Model No. DRTL39220
Serial No.
Serial
Number
Decal
QUESTIONS?
If you have questions, or if there
are missing or damaged parts,
we will guarantee complete sat-
isfaction through direct assis-
tance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
Customer Hot Line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
All manuals and user guides at all-guides.com
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading

Related Manuals for ProForm DRTL39220

Summary of Contents for ProForm DRTL39220

  • Page 1 All manuals and user guides at all-guides.com Model No. DRTL39220 USER'S MANUAL Serial No. Serial Number Decal QUESTIONS? If you have questions, or if there are missing or damaged parts, we will guarantee complete sat- isfaction through direct assis- tance from our factory.

  • Page 2: Table Of Contents

    8. To purchase a surge suppressor, see your local PROFORM dealer or call 1-800-806- 4. Keep the treadmill indoors, away from mois- 3651 and order part number 146148.
  • Page 3 All manuals and user guides at all-guides.com 16. The treadmill is capable of high speeds. 20. Inspect and properly tighten all parts of the Adjust the speed in small increments to treadmill regularly. avoid sudden jumps in speed. 21. Never insert any object into any opening. 17.

  • Page 4: Before You Begin

    The model number of the treadmill is cising, the unique 320x treadmill can be folded up, re- DRTL39220. The serial number can be found on a quiring less than half the floor space of other treadmills. decal attached to the treadmill (see the front cover of this manual for the location).

  • Page 5: Assembly

    All manuals and user guides at all-guides.com ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
  • Page 6 All manuals and user guides at all-guides.com 3. With the help of a second person, raise the Uprights (69) to the vertical Position. Attach the Storage Latch (36) to the left Upright with two 3/4” Screws (2). Remove the Lock Knob (30) from the Lock Pin (35). Make sure that the Lock Pin Collar (33) and the Spring (32) are on the Lock Pin as shown.
  • Page 7 All manuals and user guides at all-guides.com 6. Place the Console Base (47) on the Right Handrail (72) and the Left Handrail (not shown). Attach the Console Base with four 3/4” Screws (2) (only two Screws are shown). Do not overtighten the Screws. Insert the Wire Harness (42) through the two indicated plastic ties on the Console Base (47).

  • Page 8: Operation And Adjustment

    Adapter the right). To purchase a surge suppressor, see Surge Suppressor your local PROFORM dealer or call 1-800-806-3651 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS).
  • Page 9 All manuals and user guides at all-guides.com CONSOLE DIAGRAM Displays Note: If there is a thin sheet of Pulse Sensor plastic on the console, remove it. Clip Insert the key fully into the console. After a moment, CAUTION: the displays will light. Test the clip by carefully tak- Before operating the ing a few steps backward until the key is pulled console, read the following precautions.
  • Page 10 All manuals and user guides at all-guides.com To stop the walking belt, press the Stop button. continue to hold the Stop button for a moment. An The elapsed time will begin to flash in the “E” for English miles or an “M” for metric kilometers Time/Distance display.

  • Page 11: How To Fold And Move The Treadmill

    All manuals and user guides at all-guides.com HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill.
  • Page 12 All manuals and user guides at all-guides.com HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin.

  • Page 13: Troubleshooting

    All manuals and user guides at all-guides.com TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m.
  • Page 14 All manuals and user guides at all-guides.com PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 8. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- come damaged.

  • Page 15: Conditioning Guidelines

    All manuals and user guides at all-guides.com CONDITIONING GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed and incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian.

  • Page 16: Ordering Replacement Parts

    To order replacement parts, call our Customer Service Department toll-free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When ordering parts, please be prepared to give the following information: • The MODEL NUMBER OF THE PRODUCT (DRTL39220) • The NAME OF THE PRODUCT (PROFORM ®...
  • Page 17 All manuals and user guides at all-guides.com PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. Silver Ground 3/4” Screw (2)–8 3/4” Tek Screw Screw (75)–1 (58)–8 1/2”...
  • Page 18 All manuals and user guides at all-guides.com PART LIST—Model No. DRTL39220 R1002B Qty. Description Qty. Description Hood Controller 3/4” Screw Lift Frame Motor Belt Extension Leg Assembly Motor Tension Bolt Warning Decal Flat Washer Extension Leg Motor Star Washer 3 1/2” Bolt...
  • Page 19 All manuals and user guides at all-guides.com EXPLODED DRAWING—Model No. DRTL39220 R1002B...
