SPECIFICATIONS
Tuner section
Tuning system:
PLL Frequeency synthesizer system
Receive range:
AM 530kHz to 1710kHz
FM 87.75MHz to 107.9MHz
Intermediate frequency:
AM 10.7 +0.03/-0.03MHz
FM 10.7 +0.03/-0.03MHz
Quieting sensitivity:
AM Less than 39dBu
FM Less than 15dBu
Separation:
FM More than 15dB
Auto stop sensitivity:
AM 35 +6/-6dBu(DX)
FM 23 +6/-6dBu(DX)
S/N ratio:
AM More than 45dB
FM More than 50dB
CD section
Frequency Response:
17Hz to 20kHz
S/N ratio:
More than 70dB (JIS-A)
Separation:
More than 55dB (20kHz LPF)
Clarion Co., Ltd.
7-2, Shintoshin, Chuo-Ku, Saitama-Shi, Saitama 330-0081, Japan
Service Dept.: 7-2, Shintoshin, Chuo-Ku, Saitama-Shi, Saitama 330-0081, Japan
Tel: +81-48-541-3747 FAX: +81-48-541-3804
(10kHz steps)
(at 20dB S/N)
(at 30dB S/N)
55 +8/-8dBu(LO)
(PF-2945A-A)
41 +6/-6dBu(DX)
61 +8/-8dBu(LO)
(PF-2982B-A)
(600kHz, 1000kHz, 1400kHz)
(87.9MHz, 98.1MHz, 107.9MHz)
Service Manual
SUBARU Automobile Genuine AM/
FM Radio CD/MP3/WMA Player
PF-2945A-A
(Genuine No. 86201FG600)
Model
(ID No. CZ601U1)
PF-2982B-A
(Genuine No. 86201SC600)
(ID No. CP603U1)
MP3/WMA operations:
AUX section
Distortion:
S/N ratio:
Separation:
General section
Load resistance:
Supply voltage:
Max. power output:
Dimensions(mm):
Weight:
COMPONENT
PF-2945A-A / PF-2982B-A
1. Main unit
-1-
Published by Service Dept.
298-6487-00 Sep. 2007 X
Printed in P.R.C.
MP3 Sampling rate 11.025kHz-48kHz,
Bit rate 8kbps-320kbps / VBR
WMA Bit rate 48kbps-192kbps
Logical format (File system);
ISO9660 level 1, 2 or JOLIET or Romeo
Less than 1.0% (20kHz LPF)
More than 70dB (JIS-A)
More than 55dB (20kHz LPF)
4 ohm
DC 13.2V
Negative ground
More than 16Wx4
205(W)x100(H)x157(D)
appro.1.75kg
1
-----------
PF-2945A-A/PF-2982B-A
