- Page 1 KW-V660BT KW-V66BT MONITOR WITH DVD RECEIVER INSTRUCTION MANUAL • Updated information (the latest Instruction Manual, system updates, new functions, etc.) is available from <https://www.jvc.net/cs/car/>. © 2020 JVCKENWOOD Corporation B5H-0357-03 EN (K)
-
Page 2: Table Of Contents
Contents Before Use Tuner Precautions ..............4 Tuner Basic Operation ..........25 How to read this manual ......... 5 Memory Operation ..........26 Selecting Operation ..........26 Basic Operations Traffic Information ...........27 Tuner Setup ..............27 Functions of the Buttons on the Front Panel ... 6 Turning on the Unit ........... - Page 3 Controlling Audio Speaker/ X’over setup ..........48 Controlling General Audio ........49 Equalizer Control ............50 Volume Offset ............51 Sound Effect ...............51 Listening Position/ DTA ..........52 Remote control Functions of the Remote control Buttons ..53 Connection/Installation Before Installation ............54 Installing the unit .............55 Troubleshooting Problems and Solutions .........59 Error Messages ............59...
-
Page 4: Before Use
• When you purchase optional accessories, the data stored in the USB device. For how to check with your JVC dealer to make sure that disconnect the USB device, see Disconnect the they work with your model and in your area. -
Page 5: How To Read This Manual
• Simultaneously running multiple applications on your smartphone while screen sharing places heavy demand on the microprocessor of the phone, potentially affecting communication and performance. • For best results while pairing with your JVC receiver, please be sure to close any unused applications. English... -
Page 6: Basic Operations
Basic Operations Basic Operations Functions of the Buttons on Turning on the Unit the Front Panel The method of turning on is different depending on the model. Press the [ ] button. h The unit is turned on. ● To turn off the unit: NOTE Press the [ ] button for 1 second. -
Page 7: Getting Started
Basic Operations Getting Started ■ [Camera] Set the parameters for the camera. 1 Touch [Camera]. Initial setup 2 Set each item and touch [ For detailed operation, see Camera Setup Perform this setup when you use this unit first (P.42). time. -
Page 8: Adjusting The Volume
Basic Operations Adjusting the volume Touch [User Interface]. To adjust the volume (0 to 40), Press [＋] to increase, and press [−] to decrease. Holding [＋] increases the volume continuously to level 15. h User Interface screen appears. Touch screen operations Touch [Clock Adjust]. -
Page 9: Home Screen Descriptions
Basic Operations Display the HOME screen Gesture Touch Control: You can also control playback by moving your finger on the touch panel as follows (for some Press the [ ] button. sources, the gesture control is not available). • Sliding the finger towards up/down: - Functions same as pressing [ ] / [ (Media) in the USB Control screen. - Page 10 (P.21) (P.11) It is necessary to connect Android To turn off the AV source smartphone with “Mirroring OA for JVC” application installed and to set [Mode] to [Mirroring for Android™]. (P.21) Touch [ ] on the HOME screen.
-
Page 11: Source Control Screen Descriptions
Basic Operations Customize Short-cut buttons on Secondary screen HOME screen • [ ] [ ] : The Secondary screen changes every time you touch it. You can also change the You can arrange the position of the source icons Secondary screen by flicking left or right on as you like. -
Page 12: Function Screen
Basic Operations FUNCTION screen ● To turn on the screen Touch the display. Press the [FNC] button. List screen There are some common function keys in the list screens of most sources. h FUNCTION screen appears. Touch to display the FUNCTION screen. The contents of the menu are as follows. -
Page 13: Disc
Disc Disc Playing a disc DVD/VCD Basic Operation Ñ Insert a disc Most functions can be controlled from the source control screen and playback screen. Insert the disc into the slot. NOTE • The screen shot below is for DVD. It may be different from the one for VCD. - Page 14 Disc Play mode indicator/Playing time Indicator Items • D, B, I, etc.: Current play mode indicator • [IN]: Disc insertion status. Meanings of the icons are as follows: D (play), White: A Disc is inside the unit. B (fast forward), A (fast backward), Orange: Disc player failure.
-
Page 15: Music Cd/Disc Media Basic Operation
Disc Ñ Function panel Music CD/Disc media Basic Operation Touch on the left side of the screen. Most functions can be controlled from the source control screen and playback screen. NOTE • In this manual, “Music CD” means a general CD which includes music tracks. -
Page 16: Dvd Disc Menu Operation
Disc DVD Disc Menu Operation • [ ] : Repeats the current track. Each time You can set up some functions using the DVD- you touch the key, repeat mode switches in VIDEO disc menu. the following sequence; Track/File repeat ([ ]), Repeat all ([ Touch the framed area during playback. -
Page 17: Dvd Setup
Disc DVD Setup To switch among picture angles ■ Touch [Angle]. Each time you touch this key, picture angles are switched. You can set up the DVD playback functions. Touch the framed area during playback. * These keys may not function depending on the disc. - Page 18 Disc [Screen Ratio] ■ Sets the screen display mode. [16:9 ](Default): Displays wide pictures. [4:3LB]: Displays wide pictures in the Letter Box format (having black stripes at the top and bottom of screen). [4:3PS]: Displays wide pictures in the Pan & Scan format (showing pictures cut at the right and left ends).
-
Page 19: Apps
APPS APPS Apple CarPlay Operation Apple CarPlay is a smarter, safer way to use your iPhone in the car. Apple CarPlay takes the things you want to do with iPhone while driving and displays them on the screen of the product. You can get directions, make calls, send and receive messages, and listen to the music from iPhone while driving. -
Page 20: Android Auto Operation
APPS To enter Android Auto mode, touch Android Auto™ Operation [Android Auto] icon in the source selection screen. (P.10) Android Auto enables you to use functions of your Android smartphone convenient for driving. You can easily access route guidance, make calls, listen to music, and access convenient functions on the Android smartphone while driving. -
Page 21: Usb Mirroring Operation
Download Mirroring App from the Google Play. Ñ Connecting an Android Install the latest version of the Mirroring smartphone application “Mirroring OA for JVC” on your Android. Connect an Android smartphone via the Pair your smartphone with the unit via USB terminal. Bluetooth. -
Page 22: Usb
Connecting a USB device USB Basic Operation Most functions can be controlled from the Connect the USB device with the USB source control screen and playback screen. cable. (P.57) Control screen Press the [ ] button. Touch [ Touch [USB]. (P.10) Ñ... - Page 23 Video screen ] / [ • [ ] : Repeats the current track/folder. Each time you touch the key, repeat mode switches in the following sequence; File repeat ([ ]), Folder repeat ([ ]), Repeat all ([ • [ ] : Randomly plays all tracks in current folder.
-
Page 24: Search Operation
Ñ Search Operation Link search You can search a file of same artist/album/genre You can search music or video files by the as the current track. following operations. Touch [Link Search]. Touch [1]. Touch the desired tag type. You can select Touch [S]. -
Page 25: Tuner
Tuner Tuner Tuner Basic Operation Operation keys • [E] [F] : Tunes in a station. The method of Most functions can be controlled from the frequency switching can be changed (see 2 source control screen. in table). To enter Tuner source, touch [Tuner] icon in the •... -
Page 26: Memory Operation
Tuner Memory Operation Selecting Operation Ñ Ñ Auto memory Preset select You can store stations with good reception in You can list and select memorized station. memory automatically. Touch [ ] on the right side of the screen. Touch desired band key. Select a station from the list. -
Page 27: Traffic Information
Tuner Traffic Information (FM only) Tuner Setup You can listen and watch the traffic information You can set tuner related parameters. automatically when a traffic bulletin starts. Touch [ However, this feature requires a Radio Broadcast Data System that includes the TI information. Touch [ ] on the left side of the screen. -
Page 28: Siriusxm
SiriusXM® SiriusXM® SiriusXM® Basic Operation Control screen Only SiriusXM® brings you more of what you love to listen to, all in one place. Get over 140 channels, including commercial-free music plus the best sports, news, talk, comedy and entertainment. Welcome to the world of satellite radio. -
Page 29: Storing Channels In Preset Memory
SiriusXM® Storing Channels in Preset Artwork / Function panel Memory • Displays the album artwork for most SiriusXM music channels. You can store the current channel in memory. • Touch [ ] of the screen to display the function Tune in the channel you wish to store in panel. -
Page 30: Direct Search
SiriusXM® Direct search Category/Channel search You can tune in a channel directly. You can specify the desired category and select a channel. Touch [ ] on the left side of the screen. Touch [1]. Touch [Direct Channel]. Select a category. Enter the channel number and touch [Enter]. -
Page 31: Replay
SiriusXM® Replay SiriusXM Setup You can replay the last 60 minutes of the Touch [ ] on the left side of the screen. program from the current channel. Touch [SETUP]. Touch [L] or [Replay] on the function panel. h SiriusXM SETUP screen appears. See the following sections for each setting. - Page 32 SiriusXM® Ñ Ñ Parental code Parental Control You can set a SiriusXM parental code for Parental The Parental Control feature allows you to limit Control. access to any SiriusXM channels, including those with mature content. When enabled, the Touch [Parental Code] on the SiriusXM Parental Control feature requires you to enter a SETUP screen.
- Page 33 SiriusXM® Touch each channel on the list and set to When selecting [User] [ON] or [OFF]. This allows you to limit access to any SiriusXM [ON]: Locks the channel. channel (Parental Lock Channel). [OFF]: Unlocks the channel. Touch [Parental Lock Channel Selection] on the SiriusXM SETUP screen.
-
Page 34: Bluetooth Control
Bluetooth Control Bluetooth Control Ñ About the cell-phone and Using the Bluetooth function, various functions Bluetooth audio player can be used: listening to the audio file, making/ receiving a call. This unit conforms to the following Bluetooth specifications: Information for using Bluetooth®... -
Page 35: Register From The Bluetooth Device
Bluetooth Control Register from the Bluetooth Bluetooth Setup device Press the [FNC] button. It is necessary to register the Bluetooth audio h FUNCTION screen appears. player or cell-phone to this unit before using the Bluetooth function. Touch [ You can register up to 7 Bluetooth devices. NOTE •... -
Page 36: Playing Bluetooth Audio Device
Bluetooth Control Ñ Connect the Bluetooth device Playing Bluetooth Audio Device Touch [Select Device] in the Bluetooth SETUP screen. Most function can be controlled from the source control screen. To enter Bluetooth source, touch [BT Audio] icon in the source selection screen. (P.10) Ñ... - Page 37 Bluetooth Control Touch the device name you want to Function panel connect. Touch on the left side of the screen to display the function panel. Touch again to close the panel. • [BT DEVICE CHANGE] : Selects the device to connect via Bluetooth audio (A2DP) or APP (SPP).
-
Page 38: Using Hands-Free Unit
Bluetooth Control Using Hands-Free Unit ● Bluetooth SETUP 1) Touch [ Bluetooth SETUP screen appears. You can use telephone function by connecting the Bluetooth telephone to this unit. NOTE NOTE • The status icons such as battery and antenna displayed may differ from those displayed on the •... - Page 39 Bluetooth Control Ñ Voice Recognition Call using the preset number You can access the voice recognition function of Touch [ the cell-phone connected to this unit. You can search the cell-phone phonebook by voice. (The Touch the Name or phone number. functionality depends on the cell-phone.) Press the [ ] button.
- Page 40 Bluetooth Control Ñ Ñ Receive a call Operations during a call Touch [ ] to answer a phone call or [ to reject an incoming call. ● Adjust the receiver volume Press the [−] or [＋] button. NOTE • While monitoring the view camera, this screen does not appear even if a call comes in.
- Page 41 Bluetooth Control Ñ Phone number preset ■ [Delete] To delete a preset number, touch [Delete] You can register frequently used phone and then touch [Yes] on the confirmation numbers to this unit. screen. Ñ Touch [ Phonebook transfer Touch [Edit]. You can transfer the phonebook in your Bluetooth smartphone via PBAP.
-
Page 42: Other External Components
Other External Components Other External Components Ñ View Camera Camera Setup Press the [FNC] button. NOTE h FUNCTION screen appears. • To connect a camera, see P.57. • To use a rear view camera, a REVERSE lead Touch [ connection is required. (P.57) h SETUP Menu screen appears. -
Page 43: External Audio/Video Players-Av-In
Other External Components External audio/video players— To adjust the parking guidelines AV-IN NOTE • Install the rear view camera in the appropriate Connect an external component to the position according to the instructions supplied AV-IN input terminal. (P.57) with the rear view camera. •... -
Page 44: Setting Up
Setting Up Setting Up Monitor Screen Setup System Setup You can adjust image quality in video screen. Press the [FNC] button. Press the [FNC] button. h FUNCTION screen appears. h FUNCTION screen appears. Touch [ Touch [ h Screen Control screen appears. Adjust each item as follows. -
Page 45: User Interface Setup
Setting Up User Interface Setup Special Setup You can setup user interface parameters. You can setup Special parameters. Press the [FNC] button. Press the [FNC] button. h FUNCTION screen appears. h FUNCTION screen appears. Touch [ Touch [ h SETUP screen appears. h SETUP screen appears. -
Page 46: Display Setup
Setting Up Display Setup To register original image You can load an image from the connected USB device and set it for the background image. Press the [FNC] button. Before operating this procedure, it is necessary to h FUNCTION screen appears. connect the device which has the image to load. -
Page 47: Av Setup
Setting Up AV Setup You can set AV parameters. Press the [FNC] button. h FUNCTION screen appears. Touch [ h SETUP screen appears. Touch [AV]. h AV screen appears. Set each item as follows. ■ [AV-OUT] Specify whether to output the current source signal from the VIDEO OUT terminal. -
Page 48: Controlling Audio
Controlling Audio Controlling Audio Speaker/ X’over setup You can adjust the various settings such as audio balance or subwoofer level. Press the [FNC] button. Press the [FNC] button. h FUNCTION screen appears. h FUNCTION screen appears. Touch [ Touch [ h Audio screen appears. -
Page 49: Controlling General Audio
Controlling Audio [Tweeter] (Only for Front) [TW] (Tweeter) [Gain]* ■ ■ You can set the tweeter when you are Adjusts the tweeter level. (When front is selecting front speakers. selected on Speaker Select screen) [None], [Small], [Medium], [Large] [Phase Inversion]* ■... -
Page 50: Equalizer Control
Controlling Audio Equalizer Control [SW Level] ■ Adjusts the subwoofer volume. You can adjust equalizer by selecting the Ñ Recall the EQ curve optimized setting for each category. Press the [FNC] button. Touch [Preset Select]. h FUNCTION screen appears. Select EQ curve. Touch [ h Audio screen appears. -
Page 51: Volume Offset
Controlling Audio Volume Offset Sound Effect Finely adjust the volume of the current source You can set sound effects. to minimize the difference in volume between Press the [FNC] button. different sources. h FUNCTION screen appears. Press the [FNC] button. h FUNCTION screen appears. -
Page 52: Listening Position/ Dta
Controlling Audio Listening Position/ DTA Position DTA control You can fine-adjust your listening position. Adjust the sound delay time as nearer speakers Touch [Adjust]. to the selected seat have more delay time, so that the sound from each speaker arrive a Touch [Delay]. -
Page 53: Remote Control
Remote control Remote control This unit can be operated using the remote Function control RM-RK258 (optional accessory). Name Switches to the direct search mode. [DIRECT] Functions of the Remote For details on the direct search mode, control Buttons see Direct search mode (P.53). Changes the aspect ratio. -
Page 54: Connection/Installation
Connection/Installation Connection/Installation Before Installation to a power source with a constant voltage supply, such as with battery wires, the battery may be drained. Before installation of this unit, please note the following precautions. • If the console has a lid, make sure to install the unit so that the front panel will not hit the lid # WARNINGS when closing and opening. -
Page 55: Installing The Unit
Connection/Installation Ñ Supplied accessories for Installing the unit installation Ñ Non-Japanese cars (3 m) (2 m) Bend the tabs of the mounting sleeve with a screwdriver or similar utensil and attach it in place. (M5 × 6 mm) (M5 × 8 mm) NOTE •... - Page 56 Connection/Installation Ñ Ñ Microphone unit Removing the unit 1) Check the installation position of the 1) Remove the trim plate by referring to step 1 in “Removing the trim plate”. microphone (accessory 1). 2) Clean the installation surface. 2) Insert the extraction key (accessory 9) deeply into the slot as shown.
- Page 57 Connection/Installation Ñ Connecting wires to terminals USB device 5V = 1.5A USB terminal (1.0 m) SiriusXM Connect Vehicle Tuner connector Sirius XM For more information on how to install the SiriusXM Connect Vehicle tuner, consult the installation guide included with the tuner. Light Green (Parking sensor wire) Accessory 3: Parking Extention cable For best safety, be sure to connect the...
- Page 58 Connection/Installation Ñ Connecting an iPhone/Android Android smartphone USB cable 1 3 5 7 2 4 6 8 1 3 5 7 2 4 6 8 iPhone Accessory 7 Lightning connector Accessory 8 KS-U62 (0.8m) Speaker impedance: 4-8 Ω White To front left speaker USB terminal (1.0 m)
-
Page 59: Troubleshooting
Troubleshooting Troubleshooting Problems and Solutions The specified disc does not play, but another one plays instead. If any trouble occurs, first check the following The disc is quite dirty. table for possible problems. h Clean the disc. See Precautions on handling discs (P.5). - Page 60 The disc player is malfunctioning. h Eject the disc and try inserting it again. Contact the [Check Tuner] JVC dealer if this indicator continues blinking or the A SiriusXM tuner is not connected to this unit. h Verify that the SiriusXM Connect Vehicle Tuner disc cannot be ejected.
-
Page 61: Appendix
Appendix Appendix Playable Media and Files You can play various kinds of media and files on this unit. Ñ List of playable discs NOTE • 8-cm (3 inch) discs cannot be used. Disc types / Standard Support Remark DVD-Video DVD-Audio ×... - Page 62 Appendix Ñ About files The following audio and video files are supported. ■ Playable Audio files Format Bit rate Sampling frequency Bit count AAC-LC (.m4a) MPEG2/4 AAC LC 8 – 320kbps, VBR 16 – 48 kHz 16 bit HE-AAC(V1,V2) MP3 (.mp3) MPEG 1/2 Audio Layer 3 8 –...
-
Page 63: Region Codes In The World
Appendix Region Codes in the World The DVD players are given a region code according to the country or area it is marketed, as shown in the following map. ■ DVD disc marks ■ Operation regulatory marks With this DVD, some functions of this unit such as the play function may be restricted depending on the location where the DVD is Indicates a region number. -
Page 64: Dvd Language Codes
Appendix DVD Language Codes Code Language Code Language Code Language Afar Inupiak Sanskrit [aa] [ik] [sa] Abkhazian Indonesian Sindhi [ab] [id] [sd] Afrikaans Icelandic Sangho [af] [is] [sg] Amharic Italian Serbo-Croatian [am] [it] [sh] Arabic Japanese Singhalese [ar] [ja] [si] Assamese Javanese Slovak... -
Page 65: Specifications
Appendix Specifications ■ USB interface section USB Standard ■ Monitor section : USB 2.0 High Speed Picture Size File System : 6.75 inches (diagonal) wide : FAT 16/ 32, exFAT : 151.8 mm (W) × 79.7 mm (H) Maximum Power Supply Current 5-15/16 ×... - Page 66 Appendix ■ DSP section ■ Video section Graphics equalizer Color System of External Video Input Band: 13 Band : NTSC/ PAL Frequency (BAND1 – 13) External Video Input Level (Mini jack) : 62.5/ 100/ 160/ 250/ 400/ 630/ 1k/ 1.6k/ 2.5k/ 4k/ : 1 Vp-p/ 75 Ω...
-
Page 67: About This Unit
Appendix About this Unit A CONSUMER ENGAGED IN A PERSONAL ACTIVITY AND/ OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR ■ Copyrights SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. •... - Page 68 Appendix STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON OF SUCH DAMAGE.
- Page 69 Products: MONITOR WITH DVD RECEIVER equipment and receiver. – Connect the equipment into an outlet on a Model Name: KW-V660BT / KW-V66BT circuit different from that to which the receiver Responsible Party: JVCKENWOOD USA is connected. CORPORATION – Consult the dealer or an experienced radio/TV 2201 East Dominguez Street, technician for help.
- Page 70 Appendix ■ Informação sobre a eliminação de pilhas Este produto não deve ser eliminado como lixo doméstico geral. Devolva a pilha usada ao revendedor ou entidade autorizada para que a mesma seja devolvida ao fabricante ou importador. A reciclagem e a eliminação de lixo de maneira apropriada ajudarão a conservar os recursos naturais ao mesmo tempo que prevenirão os efeitos prejudicais à...
- Page 71 Important Notice on Software EULA Ñ Ñ Software License on This Product Software License Agreement The software embedded in this product comprises a JVCKENWOOD Corporation (hereinafter called number of independent software components, each “Licensor”) holds either the copyright to the of which is copyrighted by JVCKENWOOD Corporation embedded software or the right to sublicense it.
- Page 72 Article 3 (Terms of License) Article 8 (Cancellation of the Agreement) 1. In assigning this product, User may not retain Licensor reserves the right to cancel this agreement the original copy of the embedded Licensed forthwith and claim compensation from User for the Software (including associated literature, updates damages caused by such cancellation when User: and upgrades) and any duplicates and associated...
- Page 74 KW-V660BT KW-V66BT MONITOR WITH DVD RECEIVER Quick Start Guide MONITEUR AVEC RÉCEPTEUR DVD Guide de démarrage rapide MONITOR CON RECEPTOR DVD Guía de inicio rápido • Updated information (the latest Instruction Manual, system updates, new functions, etc.) is available from •...
- Page 75 Important Notice on Software EULA Ñ Ñ Software License on This Product Software License Agreement The software embedded in this product comprises a JVCKENWOOD Corporation (hereinafter called number of independent software components, each “Licensor”) holds either the copyright to the of which is copyrighted by JVCKENWOOD Corporation embedded software or the right to sublicense it.
- Page 76 Article 3 (Terms of License) Article 8 (Cancellation of the Agreement) 1. In assigning this product, User may not retain Licensor reserves the right to cancel this agreement the original copy of the embedded Licensed forthwith and claim compensation from User for the Software (including associated literature, updates damages caused by such cancellation when User: and upgrades) and any duplicates and associated...
- Page 77 Functions of the Buttons on the Front Panel .......7 to the INSTRUCTION MANUAL on the following Turning on the Unit ................7 website: Getting Started ..................8 <https://www.jvc.net/cs/car/> Adjusting the volume .................9 Touch screen operations ..............9 HOME screen descriptions ............10 Source selection screen descriptions ........10 Source control screen descriptions ........12...
-
Page 78: Before Use
• When you purchase optional accessories, check dew may form on the lens in the disc player of with your JVC dealer to make sure that they work the unit due to condensation. This condensation with your model and in your area. - Page 79 • Simultaneously running multiple applications on your smartphone while screen sharing places heavy demand on the microprocessor of the phone, potentially affecting communication and performance. • For best results while pairing with your JVC receiver, please be sure to close any unused applications.
-
Page 80: Basic Operations
Basic Operations Basic Operations Functions of the Buttons on Turning on the Unit the Front Panel Press the [ ] button. h The unit is turned on. ● To turn off the unit: Press the [ ] button for 1 second. NOTE NOTE •... -
Page 81: Getting Started
Basic Operations Basic Operations Getting Started ■ [Camera] Set the parameters for the camera. 1 Touch [Camera]. Initial setup 2 Set each item and touch [ Perform this setup when you use this unit first For detailed operation, see Instruction time. -
Page 82: Adjusting The Volume
Basic Operations Adjusting the volume Touch [User Interface]. To adjust the volume (0 to 40), Press [＋] to increase, and press [−] to decrease. Holding [＋] increases the volume continuously to level 15. h User Interface screen appears. Touch screen operations Touch [Clock Adjust]. -
Page 83: Home Screen Descriptions
Basic Operations Display the HOME screen Gesture Touch Control: You can also control playback by moving your finger on the touch panel as follows (for some Press the [ ] button. sources, the gesture control is not available). • Sliding the finger towards up/down: - Functions same as pressing [ ] / [ ] (Media) - Page 84 • Switches to the USB Mirroring screen from the connected Android smartphone. It is necessary to connect Android smartphone with “Mirroring OA for JVC” application installed and to set [Mode] to [Mirroring for Android™]. • Displays the Hands Free screen. (P.21)
-
Page 85: Source Control Screen Descriptions
Basic Operations Source control screen [Û] descriptions Touch to display the Hands Free screen. (P.21) There are some functions which can be When connecting as Apple CarPlay or Android operated from most screens. Auto, it works as a phone provided in Apple CarPlay or Android Auto. -
Page 86: Function Screen
Basic Operations FUNCTION screen ● To turn on the screen Touch the display. Press the [FNC] button. List screen There are some common function keys in the h FUNCTION screen appears. list screens of most sources. Touch to display the FUNCTION screen. The contents of the menu are as follows. -
Page 87: Disc
Disc Disc Playing a disc DVD/VCD Basic Operation Ñ Insert a disc NOTE • The screen shot below is for DVD. It may be Insert the disc into the slot. different from the one for VCD. When the operation buttons are not displayed on the screen, touch area. -
Page 88: Dvd Disc Menu Operation
Disc DVD Disc Menu Operation Operation keys • [E] [F] : Searches for the previous/next You can set up some functions using the DVD- content. VIDEO disc menu. Touch and hold to fast-forward or fast-backward the disc. Touch area during playback. •... -
Page 89: Usb
Connecting a USB device USB Basic Operation Most functions can be controlled from the Connect the USB device with the USB source control screen and playback screen. cable. (P.29) Control screen Press the [ ] button. Touch [ Touch [USB]. (P.11) Ñ... -
Page 90: Tuner
Tuner Tuner Tuner Basic Operation Operation keys • [E] [F] : Tunes in a station. The method of Most functions can be controlled from the frequency switching can be changed (see 2 in source control screen. table). To enter Tuner source, touch [Tuner] icon in the •... -
Page 91: Siriusxm
Tuner SiriusXM® SiriusXM® Memory Operation Ñ Auto memory SiriusXM® Basic Operation You can store stations with good reception in memory automatically. Only SiriusXM® brings you more of what you love to listen to, all in one place. Get over 140 Touch desired band key. - Page 92 SiriusXM® Control screen Artwork / Function panel • Displays the album artwork for most SiriusXM music channels. • Touch [ ] of the screen to display the function panel. Touch [ ] to close the panel. – [Direct Channel]: Touch and enter the desired number.
-
Page 93: Bluetooth Control
Bluetooth Control Bluetooth Control Ñ About the cell-phone and Operate your smartphone/cell-phone Bluetooth audio player according to the displayed messages. Confirm the request on the This unit conforms to the following Bluetooth ■ smartphone/cell-phone. specifications: Version Bluetooth Ver. 4.1 Profile Cell-phone: HFP (Hands Free Profile) SPP (Serial Port Profile) -
Page 94: Using Hands-Free Unit
Bluetooth Control Using Hands-Free Unit Touch [Select Device] in the Bluetooth SETUP screen. You can use telephone function by connecting the Bluetooth telephone to this unit. NOTE • While Apple CarPlay or Android Auto is being connected, Bluetooth Hands-Free function cannot be used. - Page 95 Bluetooth Control Call using call records Call using the preset number Touch [ Touch [ Select the phone number from the list. Touch the Name or phone number. Call by entering a phone number Call using the phonebook Touch [ Touch [ Enter a phone number with number keys.
- Page 96 Bluetooth Control Ñ Ñ Receive a call Operations during a call Touch [ ] to answer a phone call or [ to reject an incoming call. ● Adjust the receiver volume Press the [−] or [＋] button. NOTE • While monitoring the view camera, this screen does not appear even if a call comes in.
-
Page 97: Controlling Audio
Controlling Audio Controlling Audio Ñ Controlling General Audio You can adjust the various settings such as audio balance or subwoofer level. Press the [FNC] button. Press the [FNC] button. h FUNCTION screen appears. h FUNCTION screen appears. Touch [ Touch [ h Audio screen appears. - Page 98 Controlling Audio Ñ Equalizer Control [SW Level] ■ Adjusts the subwoofer volume. You can adjust equalizer by selecting the optimized setting for each category. Press the [FNC] button. h FUNCTION screen appears. Touch [ h Audio screen appears. Touch [Equalizer]. Touch the screen and set the Graphic Equalizer as desired.
-
Page 99: Connection/Installation
Connection/Installation Connection/Installation Before Installation touching to cause a short circuit, then replace the old fuse with one with the same rating. • Insulate unconnected wires with vinyl tape or Before installation of this unit, please note the other similar material. To prevent a short circuit, following precautions. -
Page 100: Installing The Unit
Connection/Installation Ñ Supplied accessories for Installing the unit installation Ñ Non-Japanese cars (3 m) (2 m) Bend the tabs of the mounting sleeve with a screwdriver or similar utensil and attach it in place. (M5 × 6 mm) (M5 × 8 mm) NOTE •... - Page 101 Connection/Installation Ñ Ñ Microphone unit Removing the unit 1) Check the installation position of the 1) Remove the trim plate by referring to step 1 in “Removing the trim plate”. microphone (accessory 1). 2) Clean the installation surface. 2) Insert the extraction key (accessory 9) deeply into the slot as shown.
- Page 102 Connection/Installation Ñ Connecting wires to terminals USB device 5V = 1.5A USB terminal (1.0 m) SiriusXM Connect Vehicle Tuner connector Sirius XM For more information on how to install the SiriusXM Connect Vehicle tuner, consult the installation guide included with the tuner. Light Green (Parking sensor wire) Accessory 3: Parking Extention cable For best safety, be sure to connect the...
- Page 103 Connection/Installation Ñ Connecting an iPhone/Android Android smartphone USB cable 1 3 5 7 2 4 6 8 1 3 5 7 2 4 6 8 iPhone Accessory 7 Lightning connector Accessory 8 KS-U62 (0.8m) Speaker impedance: 4-8 Ω White To front left speaker USB terminal (1.0 m)
-
Page 104: Appendix
Appendix Appendix Specifications About this Unit ■ Copyrights ■ Bluetooth section • The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use Frequency of such marks by JVCKENWOOD Corporation is under : 2.402 – 2.480 GHz license. - Page 105 Appendix • THIS PRODUCT IS LICENSED UNDER THE AVC PATENT THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT PORTFOLIO LICENSE FOR THE PERSONAL USE OF A HOLDERS AND ONTRIBUTORS ``AS IS’’ AND ANY CONSUMER OR OTHER USES IN WHICH IT DOES NOT EXPRESS OR IMPLIED WARRANTIES, INCLUDING, RECEIVE REMUNERATION TO (¡)ENCODE VIDEO IN BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF...
- Page 106 Appendix • libogg Copyright (c) 2002, Xiph.org Foundation Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: – Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
- Page 107 ■ FCC CAUTION This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. Changes or modifications not expressly approved by the party responsible for compliance could void the ■ ISED CAUTION user’s authority to operate the equipment. This device contains licence-exempt transmitter(s)/ NOTE receiver(s) that comply with Innovation, Science and...
- Page 108 Este produto não deve ser eliminado como lixo Products: MONITOR WITH DVD RECEIVER doméstico geral. Devolva a pilha usada ao revendedor Model Name: KW-V660BT / KW-V66BT ou entidade autorizada para que a mesma seja Responsible Party: JVCKENWOOD USA devolvida ao fabricante ou importador. CORPORATION A reciclagem e a eliminação de lixo de maneira...
