- Page 1 PG-F ECHNICAL RACTICE EMOTE ERMINAL NCLOSURE Model List CLEI Code FRE-765 VAMRBN0L~~ Section SCP-FRE765-041-03H...
- Page 2 Information furnished by ADC is believed to be accurate and reliable. In no event shall ADC be liable for any damages resulting from the loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
- Page 3 Using This Technical Practice SING ECHNICAL RACTICE Two types of messages, identified by icons, appear in the text: Notes contain information about special circumstances. Cautions indicate the possibility of equipment damage or the possibility of personal injury. FRE-765 List 4A January 6, 2003...
- Page 4 Using This Technical Practice SCP-FRE765-041-03H January 6, 2003 FRE-765 List 4A...
-
Page 5: Table Of Contents
Auxiliary Power Pairs ..................11 Subscriber Line Wiring .....................12 Cabling Verification ......................14 Turn-Up and Testing ......................14 Troubleshooting.........................14 Product Support _____________________________________________________________________ 15 Technical Support ..........................15 Limited Warranty..........................15 Returns .............................15 FCC Class B Compliance ........................17 Modifications ...........................17 Acronyms___________________________________________________________________________ 18 FRE-765 List 4A January 6, 2003... - Page 6 SCP-FRE765-041-03H January 6, 2003 FRE-765 List 4A...
- Page 7 3. Installing the Ground Wire..........................8 4. COT or Field Shelf to FRE-765 RT Enclosure, No Doublers.................9 5. COT or Field Shelf to FRE-765 RT Enclosure, 1 Doubler ................9 6. COT or Field Shelf to FRE-765 RT Enclosure, 2 Doublers................9 7. Installing HDSL Lines...........................10 8.
- Page 8 SCP-FRE765-041-03H January 6, 2003 FRE-765 List 4A...
- Page 9 IST OF ABLES 1. FRE-765 Circuit Assignments.........................4 2. Channel Unit Circuit Utilization ........................4 3. FRE-765 List 4A Backplane Connectors ......................5 4. Connector P3 ..............................5 5. Connector P2 (b).............................6 6. Power and Ground Line Unit Terminations ....................6 7. Grommet Hole Diameters..........................7 8.
- Page 10 SCP-FRE765-041-03H January 6, 2003 FRE-765 List 4A...
-
Page 11: Overview
HDSL HDSL Subscriber BYPASS Terminations CHASSIS Ground Bar Figure 1. FRE-765 List 4A RT Enclosure (Interior View) Features of the FRE-765 List 4A RT Enclosure include: • pole or wall mounting • line power from COT • -, 1-, 1 -, 2-inch cable entrance conduit knockouts with rubber grommet (provided) •... - Page 12 Subscriber circuits must also be protected with 3-mil carbon blocks, or equivalent, when these circuits are exposed to the outside plant. Use the List 4A RT Enclosures only with the FCS-718 List 2 or higher, or the FCS-719 List 2 or higher COT Shelves. January 6, 2003 FRE-765 List 4A...
-
Page 13: Specifications
UNCTIONAL ESCRIPTION Operational Capabilities The FRE-765 List 4A RT enclosure requires the following plug-in units: • one RT Line Unit which is line powered via the HDSL pairs that connect the RT to the PG-Flex COT line units installed in a COT Shelf. - Page 14 Functional Description SCP-FRE765-041-03H Table 1. FRE-765 Circuit Assignments Line Unit Channel Unit 1 Channel Unit 2 Channel Unit 3 Channel Unit 4 Refer to Table 6, “Power Ckt 1 Ckt 1 Ckt 1 and Ground Line Unit Ckt 2 Ckt 2 Ckt 2 Terminations,”...
-
Page 15: Backplane Connections
SCP-FRE765-041-03H Functional Description Backplane Connections Table 3, “FRE-765 List 4A Backplane Connectors,” on page 5 lists the FRE-765 List 4A backplane connectors and where each connector is described in this practice. Table 3. FRE-765 List 4A Backplane Connectors Connector or Fuse... - Page 16 Screw No connection—reserved for future use. Screw Chassis Ground CHASSIS GND (*) The RT enclosure is shipped with the “CHASSIS GND” wire-wrap post connected to the adjacent “GND” wire-wrap post on the RT Backplane. January 6, 2003 FRE-765 List 4A...
-
Page 17: Installation And Test
Select only one concentric knockout hole on the FRE-765. Remove the largest knockout so that the entire hole is open. Install the grommet from the outside of the FRE-765. (Hint - Hold it at an angle to the hole and roll it into position.) Ensure that the lip of the grommet rests on the bottom of the FRE-765 around the knockout hole. -
Page 18: Chassis Ground Wiring
Figure 3, “Installing the Ground Wire,” on page Use 6 AWG wire to ensure a good ground connection to the FRE-765. Route the chassis ground wire through the small hole in the strain relief on the bottom of the enclosure. -
Page 19: Cot Or Field Shelf To Fre-765 Rt Enclosure, No Doublers
With two doublers, two HDSL pairs plus four power pairs are required between the COT or Field Shelf and the FRE-765 RT Enclosure. The third and fourth power pairs are wired to the same terminations as the first and second power pairs (respectively) on the COT or Field Shelf and the FRE-765 RT Enclosure. -
Page 20: Hdsl Pairs
Termination for auxiliary power pairs when using two doubler units. This line is simplexed with +130Vdc for powering the RT. PWR 2B Termination for auxiliary power pairs when using two doubler units. This line is simplexed with -130Vdc for powering the RT. January 6, 2003 FRE-765 List 4A... -
Page 21: Bypass Pair
Route the auxiliary power pairs through the strain relief on the bottom of the enclosure. Use a cable tie to secure to the bracket near the cable entrance. Terminate the power pairs on the Auxiliary Power terminations per Table 8, “HDSL, Metallic Bypass, and Auxiliary Power Line Unit Terminations,” on page FRE-765 List 4A January 6, 2003... -
Page 22: Subscriber Line Wiring
Functional Description SCP-FRE765-041-03H Subscriber Line Wiring Use the following instructions to install the subscriber lines for the FRE-765 enclosure and see Figure 8, “Installing Subscriber Lines,” on page 12 Route the subscriber line cables through the bottom of the enclosure. - Page 23 Connector Slot Circuit (*) The cable on the rear of the termination module is installed in connector P1 on the RT enclosure backplane. (†) Shaded terminations used only with the 8 Channel POTS Units. FRE-765 List 4A January 6, 2003...
-
Page 24: Cabling Verification
Verify the following connections: Perform the following verifications before inserting any cards in the COT shelf. Visually ensure that the ground wire is tightly secured to the grounding lug inside the FRE-765 and at the ground termination point. Visually verify that the HDSL lines are terminated properly and with the correct orientation. If the HDSL lines are not connected properly, the COT will not communicate with the FRE-765. -
Page 25: Product Support
ADC’s Return Material Authorization (RMA) Department. Call or write ADC’s RMA Department to ask for an RMA number and any additional instructions. Use the telephone number, fax number or email address listed below: •... - Page 26 If there is another reason for returning the equipment, please let us know so we can determine how best to help you. Pack the equipment in a shipping carton. Write ADC’s address and the RMA Number you received from the RMA Department clearly on the outside of the carton and return to: ADC DSL Systems, Inc.
-
Page 27: Fcc Classb Compliance
The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by ADC Technologies, Inc. voids the user's warranty. All wiring external to the product(s) should follow the provisions of the current edition of the National Electrical Code. -
Page 28: Acronyms
