Related Manuals for Shark LIGHT & EASY S3251
Summary of Contents for Shark LIGHT & EASY S3251
- Page 1 WWW.SHARKCLEAN.COM LIGHT & EASY™ STEAM MOP S3251 OWNER’S GUIDE S3251_11_ENG_IB_101117.indd 1 10-11-17 1:58 PM...
-
Page 2: Important Safety Instructions
Do not attempt to defeat this safety feature. TOLL FREE: 1-800-798-7398 S3251_11_ENG_IB_101117.indd 2 1. Use the system only for its SHARK ® intended use. 2. DO NOT use outdoors. 3. DO NOT leave the appliance unattended when plugged in. - Page 3 11. DO NOT unplug by pulling on power cord. To unplug, grasp the plug not the power cord. Do not use extension cords or outlets with inadequate current carrying capacity. 12. DO NOT put any objects into openings. Do not use with any opening blocked.
-
Page 4: Assemble
Quick Start fig. 1 ASSEMBLE Fit together the extension tubes as shown in the illustration. (fig. 1) Place the micro-fiber cleaning pad underneath the mop head, with quick fastener strips facing up. Simply press the mop to the pad to attach it. (fig. 2) TOLL FREE: 1-800-798-7398 S3251_11_ENG_IB_101117.indd 4 fig. -
Page 5: Steam Cleaning
QUICK TIP: For easier pushing and pulling, extend the handle length. STEAM CLEANING For your comfort, you can adjust the height of the mop. Just lift the latch on the tube 90 degrees to the open position. Holding the handle, extend the tube to the desired height and then close the latch to the locked position. -
Page 6: Technical Specifications
This manual covers model number: S3251 11 TECHNICAL SPECIFICATIONS Voltage: 120V., 60Hz. Power: 1550 Watts Water Capacity: 250 ml (8 oz.) TOLL FREE: 1-800-798-7398 S3251_11_ENG_IB_101117.indd 6 10-11-17 1:58 PM... - Page 7 Contents Thank you for GETTING STARTED ... 2 purchasing USING YOUR STEAM MOP ...6 the Shark STORAGE AND CARE OF YOUR STEAM MOP ... 8 ® Light & Easy TROUBLESHOOTING ... 10 ™ Steam Mop. WARRANTY AND REGISTRATION ...13 S3251_11_ENG_IB_101117.indd 1 www.sharkclean.com...
-
Page 8: Getting Started
When assembling your steam mop there may be a little water in or around the water tank. This is because we test all our steam mops 100% before you buy them, so you get a quality Shark Light & Easy Steam Mop. ® ™... - Page 9 Insert the assembled handle piece into the steam mop base. Push the tube base together until you hear a click. (fig. 2) For your comfort, you can adjust the height of the mop. Just lift the latch on the tube 90 degrees to the open position.
- Page 10 Getting Started fig. 1 ATTACHING THE MICRO-FIBER PAD Place the micro-fiber cleaning pad on the floor with the quick fastener strips facing up. Place the Light & Easy™ Steam Mop on the top of the pad to attach. (fig. 1) IMPORTANT: Only add water to the tank.
- Page 11 To extend the life of your product we recommend that you use distilled water or Shark Water Filtration Bottle. Visit www. sharkclean.com to order. FILLING THE WATER TANK IMPORTANT: Unplug the Light &...
- Page 12 Light & Easy™ Steam Mop. Visit www.sharkclean.com for other great quick cleaning products to complement your Light & Easy™ Steam Mop, such as the Shark Navigator. TOLL FREE: 1-800-798-7398 S3251_11_ENG_IB_101117.indd 6 When you use your steam mop for the...
- Page 13 Wait 30 seconds for the boiler to heat the water. Pump the handle a few times to prime the pump, activate steam and moisten the micro-fiber pad. (fig. 4) S3251_11_ENG_IB_101117.indd 7 If your Light & Easy Steam ™ Mop stops steaming, it could be out of water.
- Page 14 Replace the water cap. TOLL FREE: 1-800-798-7398 S3251_11_ENG_IB_101117.indd 8 To store the cooled Shark Easy™ Steam Mop, hang on a large hook. (fig. 3) NOTE: If you want to store the Light & Easy™ Steam Mop standing...
- Page 15 Care of Your Light & Easy™ Steam Mop fig. 5 CARE OF YOUR MICRO-FIBER CLEANING PAD Wash pads in warm water. Wash separately from other laundry. Only use liquid detergent (no powder detergent). Do not use fabric softeners. Line dry or dry on a low dryer setting.
-
Page 16: Trouble Shooting
Trouble Shooting PROBLEM The Light & Easy™ Steam Mop will not turn-on. Light & Easy™ Steam Mop will not make steam. Light & Easy™ Steam Mop leaves water on the floor. Light & Easy™ Steam Mop left white spot on the floor. - Page 17 English Notes www.sharkclean.com S3251_11_ENG_IB_101117.indd 11 10-11-17 1:58 PM...
- Page 18 Notes TOLL FREE: 1-800-798-7398 S3251_11_ENG_IB_101117.indd 12 10-11-17 1:58 PM...
- Page 19 English ONE (1) YEAR LIMITED WARRANTY EURO-PRO Operating LLC warrants this product to be free from defects in material and workmanship for a period of one (1) year from the date of the original purchase, when utilized for normal household use, subject to the following conditions, exclusions and exceptions. If your appliance fails to operate properly while in use under normal household conditions within the warranty period, return the complete appliance and accessories, freight prepaid.
- Page 20 U.S.: EURO-PRO Operating LLC Newton, MA 02459 Canada: EURO-PRO Operating LLC 4400 Bois Franc Ville St. Laurent, Québec H4S 1A7 1-800-798-7398 www.sharkclean.com COPYRIGHT© EURO-PRO OPERATING LLC 2010 PRINTED IN CHINA S3251.E.101117 Illustrations may differ from actual product. S3251_11_ENG_IB_101117.indd 14 10-11-17 1:58 PM...
