto WH172AAT Series
- Page 1 WH173BAT WH172AAT WH173BAT WH172AAT WH173SGAT 563414-1...
- Page 2 Safety Precautions (Be sure to follow them for safety sake.) 重要提示： Important: 1. Functions of the concealed cistern: storage water, inlet and outlet calve vessel, frame of wall-hung toilet, The function reflected in the actuator panel instructions. 2. This instruction manual only supports the installation of the concealed cistern. 3.
- Page 3 Be sure to read through this installation manual before installation work and install the product properly according to the descriptions of this manual. Be sure to follow the warnings and cautions for safety sake. This indication means the case where there is a possible This indication means the case where there is a possible danger which may result in death or serious injury if the damage which may result in injury or only physical...
- Page 4 Self diagnosis and troubleshooting 温馨提示： Note: Users may fix the problems on their own if the corrective action is to be taken by the user according to the chart below. Non-professionals are prohibited from disassembling and repairing the product. Please contact the relevant professionals for futher troubleshooting to avoid aggravating the problem.
- Page 5 INSTALLATION INSTRUCTION FOR CONCEALED CISTERN 重要提示： Important: 1. Please read through this Instructions carefully prior to installation,and our company shall not be responsible for any loss caused by not installating according with this Instructions. Lubricants are provided for the installation. 2.
- Page 6 Included Parts Check to make sure you have all these parts from the package: Parts in Bag 1 In Wall Tank (Carrier) Installation Outlet Pipe Inlet Pipe Manual Mud Guard Mud Guard Push Plate Rough In Push Plate Rough In Installation Template Parts in Bag 2 Parts in Bag 3...
- Page 7 Before Installation Dimensions and Supply Pipe-laying 安装墙 安装墙 135~220 Main wall Main wall 20~60 R1/2 0 110 70~130 要求排水管中心到安装墙面的距离 摆动45度 ＊ (W)在70～130之间. ＊ 45° swinging ◯ 200~220 70~90 Please make sure W is between 70 to 130. ◯ 180~220 70~110 155~215 70~130 135~195...
- Page 8 Installation procedure 安装排水管: Install the discharge pipe 安装墙脚固定块、调整地板固定支架: Install Angle Fixture and adjust floor-fixing bracket 170: Bolt length of 75 mm Horizontal 170: Bolt length of 120 mm 安装墙脚固定块。 Vertical Install Angle Fixture. 调整地板固定支架。 Adjust floor-fixing bracket. 安装分歧管。 Sealing Tape Install the branch pipe.
- Page 9 安装上支架: Install the upper bracket 130mm 110mm 85mm 65mm 位置2 位置2 位置1 位置1 Position 2 Position 2 Position 1 Position 1 提示 : 排污管侧向安装角度一般不超过 45° ， 否则很可能会影响排污效果。 Note: The drainage function may be affected when the installation angle of drainage pipe exceed 45° 110/130 固定供电电缆（绝缘锁）: Secure the power supply cable (wire band)
- Page 10 在主墙和地板上标记:（ 10X深60） 膨胀螺栓的使用方法: Draw on the main wall and floor Install Anchors 4 9 0 10mm As shown on picture: 6 5 0 1. Drill 10*60; 2. Insert anchor; 1 1 6 5 深60mm Depth 60 mm F F L 调节支架的水平和垂直，并锁紧螺栓：...
- Page 11 安装角阀： Install the Angle valve Sealing Tape “Click” “Click’’ “Click’’ “Click” “Click’’ “Click’’ 安装供水管 Install the water supply pipe Sealing Tape...
- Page 12 预留推板安装： Install Plug For the fixing of the long screw, there are two groups of screw holes on the bracket which are of different distance. Please choose the right position according to the size of the toilet bowl. “Click’’ “Click’’ Important remind: When the concealed tank fixed completely, it is important to test leaking with water upon 12 hours before fixing wall.
- Page 13 因安装的卫洗丽不同，墙壁开孔位置有所差异。 The positions of the holes to drill in the wall vary depending on WASHLET being installed. 电源插头形状可能随国家/地 区不同而有差异。请确认现 有的电源插头的形状能否保 证正常安装。 Power plug shape may vary by country. Please confirm which Power plug shape you have for 如果是配有上述插头的卫洗丽， correct installation. 请前往第15页。...
- Page 14 装修墙厚度范围20～60mm (从固定支架外面算起,到贴砖后完成面) The thickness of fixed wall is 20~60mm (measured from the front of frame to the finished tile surface) It is forbidden to use unsustainable, ductile or 预留推板 light-weight material to fix the Push Plate covering. Such as foam board Rough-In etc.
- Page 15 装修墙厚度范围20～60mm (从固定支架外面算起,到贴砖后完成面) The thickness of fixed wall is 20~60mm (measured from the front of frame to the finished tile surface) It is forbidden to use unsustainable, ductile or 预留推板 light-weight material to fix the Push Plate covering. Such as foam board Rough-In etc.
- Page 16 安装坐便器： Mark Install the toilet Set Straight Pipes into Flush Bend and Add lubricant onto the Rubber Gaskets of Drain Bend properly, and marks lines. two Straight Pipes and set them into Bowl. L2+3mm L1+3mm L1 is the distance of two marks on Flush Straight Chamfer and trim the cutting edges on the shortened Straight pipes (as Pipe, and L2 is that of two marks on Drainpipe...
- Page 17 维修保养 Servicing procedures 冲洗阀的维护及更换、自动冲洗单元的更换 Servicing and / or Replacing the Flush Valve, Replacing the Auto Flush Unit Remove the splash guard and pull it out. Close the shutoff valve in the tank, and then push the button on the actuator to flush the water. ❷...
- Page 18 清洁进水阀滤嘴 Cleaning the Filter of the Fill Valve 1. Close the water shutoff valve, and then remove the fill valve as described above. 2. As shown in the figure, disassemble the fill valve, and then either clean the filter with water or use a brush to clean any dirt from it. 3.
- Page 19 墙壁面板详细尺寸。 Detail dimensions for wall Panel. 180mm Ø64mm Ø19mm Ø19mm 接线盒孔 Electrical Box Hole Ø24mm Ø114mm Ø40mm 78mm 最小340mm-最大460mm min.340mm-max.460mm 180mm Ø64mm Ø19mm Ø19mm Ø24mm Ø24mm Ø114mm Ø40mm 78mm...
- Page 20 TOTO INDIA INDUSTRIES Off. Andheri Kurla Road, Andheri (East), Mumbai 400 059, India. PVT. LTD Phone : +91-22-4022-3717 / 3718 Fax : +91-22-4022-3719 http://asia.toto.com/ R. 810, Daeha Business Centre, 360 Kim Ma St., Ba Dình Dist., Ha Noi City TOTO VIETNAM Phone : +84-4-37714354 Fax : +84-4-37714355 http://toto.com.vn/...
