17" Auto scan Colour Monitor
Service
Service
Service
DDC/Power saving/TCO
User-friendliness Control
Description
Important Safety Notice ------------------------------- 2
Technical Data ------------------------------------------ 3
Installation ----------------------------------------------- 4
OSD Menu tree structure ---------------------------- 5
OSD Adjustments ----------------------------------- 6-14
Warning and Notes ------------------------------------ 15
Mechanical Instructions ------------------------------ 16
Wiring Diagram----------------------------------------- 17
DDC Instructions --------------------------------- 18~21
DDC Data--------------- ---------------------------------22
Electrical Adjustments -------------------------- 23~25
Safety test requirements (Hipot & Ground)--------26
Block Diagram & Control Panel C.B.A.-------------27
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFORMER FOR THIS UNIT WHEN SERVICING.
TABLE OF CONTENTS
Page
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
SAFETY NOTICE
©
Description
Video Panel(A) Schematic Diagram & Waveforms---28
Video Panel C.B.A------------------------------------------29
Main Panel C.B.A. (B1,B2,B3,C)- -----------------------30
Deflection Panel (B1) Schematic Diagram-------------31
H-Voltage(B2) Schematic & Waveforms(B1,B2,B3)--32
CPU(B3) Schematic Diagram ----------------------------33
Power Supply(C) Schematic Diagram & Waveforms-34
Repair Tips ---------------------------------------------------35
Exploded View ---------------------------------------------- 36
Recommanded parts List --------------------------------- 37
Spare parts list------------------------------------------ 38~44
General product specification------------------------45~67
Repair flow chart----------------------------------------68~75
LightFrame for Windows
-----------------------------------76~77
Chassis :CM 2500
107P2 CM25 GSIII
107P20/00
Horizontal frequencies
30 - 92 kHz
Page
3138 106 10113
GB
