  • Page 1 Projector ®...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY ....................4 Important Safety Instruction....................... 4 Cleaning the lens ........................5 3D Safety Information ........................ 6 Copyright ........................... 6 Disclaimer ..........................7 Trademark Recognition ......................7 FCC ............................7 Declaration of Conformity for EU countries ................8 WEEE ............................
  • Page 3 Compatible resolutions ......................43 Image size and projection distance ..................45 Projector dimensions and ceiling mount installation ..............46 IR remote codes ........................47 Troubleshooting ........................49 Warning indicators ........................51 Specifications ........................... 53 Optoma global offices ....................... 54 English...

  • Page 4: Safety

    SAFETY The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

  • Page 5: Cleaning The Lens

    ‡ Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the unit for repair. ‡ See projector enclosure for safety related markings.

  • Page 6: 3D Safety Information

    Warning: Do not clean the lens if the projector is warming up as this may cause the lens’ surface film to peel off. Warning: Do not wipe or tap the lens with a hard object. 3D Safety Information Please follow all warnings and precautions as recommended before you or your child use the 3D function. Warning Children and teenagers may be more susceptible to health issues associated with viewing in 3D and should be closely supervised when viewing these images.

  • Page 7: Disclaimer

    Disclaimer The information in this document is subject to change without notice. The manufacturer makes no representations or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of the manufacturer to notify any person of such revision or changes.

  • Page 8: Declaration Of Conformity For Eu Countries

    Noticee: Canadian users This Class B digital apparatus complies with Canadian ICES-003. Remarque à l'intention des utilisateurs canadiens Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada. Declaration of Conformity for EU countries ‡ EMC Directive 2014/30/EC (including amendments) ‡...

  • Page 9: Introduction

    ‡ The actual remote control may vary depending on the region. ‡ The remote control is shipped with the batteries. ‡ * For European warranty Information, please visit www.optoma.com. Optional accessories HDMI cable Lens cap Notee: Optional accessories vary depending on model, specification and region.

  • Page 10: Product Overview

    INTRODUCTION Product Overview Minimum 100mm Minimum Minimum 100mm 100mm Minimum Minimum 300mm 300mm Minimum 100mm Notee: ‡ Do not block projector intake and exhaust vents. ‡ When operating the projector in an enclosed space, allow at least 30 cm clearance around the intake and exhaust vents.

  • Page 11: Connections

    INTRODUCTION Connections Item Item RS232 Connector USB Power Out (5V 1.5A) HDMI 1 Connector Service Connector HDMI 2 / MHL Connector S/PDIF Connector VGA Connector 10. AUDIO OUT Connector 12V OUT Connector 11. Kensington Lock Port AUDIO IN Connector 12. Power Socket English...

  • Page 12: Keypad

    INTRODUCTION Keypad Item Item Power Lamp LED Enter On/Standby LED Re-Sync Source Menu Four Directional Select Keys Temp LED English...

  • Page 13: Remote Control

    INTRODUCTION Remote control User2 User1 User3 Contrast Brightness Mode Aspect ratio Keystone Mute Sleep Timer Volume Source Re-sync Menu Volume HDMI1 HDMI2 VGA1 VGA2 Video YPbPr Item Item Power On 15. User 3 User 2 16. Contrast User 1 17. Display Mode Brightness 18.

  • Page 14: Setup And Installation

    Do not operate the projector in any orientation other that table top or ceiling mount. The projector should be horizontal and not tilted either forwards/backwards or left/right. Any other orientation will invalidate the warranty and may shorten the lifetime of the projector lamp or the projector itself. For none standard installation advise please contact Optoma. English...

  • Page 15: Connecting Sources To The Projector

    SETUP AND INSTALLATION Connecting sources to the projector Item Item Item HDMI Cable USB Cable 11. HDMI Dongle MHL Cable S/PDIF Out Cable 12. RS232 Cable RCA Component Cable USB Power Cable 13. Power Cord VGA In Cable Audio Out Cable Audio In Cable 10.

  • Page 16: Adjusting The Projector Image

    SETUP AND INSTALLATION Adjusting the projector image Image height The projector is equipped with elevator feet for adjusting the image height. Locate the adjustable foot you wish to adjust on the underside of the projector. Rotate the adjustable foot clockwise or counterclockwise to raise or lower the projector. Tilt-Adjustment Feet Tilt-Adjustment Ring Zoom, lens shift, and focus...

  • Page 17: Remote Setup

    SETUP AND INSTALLATION ‡ To adjust the focus, turn the focus ring clockwise or counterclockwise until the image is sharp and legible. Focus Ring Notee: The projector will focus at a distance of 1.2m to 8.1m. Remote setup Installing / replacing the batteries Two AAA size batteries are supplied for the remote control.
  • Page 18 SETUP AND INSTALLATION Effective range Infra-Red (IR) remote control sensor is located on top of the projector. Ensure to hold the remote control at an angle within 30° (horizontally) or 20° (vertically) perpendicular to the projector’s IR remote control sensor to function correctly.

  • Page 19: Using The Projector

    USING THE PROJECTOR Powering on / off the projector User2 User1 User3 Contrast Brightness Mode Aspect ratio Keystone Mute Sleep Timer Volume Source Re-sync User2 User1 User3 Contrast Brightness Mode Aspect ratio Keystone Menu Mute Sleep Timer Volume Volume Source Re-sync HDMI1 HDMI2...
  • Page 20 USING THE PROJECTOR Powering off Turn off the projector by pressing the “ ” button on the projector keypad or the “ ” button on the remote control. The following message will be displayed: Power Off Power Off? Press power key again. Press the “...

  • Page 21: Selecting An Input Source

    USING THE PROJECTOR Selecting an input source User2 Turn on the connected source that you want to display on the screen, such as computer, notebook, video player, User1 User3 Contrast Brightness Mode etc. The projector will automatically detect the source. If multiple sources are connected, press the “ ”...

  • Page 22: Menu Navigation And Features

    USING THE PROJECTOR Menu navigation and features The projector has multilingual on-screen display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. To open the OSD menu, press on the remote control or the projector keypad.

  • Page 23: Osd Menu Tree

    USING THE PROJECTOR OSD Menu tree Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Cinema HDR SIM. Game Reference Display Mode Bright User ISF Day ISF Night ISF 3D Off [Default] Blackboard Light Yellow Wall Color Light Green Light Blue...
  • Page 24 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu BrilliantColor 1 ~ 10 Color Temperature Native Native HDTV Color Gamut Presentation Cinema Game R [Default] Color x offset -50 ~ 50 [Default: 0] Display Image Settings Color Settings...
  • Page 25 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Automatic On [Default] -50 ~ 50 (depends on signal) Frequency [Default: 0] 0 ~ 31 (depends on signal) Phase [Default: 0] Signal -50 ~ 50 (depends on signal) H.
  • Page 26 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Lamp Reminder On [Default] Lamp Settings Cancel [Default] Lamp Reset Filter Usage (read only) Hours Optional Filter Installed 300hr Filter Settings Filter Reminder 500hr [Default] 800hr 1000hr...
  • Page 27 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Test Pattern Color Temp Gamma Auto Source User1 Projection Lamp Settings Digital Zoom Dynamic Range [Default] Dynamic Black Test Pattern Color Temp Gamma Remote Auto Source Settings...
  • Page 28 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu English [Default] Deutsch Français Italiano Español Language Português 簡体中文 日本語 한국어 Русский Top Left Top Right Menu Location Center [Default] Bottom Left Menu Settings Bottom Right Menu Timer 5sec...
  • Page 29 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Cancel [Default] Reset OSD Setup Reset Cancel [Default] Reset to Default Regulatory Serial Number Source Resolution 00x00 Refresh Rate 0.00Hz Display Mode Power Mode (Standby) Light Source Info...

  • Page 30: Display Menu

    USING THE PROJECTOR Display menu Image settings menu Display Mode There are many factory presets optimized for various types of images. ‡ Cinema: Provides the best colors for watching movies. HDR: Decodes and displays High Dynamic Range (HDR) content for the deepest blacks, brightest ‡...
  • Page 31 USING THE PROJECTOR  HDR Demo Mode ‡ This feature enables you to see the difference in the image quality between the raw unprocessed image and the image processed as processed by the HDR. Brightness Adjust the brightness of the image. Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture.
  • Page 32 USING THE PROJECTOR ‡ Color Space (non-HDMI input only): Select an appropriate color matrix type from the following: AUTO, RGB, or YUV. ‡ Color Space (HDMI input only): select an appropriate color matrix type from the following: Auto, RGB(0-255), RGB(16-235), and YUV. Signal Adjust the signal options.
  • Page 33 USING THE PROJECTOR Aspect ratio menu Select the aspect ratio of the displayed image between the following options: 4e:3: This format is for 4:3 input sources. ‡ 16e:9: This format is for 16:9 input sources, like HDTV and DVD enhanced for Wide screen TV. ‡...
  • Page 34 USING THE PROJECTOR 4K UHD scaling table: 16 e: 9 screen 480i/p 576i/p 720p 1080i/p 2160p Scale to 2880 x 2160. 16x9 Scale to 3840 x 2160. Get the central 3840 x 1620 image, and then scale to 3840 x 2160 for display. Native mode 1:1 mapping centered.

  • Page 35: Audio Menu

    USING THE PROJECTOR Audio menu Internal Speaker Use this option to turn on or off the internal speaker. Autoe: Choose “Auto” to automatically turn off the internal speaker when an external speaker is ‡ connected to the projector. ‡ Off: Choose “Off” to turn off the internal speaker. One: Choose “On”...
  • Page 36 USING THE PROJECTOR Power settings menu Direct Power On Choose “On” to activate Direct Power mode. The projector will automatically power on when AC power is supplied, without pressing the “Power” key on the projector keypad or on the remote control. Auto Power Off (min.) Sets the countdown timer interval.
  • Page 37 USING THE PROJECTOR Remote settings menu IR Function Set the IR function setting. ‡ One: Choose “On”, the projector can be operated by the remote control from top and front IR receivers. ‡ Fronte: Choose “Front”, the projector can be operated by the remote control from the front IR receiver. Backe: Choose “Back”, the projector can be operated by the remote control from the rear IR receiver.
  • Page 38 USING THE PROJECTOR When the keypad lock function is “On”, the Keypad will be locked. However, the projector can be operated by the remote control. By selecting “Off”, you will be able to reuse the Keypad. Information Hide Enable this function to hide the information message. Off: Choose “Off”...

  • Page 39: Info Menu

    USING THE PROJECTOR Info menu View the projector information as listed below: ‡ Regulatory ‡ Serial Number ‡ Source ‡ Resolution ‡ Refresh Rate ‡ Display Mode ‡ Power Mode (Standby) ‡ Light Source Hours ‡ Projector ID ‡ Color Depth ‡...

  • Page 40: Maintenance

    MAINTENANCE Replacing the light bulb (Maintenance personnel only) The projector automatically detects the lifespan of the light bulb and when the light bulb is at its end, a warning message will appear on the screen. When this message appears, please contact your local dealer or service center to replace the light bulb as soon as possible.
  • Page 41 MAINTENANCE Replacing the lamp (continued) Procedure: Switch off the power to the projector by pressing the “ ” button on the projector keypad or the “ ” button on the remote control. Allow the projector to cool down for at least 30 minutes. Disconnect the power cord.

  • Page 42: Installing And Cleaning The Dust Filter

    MAINTENANCE Installing and cleaning the dust filter Installing the dust filter Notee: Dust filters are only required/supplied in the selected regions with excessive dust. Cleaning the dust filter We recommend you to clean the dust filter every three months. Clean it more often if the projector is used in a dusty environment.

  • Page 43: Additional Information

    ADDITIONAL INFORMATION Compatible resolutions Digital (HDMI 1.4) Native resolution: 1920 x 1080 @ 60Hz Established Timing Standard Timing Descriptor Timing Supported Video Mode Detail Timing 720 x 400 @ 70Hz 1280 x 720 @ 60Hz 1920 x 1080 @ 60Hz 720 x 480i @ 60Hz 16:9 1920 x 1080p @ 60Hz (default)
  • Page 44 ADDITIONAL INFORMATION B0 / Established Timing B0 / Standard Timing B1 / Video Mode B1 / Detail Timing 4096 x 2160 @ 30Hz 4096 x 2160 @ 50Hz 4096 x 2160 @ 60Hz Notee: Support 1920 x 1080 @ 50Hz. Analog Native resolution: 1920 x 1080 @ 60Hz B0 / Established Timing...

  • Page 45: Image Size And Projection Distance

    ADDITIONAL INFORMATION Image size and projection distance Screen Size W x H Projection Distance (D) Offset (HD) Diagonal length (inch) size (inch) (feet) of 16e:9 Screen Width Height Width Height Wide Tele Wide Tele (feet) 0.66 0.37 25.97 14.61 1.05 3.44 0.02 0.07...

  • Page 46: Projector Dimensions And Ceiling Mount Installation

    ADDITIONAL INFORMATION Projector dimensions and ceiling mount installation To prevent damage to your projector, please use the Optoma ceiling mount. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: ‡...

  • Page 47: Ir Remote Codes

    ADDITIONAL INFORMATION IR remote codes User2 User1 User3 Contrast Brightness Mode Aspect ratio Keystone Mute Sleep Timer Volume Source Re-sync Menu Volume HDMI1 HDMI2 VGA1 VGA2 Video YPbPr Customer code Key code Description format Byte 1 Byte 2 Byte 3 Byte 4 Power on Format 1...
  • Page 48 ADDITIONAL INFORMATION Customer code Key code Description format Byte 1 Byte 2 Byte 3 Byte 4 Mute Format 1 Momentarily turns off / on the audio. Automatically adjusts the picture (Dynamic Format 1 brightness to give optimum contrast Black) performance. Sleep timer Format 1 Sets the countdown timer interval.

  • Page 49: Troubleshooting

    ADDITIONAL INFORMATION Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image problems No image appears on-screen ‡ Ensure all the cables and power connections are correctly and securely connected as described in the "Installation"...
  • Page 50 ADDITIONAL INFORMATION Other problems The projector stops responding to all controls ‡ If possible, turn off the projector, then unplug the power cord and wait at least 20 seconds before reconnecting power. Lamp burns out or makes a popping sound ‡...

  • Page 51: Warning Indicators

    ADDITIONAL INFORMATION Warning indicators When the warning indicators (see below) light up or flash, the projector will automatically shutdown: ‡ "LAMP" LED indicator is lit red and if "On/Standby" indicator flashes red. ‡ "TEMP" LED indicator is lit red and if "On/Standby" indicator flashes red. This indicates the projector has overheated.
  • Page 52 ADDITIONAL INFORMATION ‡ Power off: Power Off Power Off? Press power key again. ‡ Temperature warning: Warning TEMPERATURE TOO HIGH Please: 1. Make sure air in and outlets are not blocked. 2. Make sure the environment temperature is under 45 degree C. If the problem persists in spite of the above.

  • Page 53: Specifications

    ADDITIONAL INFORMATION Specifications Optical Description - Graphic up to 2160p@60Hz Maximum resolution - Maximum Resolution: HDMI1 (2.0): 2160p@60Hz HDMI2 (1.4): 2160p@60Hz Native resolution (w/o actuator) 1920x1080 Lens Manual zoom and manual focus Image size (diagonal) 34.1”~302.4”, optimized@wide 82”(2.2m) Projection distance 1.2~8.1m, optimized@1.61m Electrical Description...

  • Page 54: Optoma Global Offices

    ADDITIONAL INFORMATION Optoma global offices For service or support, please contact your local office. Japan 3178 Laurelview Ct. 888-289-6786 東京都足立区綾瀬3-25-18 Fremont, CA 94538, USA 510-897-8601 info@os-worldwide.com 株式会社オーエス www.optomausa.com services@optoma.com 0120-380-495 www.os-worldwide.com コンタクトセンター: Canada Taiwan 3178 Laurelview Ct. 888-289-6786 12F., No.213, Sec. 3, Beixin Rd.,...
  • Page 55 *36.7CM01G001-A* P/N:36.7CM01G001-A www.optoma.com...
