- Page 1 Philips Professional and Business Solution 22HFL3350D 26HFL3350D 32HFL3350D SETUP MANUAL...
-
Page 3: Table Of Contents
Table of contents 1 Important � � � � � � � � � � � � � � � � � � � � � 4 Safety ......4 Screen care. - Page 4 One of Philips’ leading Business Principles is to take all necessary health and safety measures for our products, to comply with all applicable...
- Page 5 Mains fuse (UK only) This TV is fitted with an approved moulded plug. Should it become necessary to replace the mains fuse, this must be replaced with a fuse of the same value as indicated on the plug (example 10A). Remove fuse cover and fuse.
-
Page 6: Important
Never place liquid containers, such as vases, near the TV. If liquids are spilt on or into the TV, disconnect the TV from the power outlet immediately. Contact Philips to have the TV checked before use. • Never place the TV, remote control or batteries near naked flames or other heat sources, including direct sunlight. -
Page 7: Screen Care
• Risk of hearing damage! Avoid using earphones or headphones at high volumes or for prolonged periods of time. • Never allow children to climb on or play with the TV. • Place the TV where it cannot be pushed, pulled over or knocked down. -
Page 8: Your Tv
Your TV 2�1 Connection overview 1. EXT 1 First SCART connector for DVD players, VCRs, digital receivers, game consoles and other SCART devices. Supports Audio L/R, CVBS in/out, RGB 2. EXT 2 Second SCART connector. Supports Audio L/R, CVBS in/out. 3. - Page 9 13. USB USB connector for storage devices. 14. HDMI Additional HDMI connector for mobile high-definition devices. 15. COMMOM INTERFACE Slot for Conditional Access Modules. Note Refer to the user manuals for the respective devices for details of connection. 2�1�1 Side controls and indicators POWER PROGRAM +/- MENU...
-
Page 10: Remote Control
Remote control For advanced information about the remote control, see Chapter 5 Remote control overview. Guest mode remote control For setup and configuration purposes. EN-8 Setup remote control This remote control may be purchased separately for Institutional TV/Professional and Business Solutions features and SmartCard settings. -
Page 11: Get Started
4�2 Wall mount the TV WARNING Wall mounting of the TV should only be performed by qualified installers. Koninklijke Philips Electronics N.V. bears no responsibility for improper mounting that results in accident or injury. Step 1 Purchase a VESA-compatible wall bracket Depending on the size of your TV screen,... -
Page 12: Connect The Antenna Cable
NOTE When securing the VESA-compatible wall bracket to your TV, use M4 bolts for 26 inch models, M6 bolts for 32 inch models or M8 bolts for larger models (bolts not supplied). 4�3 Connect the antenna cable Locate the TV ANTENNA connector at the back of the TV. -
Page 13: Prepare Tv For Digital Services
Slide the battery cover off the back of the remote control. Insert the two supplied batteries (Size AAA, Type LR03). Be sure the + and - ends of the batteries line up with the markings inside the case. Slide the cover back into position. Note Remove the batteries if not using the remote control for an extended period of... - Page 14 OSD display OSD display Display message Welcome message line 1 Welcome message line 2 Welcome message ti... Enable CI slot Enable teletext Enable MHEG Press MENU or M to exit. EN-12 Enable CI slot...
-
Page 15: Remote Control Overview
Remote control overview This section provides a detailed overview of remote control features. Switches the TV on from standby or back to standby. GUIDE Toggles the Electronic Programme Guide on or off. Only active with digital channels. Selects connected devices. SUBTITLE Activates or deactivates subtitles. - Page 16 TELETEXT Toggles teletext on or off Spilts the current channel or source on the left of the screen. Teletext appears on the right. EN-14...
-
Page 17: First Time Setup
First time setup The first time the TV is switched on, a language selection menu appears. Please select your lan Press OK or the green colour key on your remote control to continue Select your language and follow the on-screen instructions to setup the TV. -
Page 18: Setup Bds Mode
Setup BDS mode The TV is designed to operate as BDS Hotel Mode, which offers the following benefits: • Disable user menu. Guests cannot change channel, picture and sound settings. • Select a switch on volume and channel. The TV will always start on the specified channel and volume level. -
Page 19: 7�2 Switch On Bds Mode
Setup menu BDS mode BDS mode Local keyboard locked Remote control OSD display Switch on volume 50 Maximum volume 100 Switch on channel Power on Select Setup menu > Remote control > High security mode. • Access the BDS Hotel Mode Setup Menu via the setup remote control only. -
Page 20: Select Osd Display
• Unlock remote control buttons. • Multi remote control • Disable multi remote control function. • Blue Select to use the blue guest remote control. • Select to use the red guest remote control. • Green Select to use the green guest remote control. -
Page 21: Set Switch On Volume
• Enable MHEG Select On to access MHEG. • Enable EPG Select On to access EPG. • Enable Subtitles Select On to display subtitles. 7�6 Set switch on volume When the user switches the TV on, it will play at the specified volume level set. Enter Setup menu. -
Page 22: Set Low Power Standby
Setup menu Local keyboard locked Remote control OSD display Switch on volume 50 Maximum volume 100 Switch on channel Power on Low power standby Press Æ to enter Power on. Press Î or ï to select the desired status. • The TV will always turn on after the mains power is connected. -
Page 23: Set Auto Scart
• Time download Set the time of the clock display automatically via Teletext. The clock will be automatically synchronised to the correct time. • Download Program Select the time from the teletext transmission of a channel. Make this download program the same as the startup channel. -
Page 24: Select Blank Current Channel
Setup menu Power on Low power standby Clock Auto scart USB break-in Monitor out Blank current Channel Store - go right Press Æ to enter Monitor out. Press Î or ï to switch ON or OFF this feature. Press ï to select Store - go right and press Æ... -
Page 25: Clone Configuration
Clone configuration 8�1 From Cloning to TV Copy TV configuration data from a USB stick to TV. Insert the USB stick to the USB connector at the side of the TV. Enter Setup menu. Press ï to select Cloning to TV. Press Æ... -
Page 26: Trouble Shooting
Trouble shooting This section describes commonly-encountered issues and accompanying solutions. 9�1 Communication issues The TV does not communicate with external interactive terminal: • Check that the card slot is enabled. See Section 4.6.2 Access CAM services for details. 9�2 Picture issues No picture •... -
Page 27: Index
Index AUDIO IN 6 L/R 6 Auto scart 21 BDS mode setup 16 Channel install manually 19 switch on 19 Clock 7 display on 20 display standby 20 settings 20 time download 21 time offset 21 time setting 20 Clone configuration from Cloning to TV 23 From Cloning to TV 23 Common Interface 7... - Page 28 setup 18 Power indicator 7 low standby 20 on status 19 Recycling 5 Remote control 8 basic use 8 batteries 10 locked 17 multi 18 overview 13 sensor 7 setting 17 smart 18 Safety 4 SCART 6 Screen care 5 SERV.
- Page 30 © 2008 Koninklijke Philips Electronics N.V. All rights reserved.
