Cobra Fi200R Instruction Manual

Items Supplied >
1 – Fi2000R Fuel Injection Module
2 – Zip Ties
Instruction Manual >
Read all instructions carefully and completely before installing your new Fi2000R module.
It is recommended that a qualified mechanic or technician install this product.
1. Remove the rider seat by removing the two button head screws from the tail section, then remove
the 2 front gas tank bolts and tilt it up using the supplied Suzuki prop rod to hold it in the up
position.
2. Route the wire harness from the Fi2000R to the fuel injectors by placing the Fi2000R next to the
ECU as shown in figure 2 and route the wiring harness between the two supports the gas tank
pivots on (see figure 1 & 2).
3. Unplug the top of the crankcase breather hose and the upper MAP sensor hose from the airbox
(see figure 1). Then by squeezing on both sides of the factory injector connectors, pull each
connector away from the injector.
4. Starting on the left side of the motorcycle insert the connector furthest from the Fi200R into the
left injector wire connector. Then attach the next connector on the Fi2000R into the left injector.
Repeat this step for all connectors. The connector closest to the Fi2000R will connect to the right
most injector on the motorcycle. You may have to squeeze the locking tabs on the connector to
ensure you have this connection firmly seated (see figure 1).
5. Attach the ground cable to the NEGATIVE post of the battery (see figure 2). Reconnect the
crankcase breather hose and MAP sensor hose.
6. Before re-installing the gas tank and seat, verify your connections. Remove the door from the
Fi2000R module to expose the LED's. Verify the wire connections by (1) turning on the ignition
while watching the 3 LED's. They will all light up for a few seconds, then go off. This is correct. If
you don't see lights, make sure the sidestand is up, bike is in neutral, clutch is in and handle bar
engine switched is set to run. If you still have no lights, re-check that all connectors are fully
engaged and the ground wire is connected correctly. (2) After achieving a steady light from all
three LED's, start the motorcycle the green light should now be the only LED on. If all three LED's
are still on after start up, verify you have attached the injector connectors correctly. Reattach the
access door when finished. Note: Make sure the ignition is turn off before changing any
connection.
7. Remove the backing from the Velcro and attach the Fi2000R to the ECU as shown in fig 2.
8. Lower the gas tank back into position and tighten the bolts. Replace the rider seat with the stock
hardware.
* Cobra recommends you always wear a helmet while riding. Please never operate your motorcycle while under
the influence of alcohol and/or drugs. Enjoy the new look of your motorcycle and please ride safely.
DOCUMENT NO. 0017 REV. A
04/05
23801 E. La Palma Ave., Yorba Linda, Ca 92887 Ph. 714.692.8180 Fax. 714.692.5016
Application(s) >
SUZUKI GSXR1000 03-04
92-5103
www.cobrausa.com
Page 1 of 3
