Clarion EN-1286S-A Service Manual

SPECIFICATIONS
Radio section
Tuning system: PLL frequency synthesizer system
Receive range: LW 144kHz to 288kHz
MW 531kHz to 1,629kHz
FM 87.5MHz to 108.0MHz
Quieting sensitivity: LW Less than 30dBuV
MW Less than 25dBuV
FM Less than 15dBuV
S/N: LW More than 45dB
MW More than 45dB
FM More than 50dB
Stereo separatrion: FM More than 20dB
Auto tuning stop sensivity:
LW 32 +6/-6 dBu
MW 30 +6/-6 dBu
FM 27 +6/-6 dBu
External 6CD changer / AUX Input section
Separation: More than 60dB
(IN 1kHz,1.2V,OUT 0dB=VOL MAX)
S/N: More than 80dB
(IN 1kHz, 1.2V,OUT 0dB=VOL MAX)
Distortion: Less than 0.1%(IN 1kHz, 1.2V)
Clarion Co., Ltd.
7-2, Shintoshin, Chuo-ku, Saitama-shi, Saitama 330-0081 Japan
Service Dept.: 7-2, Shintoshin, Chuo-ku, Saitama-shi, Saitama 330-0081 Japan
Tel: +81-48-601-3705 FAX: +81-48-601-3804
(at 20dB S/N)
(at 20dB S/N)
(at 30dB S/N)
(74dBuV,0dB=VOL MAX)
(74dBuV,0dB=VOL MAX)
(65dBuV,0dB=VOL MAX)
(65dBuV,1kHz,
MOD 75kHz-Dev)
More than 10dB
(65dBuV,7kHz,
MOD 75kHz-Dev)
- 1 -
Service Manual
RENAULT Genuine
RDS-TMC LW/MW/FM Tuner
Audio Unit
EN-1286S-A
Model
(Genuine number 28013 JY00A)
General
Load impedance:
Maximum output:
B/U consumption:
Power supply voltage: 13.2V DC(10.5V to 16V)
Ground:
Dimensions(mm):
Weight:
NOTES
* The tuner of this unit is DSP-TUNER type. When the
tuner pack(BL101) is exchanged, it is necessary to ad-
just for S-meter etc. with special JIG.
* Individual data of each unit is recorded in EEPROM
IC(IC401). When EEPROM IC is replaced, it is neces-
sary to write the data.
* DSP IC(IC201) is fixed with solder. Special JIG is nec-
essary for removing it.
* We cannot supply PWB with component parts in prin-
ciple. When a circuit on PWB has failure, please repair it
by component parts base. Parts which are not mentioned
in service manual are not supplied.
* Specifications and design are subject to change without
notice for further improvement.
COMPONENT
EN-1286S-A
1. Main unit
Published by Service Dept.
298-6517-00 Nov.2007
Printed in Japan
2k ohm Pre out/ 4ch
3.9V+/-2dB
Less than 0.25A
Negative
187.4(W) x 58.2(H) x 172.7(D)
Approx. 0.8kg
-----------
EN-1286S-A
1
