- Page 1 Guided type fall arrester including rigid anchor line - (EU) 2016/425 H-50 System DIN EN 353 -1: 2018 Hailo SPL-50-PRO Fall Arrester and Integrated BFD-50-136 Shock Absorber Information booklet about • Using • Care • Inspection...
-
Page 2: General Information, Explanation Of Symbols
This information booklet describes how to use, The SPL-50-PRO fall arrester may only be used maintain and test the SPL-50-PRO fall arrester. on the H-50 fall arrest system. For your safety, please read this information Use, maintenance and inspection must be car- brochure carefully before use. -
Page 3: Table Of Contents
Contents: WARNING Notes on potentially dangerous situations. 1. General information, If these cannot be avoided, there is a risk of severe explanation of symbols ..2 injuries or death. 2. System data ....4 CAUTION 3. -
Page 4: System Data
2. System data Information on SPL-50-PRO fall arrester SPL-50-PRO fall arrester: ..........BFD-50-136 shock absorber . -
Page 5: Intended Use
3. Intended use 4. Safety instructions • The H-50 fall arrest system is designed as a fall • Only persons who have been instructed in the use of vertical ladder and fall protection systems safety when using rung ladders and pole clim- may use the H-50 fall protection system and the bers, both above ground and below ground. - Page 6 WARNING a result of a fall, it must be immediately with- drawn from use and returned to Hailo for inspec- Risk of falling! tion and repair. The spring hook on the shock absorber may only...
- Page 7 WARNING Risk of falling! The user should basically avoid standing in a position on the fall arrest rail where they are directly above the fall arrester [F]. Warning “Risk of falling”!
-
Page 8: Technical Data
• Max. 5 Personen dürfen das Steigschutzsystem gleichzeitig benutzen. DIN EN 353-1:2018 HAILO H-50 System The H-50 system may only be used with the SPL-50-PRO fall arrester 0158 in conjunction with EN 361 compliant safety belts. ATTENTION! • The safety harness provides protection from a height of 3 m above the access level! (Safety distance = 3 m) •... -
Page 9: Use Of The Spl-50-Pro Fall Arrester
6. Use of the SPL-50-PRO fall arrester Overview SPL-50-PRO fall arrester • The SPL-50-PRO fall arrester [A] is attached to the H-50 fall arrest rail before climbing/de- scending. The SPL-50-PRO fall arrester when attached to the rails is fitted with a BFD-50- 136 shock absorber [B] and is connected to the user’s safety harness. - Page 10 6. Use of the SPL-50-PRO fall arrester Attaching and removing the SPL-50-PRO fall arrester 1. Unlocking the fall arrester Hold the fall arrester in your left hand as shown, press in both release buttons [A] and simultane- ously turn the brake lever [B] upwards. 2.
- Page 11 Note on entry and exit: End-stop There is an additional end-stop [A] at the entry and exit points at the bottom and top of the ladder. This end stop prevents the fall arrester from sliding out of the fall arrest rail unintentionally. WARNING Risk of falling! Before the end stop is brought into the transit...
- Page 12 Use the feeler gauge to check the thick- ness [F] of the wear points on the surface of the brake. • If the measured value is ≤ 0.05 mm, the brake lever must be replaced. Only Hailo is allowed to replace the brake lever.
- Page 13 Additional anchor points WARNING Risk of falling! Both on entering and leaving the fall arrest system, the user must be secured to an approved fastening point appropriate to local conditions to prevent falling. The karabiner [A] is either hooked onto an ap- proved anchor point [B] - according to EN 795 - or another structure! The system may only be entered or left from a...
-
Page 14: Markings
BFD-50-136 Shock Absorber [A] Type plate on SPL-50-PRO fall arrester [B] Security advice [C] Test badge [D] Arrow marking THIS WAY UP [E] Type plate on BFD-50-136 shock absorber [F] Shock absorber address sticker [G] Hailo Professional Logo [H] Packaging label... -
Page 15: Care Instruction
8. Care instruction 9. Inspection instruction Cleaning: • DIN EN 353-1:2018-compliant fall arresters must be inspected and documented for good • Remove soiling from the fall arrester using only working order and functionality at least once a water and an acid-free detergent. year by trained/authorised personnel. -
Page 16: Inspection Plan
19. Original markings Are the serial number, type details, etc., easily legible? 20. SPL-50-PRO fall arrester function test Use on H-50 fall arrest system 21. Period of use of BFD-50-136 Has the period of use expired? 22. Test badge for SPL-50-PRO fall arrester Has a test badge been awarded –... - Page 17 Inspection 1 Inspection 2 Inspection 3 Inspection 4 Inspection 5 Inspection 6 Inspection 7 Date Date Date Date Date Date Date (Month / Year) (Month / Year) (Month / Year) (Month / Year) (Month / Year) (Month / Year) (Month / Year)
-
Page 18: Documentation
11. Documentation Inspection of the SPL-50-PRO Fall Arrester Product description Manufacter / Supplier Date of purchase SPL-50-PRO fall arrester HAILO-Werk Daimlerstraße 2, D-35708 Haiger Identification mark Date of the first use +49 (0) 2773 82-0 Serial number +49 (0) 2773 82-1561... - Page 19 Inspection of the BFD-50-136 Shock Absorber Product description Manufacter / Supplier Date of purchase BFD-50-136 shock absorber HAILO-Werk Daimlerstraße 2, D-35708 Haiger Identification mark Date of the first use +49 (0) 2773 82-0 Serial number +49 (0) 2773 82-1561 Date of manufacture / Expiry date Further information info@hailo-professional.de...
- Page 20 1215919 Revision 2021- 02 Technical changes reserved • •...
