P-30FACC 30 WATT RMS
P-30FACD 30 WATT RMS
P-60FACC 60 WATT RMS
P-60FACD 60 WATT RMS
RISK OF ELECTRIC
SHOCK, DO NOT OPEN!
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK, DO NOT
OPEN COVER. NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
PRECAUTIONS
1.Unpacking
After removing the amplifier from the carton, inspect for any exterior damage to
the unit. If damage is noted, notify the carrier at once so that a claim can be
justified. Save all packing material. This is important when the claim is
processed.
2.Ventilation
To offset heat generated by the unit, it is necessary to provide ample ventilation
around the unit. Avoid blocking or impeding the ventilation holes in the unit. To
prevent unnecessary problems, install the unit in a place free from any
vibrations, direct sunlight, humidity or dust circulation.
3.Avoid spilling liquids or allowing materials to enter the cabinet
If the unit gets wet or any foreign material enters the cabinet, immediately
disconnect the A.C. line cord and consult your dealer or qualified technician.
INSTRUCTION
MANUAL
WARNING: TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT
EXPOSE UNITS NOT
SPECIFICALLY DESIGNED FOR
OUTDOOR USE TO RAIN OR
MOISTURE.
WARNING: REMOVAL OF THE
COVER SHOULD ONLY BE PER-
FORMED BY QUALIFIED SERVICE
PERSONNEL - NOT USER SER-
VICEABLE. THE UNIT SHOULD
ALWAYS BE UNPLUGGED BEFORE
REMOVING THE COVER, AND
REMAIN UNPLUGGED WHILE THE
COVER IS REMOVED.
200 NEW HIGHWAY, AMITYVILLE, NY11701
PHONE : 1-800-645-5516, 631-957-8700 IN METRO NY
http://www.specotech.com
Advertisement
Table of Contents
Related Manuals for Speco P-30FACC
Summary of Contents for Speco P-30FACC
- Page 1 P-30FACC 30 WATT RMS P-30FACD 30 WATT RMS P-60FACC 60 WATT RMS P-60FACD 60 WATT RMS RISK OF ELECTRIC SHOCK, DO NOT OPEN! CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT OPEN COVER. NO USER SERVICEABLE PARTS INSIDE.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’ s instructions. -
Page 3: Controls And Connections
Controls and Connections FRONT PANEL FACC FACD 1) MIC-1 input jack (1/4’ ’ phone jack) 2) Output level indicator 3) MIC-1 Volume control 4) MIC-2 Volume control 5) MIC-3 Volume control 6) MIC-4 Volume control 7) Line input selector switch 8) Line input volume control 9) Bass control 10)Treble control... - Page 4 REAR PANEL FACC FACD 1) Speaker outputs 2) Ground 3) FM antenna input 4) AM antenna input 5) MOH output terminals* 6) Manual muting terminals 7) TEL/PAGING input terminals (Balanced)** 8) Zone 1 output terminals 9) Zone 2 output terminals 10) Zone 3 output terminals 11) Zone 4 output terminals 12) AC input cable receptacle...
-
Page 5: Front Panel
FRONT PANEL 1) MIC-1 input jack (1/4’ ’ phone jack). Accepts a balanced low impedance microphone with a standard 1/4’ ’ phone plug. 2) Output level indicator. Indicates power output. Do not overload amp. 3) MIC-1 Volume control. Adjusts audio level of MIC-1. 4) MIC-2 Volume control. - Page 6 8 ~ 11) Zone 1~4 output terminals. In addition to the normal 70V and 25V line outputs, there are four groups of 70V or 25V (internally selected, see page 10) line terminals for 4 zones which can be selected using the push buttons on the front panel. 12) AC input cable receptacle .
-
Page 7: Cd Player Operation
CD PLAYER UNIT 1. CD display 2. Repeat button 3. Random button 4. Program button 5. CD power on/off button 6. Previous track button 7. Next track button 8. Play/pause button 9. Stop/eject button CD PLAYER OPERATION 1. Select CD mode with LINE selector switch. 2. -
Page 8: Tuner Operation
INSERTING A CASSETTE The cassette should be inserted edge first with the exposed tape on the right-hand side, push the cassette into the mechanism until the cassette drops into position. REMOVING THE CASSETTE Firmly press the eject button, the cassette will be automatically ejected. FAST WIND The cassette can be fast wound in either direction (forward or reverse) to any position on the tape by pressing and holding one of the fast wind buttons and will be stopped automatically after releasing the... -
Page 9: Fcc Caution
FCC CAUTION: To assure continued compliance, (example-use only shielded interface cables when connecting to computer or peripheral devices). Any changes or modifications not expressly approved by the party responsible for compliance could void the user’ s authority to operate this equipment. -
Page 10: Speaker Impedances
For 25V and 70V CONSTANT VOLTAGE LINE CONNECTIONS (refer to figure 4). IMPORTANT NOTICE: When the 25V and 70V constant line voltages are used, a line HOW TO CONNECT LINE MATCHING TRANSFORMERS IN PARALLEL ALWAYS CONNECT LINE TRANSFORMERS IN PARALLEL NEVER CONNECT LINE TRANSFORMERS IN SERIES 25V Transf. -
Page 11: Cable Requirements
CABLE REQUIREMENTS Output cabling need not be shielded in most cases and should be of sufficient gauge to minimize losses due to the resistance of the wire over long runs (insertion loss). Cable thinner than 18 gauge is not recommended. Long runs require 16 gauge or heavier. In some cases, where the output cable is run in close proximity to unshielded intercom cables, electrical cables, radio transmission antennas or other sources of interference or when the amplifier is being used for paging from a telephone system, the amplifier may require shielded... - Page 12 If Sum Wattage Total is between 217 and 240 Watts If Sum Wattage Total is between 241 and 288 Watts * RMS Amplifier used in conjuction with Speco Technologies’ P-240A Power Booster Amp Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com...
-
Page 13: Technical Specifications
Type Model Supply Main Voltage Output power Music Max RMS Rated Outputs Inputs Frequency response Total harmonic distortion Signal to noise ratio Tone Controls Controls Indicators AC power consumption Priority (VOX) Dimensions ( H x W x D ) Weight Color Mounting options Music Source... - Page 14 ...
