I N S T A L L A T I O N g U I D E
1. Make sure that all the packing materials are removed
from the inside of the door.
2. Check the oven for any damage, such as misaligned
or bent door, damaged door seals and sealing sur-
face, broken or loose door hinges and latches and
dents inside the cavity or on the door. If there is any
damage, do not operate the oven but contact quali-
fied service personnel.
3. This microwave oven must be placed on a flat, stable
surface to hold its weight and the heaviest food likely
to be cooked in the oven.
4. Do not place the oven where heat, moisture, or
high humidity are generated, or near combustible
materials.
g R O U N D I N g I N S T R U C T I O N S
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces risk of electric shock
by providing an escape wire for the electric current.
WARNING
– Improper use of the grounding plug can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not completely understood, or if doubt
exists as to whether the appliance is properly grounded, and either:
1) If it is necessary to use an extension cord, use only a 3-wire extension cord
that has a 3-blade grounding plug and a 3-slot receptacle that will accept the
plug on the appliance. The marked rating of the extension cord shall be equal to
or greater than the electrical rating of the appliance, or 2) Do not use an exten-
sion cord. If the power supply cord is too short, have a qualified electrician or
serviceman install an outlet near the appliance.
Electrical Requirements
The electrical requirements are a 120 volt 60 Hz, AC only, 20 amp. It is recom-
mended that a separate circuit serving only the oven be provided. The oven is
equipped with a 3-prong grounding plug. It must be plugged into a wall receptacle
that is properly installed and grounded.
Power Supply Cord
1. A short power supply cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care
is exercised in their use.
3. If long cord or extension cord is used：
a) The marked electrical rating of the cord set or extension cord should be
at least as great as the electrical rating of the appliance.
b) The extension cord must be a grounding-type 3-wire cord, and The longer
cord should be arranged so that it will not drape over the counter top or table top where it can be pulled on
by children or tripped over unintentionally.
Notes:
If you have any questions about the grounding or electrical instructions, consult a qualified electrician or service
person. Neither Sharp nor the dealer can accept any liability for damage to the oven or personal injury resulting
from failure to observe the electrical connection procedures.
Radio or tV Interference
Should there be any interference caused by the microwave oven to your radio or TV, check that the microwave
oven is on a different circuit, relocated the radio or TV as far away from the oven as feasible or check position and
signal of receiving antenna.
5. For correct operation, the oven must have sufficient
airflow. Allow 20 cm of space above the oven, 10 cm
at back and 5 cm at both sides. Do not cover or block
any openings on the appliance. Do not remove feet
on which oven stands.
6. Do not operate the oven without glass tray, roller
support, and shaft in their proper positions.
7. Make sure that the power supply cord is undamaged
and does not run under the oven or over any hot or
sharp surface.
8. The socket must be readily accessible so that it can
be easily unplugged in an emergency.
5
