- Page 1 WLA-1 Series Hybrid Curvature Array USER MANUAL WLA-112 WLA-115 WLA-121SUB www.wharfedalepro.com...
-
Page 2: Table Of Contents
About the WLA-1 Series ……………………………………………………………………………..2 WLA-1 sound system example ……………………………………………………………………….. 3 - 5 Dimensional Drawings ..……………………………………………………………………………….. 6 - 7 WLA-1 Series Response graphs ………..……..……..……..……..……………………………..8 - 10 Specifications …………………………………………………………………………………………... 11 WLA-121SUB ARM ……………………………………………………………………………………. 12 Configurations ………………………………………………………………………………………….. 13 - 15... -
Page 3: Important Warnings & Safety Instructions
UNPACKING All Wharfedale Pro products are fully checked before leaving our factory. After unpacking please inspect the cabinets for any physical damage Please retain the shipping carton if possible and internal packing material incase the unit ever needs to be returned. Please check as soon as possible that the unit is functioning. -
Page 4: About The Wla-1 Series
IAG’s International R&D team to be highly versatile - making it perfect for touring and fixed installations. The drivers inside are very special. Designed and Engineered by Wharfedale Pro UK and manufactured in Europe by Beyma, the full-range WLA-112 and WLA-115 elements use a coaxial design in combination with the exclusive incredible EVO-Fold high frequency waveguide. -
Page 5: Wla-1 Sound System Example
WLA-1 sound system example 2 x WLA-121SUB and 4 x WLA-112 Fullrange Front of House Stereo DP-2200F(N) x 2 2 x WLA-121SUB and 4 x WLA-115 Fullrange Front of House Stereo DP-2200F(N) x 2... - Page 6 WLA-1 sound system example 4 x WLA-112 and 4 x WLA-115 Fullrange Front of House Stereo DP-2200F(N) 6 x WLA-112 or 6 x WLA-115 DP-2200F(N)
- Page 7 WLA-1 sound system example WLA-112 and WLA-121SUB or WLA-115 and WLA-121SUB Optional SP-4 pole DP-2200F(N) ANGLE CONFIGURATIONS WLA-1 introduces a new Hybrid concept giving variable angles of 0, 5, 10 and 15 degrees...
-
Page 8: Dimensional Drawings
Dimensional Drawings WLA-112 465.0 566.0 WLA-115 543.0 566.0... - Page 9 Dimensional Drawings WLA-121SUB 760.0 566.0...
-
Page 10: Wla-1 Series Response Graphs
WLA-1 Series Response graphs WLA-112 Note : Specification and graphs are created with the dedicated DSP presets. - Page 11 WLA-1 Series Response graphs WLA-115 Note : Specification and graphs are created with the dedicated DSP presets.
- Page 12 WLA-1 Series Response graphs WLA-121SUB Note : Specification and graphs are created with the dedicated DSP presets.
-
Page 13: Specifications
Specifications Model Name WLA-112 WLA-115 WLA-121SUB Design Hybrid Curvature Array Hybrid Curvature Array Subwoofer System Type 12" coaxial passive 15" coaxial passive 21" Subwoofer Configuration two-way two-way Single Subwoofer Frequency Response (+/-3 dB) 55 Hz - 20 KHz 42 Hz - 20 KHz 25 Hz - 100 Hz Frequency Range (- 10 dB) 35 Hz - 25 KHz... -
Page 14: Wla-121Sub Arm
WLA-121SUB ARM Supplied with the WLA-121SUB is the WLA-121SUB Arm. This arm allows the first speaker of the array (WLA-112 or WLA-115) to be be angled as 0° or as -5° down. Simply insert the bolt to select the angles in the diagrams below. -
Page 15: Configurations
Configurations 1 - Common Fly Frame WLA-121SUB + 2 x WLA-112 WLA-121SUB + 2 x WLA-115 4 x WLA-112 or 4 x WLA-115 can be flown WLA-1 Common Fly Frame 50.0 573.0... - Page 16 Configurations 2 - WLA-1 LINK 3 x WLA-112 3 x WLA-115 50.0 WLA-1 Link 65.0 880.0...
- Page 17 Configurations 3 - SP-4 pole Using the optional SP-4 pole to connect a WLA-112 or a WLA-115 to the WLA-121SUB -7 degrees angle +7 degrees angle WLA-121SUB + 1 x WLA-112 or 1 x WLA-115 WLA-112 or WLA-115 140.00 SP-4 112.00 15.00 770.00...
- Page 20 Wharfedale Pro products are warranted of manufacturing or material defects for a period of three years from the original date of purchase. In the event of malfunction, contact your authorised Wharfedale Pro dealer or distributor for information. Please be aware that the warranty details may differ from country to country. Contact your dealer or distributor for information (available at www.wharfedalepro.com).
