Siemens RUGGEDCOM RX1501 Installation Manual page 22

1.
RUGGEDCOM RX1501
Installation Manual, 04/2022, C79000-G8976-1054-22
Connect the power supply terminal block to the device.
European-style (Euroblock) Terminal Block
1
Positive/Live (+/L) Terminal
2
Ground Terminal
3
Negative/Neutral (-/N) Terminal
4
Figure 2.5 AC Terminal Block Wiring – European-style (Euroblock) Terminal Block for HIP
Power Supplies
4
2
Not Connected
1
Removable Screw Terminal Block
2
Non-removable Screw Terminal Block
3
Positive/Live (+/L) Terminal
4
Ground Terminal
5
1
2 3 4
1 5 1 6
Installing the Device
2.5.1 Connecting High AC/DC Power
4
3
5 6
13
