内部公开▲ ZTE CORPORATION ZTE MY39 CDMA 1X-EVDO Wireless Data Card User Manual Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
Page 2
ZTE Corporation reserves the right to make modifications on print errors or update specifications in this manual without notice. Edition: 1 edition, July, 2005 10 9 8 7 6 5 4 3 2 1 Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
Security Settings..................17 3.6.2 Networks..................... 17 3.6.3 Ring tone..................... 18 3.6.4 Default set ....................18 Help ......................... 18 FAQ & Answers ......................19 Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
In such areas, the host communications device must be turned off. The Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
SAR values for this device compliance against FCC standard limit is less than 1.6 W/kg. 1.3 Software Drivers License Proprietary Rights Provisions: The software drivers provided with this product are copyrighted by ZTE Corporation. And Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
Weight Less than 54g Data Rate 2.4Mbps Working 3.3V(Using the laptop computer power supply) Voltage Current Loss Sleep:30mA Max:800mA 27dbm Emission Power Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
Green/Lighting: Netcard inserted to card slot and power on. Green/Blink: Connecting to network. 2.3 Software Installation Turn on your laptop, and insert the CD-ROM into your CD drive. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
Page 8
3. You are now ready to select the location on your laptop where the software should be installed, and Click the “Next” button to continue. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
Page 9
Click “Next” button on the main interface to continue. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
Page 10
Otherwise, insert the netcard and click “Yes” button to continue. 7. Select "Continue Anyway" and then click “Yes” to continue. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
8. Installation is now complete. Click the “Finish” button to finish the installation of ZTE MY39 wireless card. 2.4 Hardware Installation 1. Install the antenna to the netcard main board. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
内部公开▲ 2. Insert the ZTE MY39 into your laptop’s PC Card Slot with the label facing up. Adjust the antenna to horizontal level when the netcard is not in use. Rotate the antenna to 90° angle to ensure it can get the best intensity of the receiving signal.
5. Push the laptop latch release, and then pull the netcard out of the slot. Note: Once the netcard is inserted, do not physically remove the ZTE MY39 from the Card slot until you have completed the Unplug process. Removing the card improperly may cause a fatal error to your laptop.
3.1.2 Description of Mini Icons 1. Tray Icons Description The card hasn’t been connected. The wireless card is initializing. The wireless card has been connected. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
2. Disconnecting the Internet: Click “Disconnect” button to disconnect the Internet. After disconnected, a normal standby icon will appear on tray area. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
“Draftbox” to enter relative interface. InBox:View the received SMS. OutBox:View the sent SMS if you select “Auto Save Sent Message” in Settings submenu. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
When there are more than one message arriving at the same time, “You have new messages” will appear. Click Read, the interface will automatically switch to Inbox, and Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
Click Contact to switch to the phone book interface. Each record includes contact name, mobile phone number, family phone number, office phone number, email address. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
3.6 Setting Click Setting to switch to the settings interface. It includes: security, networks, ring tone, default set. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
Click Apply to confirm operation and click Cancel to original setting. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
Click the Help icon, and switch to the help interface. Under the help topic, you can get the wireless card information about functions introduction, installation and usage guide and published date of application software and hardware, etc. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
4. The dial number, username 4. Check the configuration in the “Network settings”. or the password in the user config files is wrong. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
Page 23
No audio card is fixed in computer Check the audio card and adjust or the volume is too small. the volume properly. Retransmission and reproduction in any manner whatsoever without the permission of ZTE is strictly forbidden. All rights reserved.
