Nortel 1100 Series Getting Started

Expansion Module for IP Phone 1100 Series features
The Expansion Module for IP Phone 1100 Series (Expansion Module) supports the
following features:
• 18 self-labeled line/programmable feature keys
• Up to 36 self-labeled line/programmable feature keys are available with Shift key
functionality on an IP Phone
• Upgradeable firmware using a TFTP or UFTP Server
• A desk-mount bracket and structural baseplate connect the Expansion Module to an
IP Phone, or to another Expansion Module.
• IP Phone and Expansion Module combination can be wall-mounted using the wall
mount template provided.
Note: Shift function and UFTP server support are Nortel Communication Server
dependent. Contact your site administrator to determine if supported at your location.
Figure 1: IP Phone 1140E with Expansion Module for the IP Phone 1100 Series
Regulatory information
Nortel Expansion Module for IP Phone 1100 Series Emissions Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
reorient or relocate the receiving antenna, increase the separation between the equipment
and receiver, connect the equipment into an outlet on a circuit different from that to which
the receiver is connected, or consult the dealer or an experienced radio or TV technician for
help.
The user should not make changes or modifications not expressly approved by Nortel
Networks. Any such changes could void the user's authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique
de la classe B est conforme à la norme NMB-003 du Canada.
This device complies with the essential requirements and other relevant provisions of EMC
and LVD directives. A copy of the Declaration may be obtained from Nortel Networks GmbH
address: Ingolstaedter Strasse 14-18, 80807 Munich Germany.
Date: December 2006
Document Release: Standard 01.01
Document Number: NN43130-100
Copyright © 2006 Nortel Networks. All Rights Reserved.
* Nortel, Nortel (Logo), the Globemark, SL-1, Meridian 1, and Succession are trademarks of Nortel
Networks.
