iQ Controller
Installation and Operation Manual
204143
FOR SWING AND FOLD DOORS
Stanley Part Number 204143
REV 5 10/2019
All manuals can be found at
www.stanleymobileapps.com
Copyright 2019 Stanley Access Technologies, LLC.
Prohibition on Copying: Any unauthorized reproduction, disclosure or distribution of copies by any
person of any portion of this work may be a violation of copyright law of the United States of America
and other countries, could result in the awarding of statutory damages of up to $250,000 (17 USC 504)
for infringement, and may result in further civil and criminal penalties.
All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Stanley 204143

Summary of Contents for Stanley 204143

  • Page 1 All manuals can be found at www.stanleymobileapps.com Copyright 2019 Stanley Access Technologies, LLC. Prohibition on Copying: Any unauthorized reproduction, disclosure or distribution of copies by any person of any portion of this work may be a violation of copyright law of the United States of America and other countries, could result in the awarding of statutory damages of up to $250,000 (17 USC 504) for infringement, and may result in further civil and criminal penalties.

  • Page 2: Table Of Contents

    National Standard for Power Assist and Low Energy Power Operated Doors,” or most current ANSI/BHMA standards specifications. All ANSI/BHMA and UL Requirements in Attachment 8 must be met before the door is put into operation. Document 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 3: Features And Functions

    Manual Mode Sensor Override: When set to ON the door sensors on the approach side will only be activated when a push plate, Magic Touch, or other Knowing Act activation signal is used. 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 4 Overspeed Resistance: Sets the sensitivity to external factors that allow the door to be used manually. Increasing this parameter will desensitize door motion to factors such as wind, stack pressure, and manual use. Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...
  • Page 5 When set to 99 the lock/strike will stay unlocked until the door returns to the closed position (99 is the only value that is based on door position and not time). 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...

  • Page 6: Wiring Instructions

    • Refer to Attachment 1, and CONNECT breakout status wiring. • REMOVE quick-connect terminal (brown wire) from the normally open terminal of the auxiliary switch (formerly open check switch), and INSTALL onto normally closed terminal. Continued Next Page Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...
  • Page 7 PUSH door in the breakout direction, and HOLD door at approximately the negative 3° position. f. Using a multimeter, CHECK continuity between TB3 terminals 9 and 10, and ENSURE there is an open circuit. g. RELEASE door. h. PLUG TB3 into control box. 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...

  • Page 8: Connecting Breakout Status Signal Wiring (Magic-Force Operators)

    ROTATE BREAKOUT CAMS COUNTER-CLOCKWISE UNTIL RAISED PORTION OF BREAKOUT STATUS CAM JUST CONTACTS SWITCH ROLLER. ROTATE CLOSE CHECK CAM CLOCKWISE UNTIL RAISED PORTION OF CAM ACTUATES SWITCH, THEN ROTATE CAM 10 DEGREES COUNTER-CLOCKWISE. ROTATE AUXILIARY CAM AS DESIRED. Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 9: Wiring The Operator Switch Module (Magic-Force Operators)

    NORMALLY OPEN CONTACT SWITCH MODULE MCB006 b. CONNECT wiring to auxiliary position switch terminal block as shown. c. SLIDE switch module into operator housing until switch module release lever snaps into place. 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...

  • Page 10: Wiring The Operator For Required Handing (Magic-Force Operators)

    Specific wiring instructions from the manufacturer must also be consulted. Refer to Attachments 2, 3, 4 and applicable manufacturer’s instructions, and CONNECT door activation or safety device. Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 11: Wiring Swing Guard T

    When the door is open and the beam is obstructed, the door will remain open. Refer to Attachment 2, 3 , or 4 as applicable for wiring connections. Wiring Other Sensors Refer to Attachment 2, 3, 4 or 5 as applicable for wiring connections. 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...

  • Page 12: Tune-In Instructions

    ” followed by four pairs of digits, followed by “ ”. For example, if the door count was 12345678 cycles the door will display “ ” “ ” “ ” “ ” “ ” “ .” Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 13: Index Tables

    14 = Monitored DM Stall & OHP both single and pair. STL & SAF 15 = Monitored DM Stall & OHP Dual Egress. STL & SAF Lock Keypad. Final Tune in. 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 14 Control Box re-learns the encoder count. Command: Lock. Entering will lock all VALUE imports except this INDEX. This prevents inadvertent changes to input values. VALUES may be unlocked by entering in this INDEX. Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...
  • Page 15 Open Check Length Magic Touch Sensitivity (01= max. Sensitivity) Magic Touch Hold Open Time (25 sec. max. = 99%) **Max value listed in table not accessible from keypad. Table 4 Continued Next Page 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 16 (99 = unlocked until full closed) Fire Alarm Mode *Please refer to Features and Functions for more information on parameters. **Max value listed in table not accessible from keypad. ***Default value is different for Magic-Swing. Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 17: Status Codes

    FIS Learn Complete Encoder Error Cable failure. Encoder Mismatch Wrong Encoder/Magnet. Wrong Encoder/Magnet or cable failure. Encoder Failure Ensure motor is attempting to move. Learn Error Troubleshooting Mode Continued next page. 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...

  • Page 18: Door States

    Otherwise, the iQ alternates between showing the current status code and the door state. • displayed when controlling more than one door. Any state that follows is referencing door #1. • Any state that follows is referencing door #2 Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 19: Final Tune-In Adjustments

    Verify that the correct Safety Logic has been selected for Sensor Monitoring and that JP301 is installed. p. Please refer to Attachment 11 for iQ Controller Fine Tuning for adjustment recommendations. 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...

  • Page 20: Attachments

    Control Box ATTACHMENTS Attachment 1 Breakout Status Wiring for Magic-Swing Operators (Sheet 1 of 1) Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 21: Attachment 2: Magic-Force Wiring Diagram

    Control Box Attachment 2 Magic-Force Wiring Diagram—iQ (Sheet 1 of 1) Class 2 Supply 12 Volts 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...

  • Page 22: Attachment 3: Magic-Swing Wiring Diagram

    Control Box Attachment 3 Magic-Swing Wiring Diagram—iQ (Sheet 1 of 1) Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 23: Attachment 4: Monitored Sensor Wiring Diagrams

    Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 1 of 14) SU100 OHP1 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 24 2. If the optional SU100 for two-way traffic is needed, this additional SU100 requires adding a 24VDC external power supply into TB4-1 and TB4-2 and removing the 15V power jumpers from TB7 and TB4 (see Attachment 5 sheet 3). Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...
  • Page 25 Monitored Sensors Wiring Diagrams (Sheet 3 of 14) *SU100 OHP1 OHP2 *SU100 *NOTE : If DMA1 and DMA2 meet the requirements of ANSI A156.10 section 8.2.2.3, the SU100 sensors are not required. 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 26 Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 4 of 14) SU100 SU100 OHP1 OHP1 Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...
  • Page 27 Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 5 of 14) 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 28 Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 6 of 14) Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...
  • Page 29 Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 7 of 14) SU100 SU100 OHP1 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 30 Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 8 of 14) SU100 Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...
  • Page 31 Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 9 of 14) DOOR MOUNTED STALL & ACT SWING DOOR PAIR SAFETY LOGIC - 10 SU100 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 32 Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 10 of 14) SU100 OHP1 SU100 OHP2 Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...
  • Page 33 Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 11 of 14) SU100 SU100 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 34 Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 12 of 14) SU100 OHP1 Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...
  • Page 35 Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 13 of 14) SU100 OHP1 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 36 Control Box Attachment 4 Monitored Sensors Wiring Diagrams (Sheet 14 of 14) SU100 OHP2 OHP1 SU100 Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 37: Attachment 5: Non-Monitored Sensors Wiring Diagram

    Control Box Attachment 5 Non-Monitored Sensors Wiring Diagrams (Sheet 1 of 3) NOTE : This wiring is for existing installations where monitoring is NOT required. SU100 OHP1 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 38 2. If the optional SU100 for two-way traffic is needed, this additional SU100 requires adding a 24VDC external power supply into TB4-1 and TB4-2 and removing the 15V power jumpers from TB7 and TB4 (see Attachment 5 sheet 3). Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...
  • Page 39 : This wiring is for existing installations where monitoring is NOT required. *SU100 OHP2 OHP1 *SU100 *NOTE If DMA1 and DMA2 meet the requirements of ANSI A156.10 section 8.2.2.3, the SU100 sensors are not required. 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...

  • Page 40: Attachment 6: Iq Terminal Block Connections

    Control Box Attachment 6 iQ Terminal Block Connections—TB1 through TB7 (Sheet 1 of 1) Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 41: Attachment 7: Iq Controls And Indicators

    Control Box Attachment 7 iQ Controls and Indicators (Sheet 1 of 2) ENCODER 2 JP301 ENCODER 1 SEE DETAIL A ENCODER 2 JP301 ENTER ENCODER 1 DOWN DETAIL A 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 42 Hold Beam, Electric Strike, Swing Guard T operate signal. Terminal Block Connector TB4 Connection point for operate sensor, safety sensor and push plate. Terminal Block Connector TB3 Connection point for safety sensor, stall sensor, and breakout switch. Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 43: Attachment 8: Ansi/Bhma And Ul Compliance Requirements

    All power operated door systems must be installed in compliance with the current edition of UL 325, “Stan- dard for Safety for Door, Drapery, Gate, Louver, and Window Operators and Systems”. 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
  • Page 44 Doors activated by a manual switch (Knowing Act switch in ANSI/BHMA terms) must have the switch installed in a location from which operation of the door can be observed by the person operating the switch. Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 45: Attachment 9: Hand Held Device Troubleshooting Aid

    Power Close Cancel and Power Assist Dark = On TB6-3 at Closed Mode / DM2 Stall TB6-5 DM1 and OHP1 Test Dark = Normal TB6-7 DM2 and OHP2 Test Dark = Normal 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...

  • Page 46: Attachment 10: Recommended Values For Door Configurations

    Open Startup Torque Open Startup Length Open Speed Open Torque Open Acceleration Open Check Length Open Check Speed Open Check Torque Open Braking Open Stop Open Check Recycle Speed Overspeed Resistance Document # 204143 REV 5 • www.stanleyaccess.com • 1.800.7.ACCESS...

  • Page 47: Attachment 11: Iq Controller Fine Tuning

    2. To verify new setting, door must be cycled open and return to full closed. NOTES is also used to set the door open force. Open Torque must comply with UL and ANSI/BHMA A156.19 or 156.10 requirements. Open / Close Speeds Forces 1.800.7.ACCESS • www.stanleyaccess.com • Document # 204143 REV 5...
