User's Guide
ADCxxDJxx00RF Evaluation Module
The ADCxxDJxx00RFEVM is an evaluation board used to evaluate the ADC12DJ5200RF, ADC12DJ4000RF,
ADC08DJ5200RF analog-to-digital converters (ADC) from Texas Instruments. The ADC12DJ5200RF is a dual-
channel, 12/08-bit ADC, capable of operating at sampling rates up to 5.2 and 4 Giga-samples per second
(GSPS) in dual-channel mode, or 10.4 and 8 GSPS in single-channel mode. The ADC12DJ5200RFEVM,
ADC12DJ4000RF, ADC08DJ5200RF output data is transmitted over a standard JESD204C high-speed serial
interface. This evaluation board also includes the following important features:
Transformer-coupled signal input network allowing a single-ended signal source from 500 kHz to
9 GHz
The LMX2594 clock synthesizer generates the ADC sampling clock
The LMK04828, LMK61E2 and LMX2594 onboard system clock generator generates SYSREF and FPGA
reference clocks for the high-speed serial interface
Transformer-coupled clock input network to test the ADC performance with an external low-noise clock
source
LM95233 temperature sensor
High-speed serial data output over a High Pin Count FMC+ interface connector
To improve signal routing quality, serial lane polarity is inverted with respect to the standard FMC
VITA-57 signal mapping. Signal mapping and polarity is shown in
Device register programming through USB connector and FTDI USB-to-SPI bus translator
SLAU640A – APRIL 2019 – REVISED JUNE 2021
Submit Document Feedback
ABSTRACT
Note
Copyright © 2021 Texas Instruments Incorporated
Table
8-1).
ADCxxDJxx00RF Evaluation Module
1

Advertisement

Table of Contents
loading

Summary of Contents for Texas Instruments ADC DJ 00RF Series

  • Page 1 The ADCxxDJxx00RFEVM is an evaluation board used to evaluate the ADC12DJ5200RF, ADC12DJ4000RF, ADC08DJ5200RF analog-to-digital converters (ADC) from Texas Instruments. The ADC12DJ5200RF is a dual- channel, 12/08-bit ADC, capable of operating at sampling rates up to 5.2 and 4 Giga-samples per second (GSPS) in dual-channel mode, or 10.4 and 8 GSPS in single-channel mode.
  • Page 2: Figure 1-1. Evm Orientation

    ADC12DJ5200RF EVM top side with ADC12DJ5200RF EVM bottom side without heat sink installed heat sink installed Copyright © 2016, Texas Instruments Incorporated Figure 1-1. EVM Orientation The digital data from the ADCxxDJxx00RFEVM board is quickly and easily captured with the TSW14J57EVM data capture boards.
  • Page 3: Table Of Contents

    ® are registered trademarks of Rohde & Schwarz GmbH & Co. All trademarks are the property of their respective owners. SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 4: Equipment

    ( J17 ) Mini USB Connector +12V DC ( J20 ) ( J14 ) Copyright © 2016, Texas Instruments Incorporated Figure 2-1. EVM Feature Locations ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 5 GUI using JMODE and the sampling frequency (Fs) entered by the user. The reference clock generator and device clock generator must be frequency-locked using a common 10-MHz reference. SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 6: Setup Procedure

    GND and the inner portion of the connector is 12 V. Connect the power cable to the EVM power connector. ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 7 Turn on the RF signal output of the signal generator connected to VIN. If external clocking is used, turn on the RF signal outputs connected to DEVCLK and Reference clock. SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 8: Figure 3-2. Configuration Gui Evm Tab

    The max clock rate supported by ADC12DJ4000RF is 4000 MHz and only 8-bit mode are suppored by ADC08DJ5200RF. All the 12-bit and 15-bit modes are disabled on ADC08DJ5200RF. Figure 3-2. Configuration GUI EVM Tab ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 9: Figure 3-3. Configuration Gui Adc Control

    See the ADC12DJ5200RF device data sheet, (SLVSEN9) for details regarding the necessary calibration sequence. 3. To enable background calibration, use the following steps: SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 10 ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 11: Figure 3-4. High Speed Data Converter Pro (Hsdc) Gui

    The HSDC Pro GUI will calculate the ADC Output Data Rate based on these inputs. The Fundamental and Harmonic frequency locations will also be calculated and identified in the FFT display. SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 12: Figure 3-5. Additional Device Parameters Dialog Box

    Setup Procedure www.ti.com Figure 3-5. Additional Device Parameters Dialog Box ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 13: Device Configuration

    JESD204C settings. Once the settings are changed, re-enable the JESD204 block. 4.2 Tab Organization Control of the ADC device features are available in the EVM, Control, JESD204C, NCO Configuration tabs. SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 14: Figure 4-1. Low-Level Register Control Tab

    Perform a generic read or write command to the device shown in the Block drop-down box using the read or write register buttons address and write data information Figure 4-1. Low-Level Register Control Tab ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 15: Troubleshooting The Adc12Dj5200Rfevm

    Verify that bandpass filters are used in the clock and input signal paths and that low-noise signal sources are used. SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 16: References

    FTDI USB to Serial Driver Installation Manual (www.ftdichip.com/Support/Documents/InstallGuides.htm) 6.2 TSW14J57EVM Operation Refer to the TSW14J57EVM user guide for configuration and status information. ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 17: Hsdc Pro Settings For Optional Adc Device Configuration

    The ADC12DJ5200RFEVM can be clocked using 3 different methods: external clock option, onboard clock option and external reference clock option. SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 18: Figure 7-1. Adc12Dj5200Rfevm Clocking System Block

    SYSREF SYSREF CLKIN0 32.5 MHz SDCLKx SDCLKx FPGA_SYSREF External Clock CLKIN1 DCLKx FPGA_CLK[3:0] Figure 7-1. ADC12DJ5200RFEVM Clocking System Block Diagram ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 19: Figure 7-2. Onboard Clocking System Block Diagram

    SDCLKx SYSREFREQ RFOUTB SYSREF CLKIN0 SDCLKx SDCLKx FPGA_SYSREF Onboard Clock CLKIN1 DCLKx FPGA_CLK[3:0] Figure 7-2. Onboard Clocking System Block Diagram SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 20: Figure 7-3. External Reference Clocking System Block Diagram

    CLKIN0 32.5 MHz SDCLKx External SDCLKx FPGA_SYSREF Referencel Clock CLKIN1 DCLKx FPGA_CLK[3:0] Figure 7-3. External Reference Clocking System Block Diagram ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 21: Figure 7-4. External Clock Configuration

    HSDC Pro Settings for Optional ADC Device Configuration Figure 7-4. External Clock Configuration SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 22: Figure 7-5. Onboard Clocking Configuration

    HSDC Pro Settings for Optional ADC Device Configuration www.ti.com Figure 7-5. Onboard Clocking Configuration ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 23: Signal Routing

    Y18,Y19 DP14_M2C_INV Y22,Y23 DP15_M2C_INV Red items with _INV in the signal name are inverted with respect to standard FMC polarity. SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 24: A Analog Inputs

    (500kHz to 9GHz) INAP(J5), INAM(J3), Differential 0.1 µF INBP(J6), INBM(J8) Differential INAP, INAM, INBP, INBM 0 Ω Figure A-1. Analog Input Path ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 25: Figure A-2. 3 Db Attenuation Pad

    A 3dB attenuation pad is added between the inputs and the ADC. The 3 dB pad helps with the flatness of the frequency response. Figure A-2. 3 dB attenuation pad SLAU640A – APRIL 2019 – REVISED JUNE 2021 ADCxxDJxx00RF Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 26: B Jumpers And Leds

    Changed the abstract to include additional devices................... • Added a Note to Open the ADC12DJ5200RFEVM GUI and Program the ADC and Clocks ......8 ADCxxDJxx00RF Evaluation Module SLAU640A – APRIL 2019 – REVISED JUNE 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
