Instruction ManualManual WARNING To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
Instruction ManualManual IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8.
• DO NOT TOUCH THE PLAYBACK SIDE OF THE DISC. • DO NOT ATTACH PAPER OR TAPE TO DISCS. Note: Polaroid SHALL NOT BE RESPONSIBLE FOR DAMAGE THAT MAY OCCUR TO A DISC FROM BEING OPERATED IN THE UNIT. Cleaning discs •...
Instruction ManualManual INTRODUCTION Safety Precautions ...1 Feature Descriptions ...5 Specifications ...5 Front and Rear Unit Profiles ...6 Remote Control Features ...6 INSTALLATION Connecting the Antenna ...8 Installing the Remote Control Batteries ...8 Connecting A/V Equipment ...9 FUNCTIONS & FEATURES Turn On/Off ...11 Basic Functions ...11 Function Selection Menus Picture Menu ...11...
Instruction ManualManual Feature Descriptions 181 Channel Tuner - total number of channels the TV can receive: 2-69 in Air mode, or 1-125 in Cable mode AV Input (Rear) - standard composite input designed for use with A/V devices, such as a VCR or DVD player AV Output (Rear) - output signals from TV to devices such as VCR's RF IN Jack - standard coaxial antenna jack...
Instruction ManualManual Front and Rear Unit Profiles Front panel AV IN1 terminals TV/VIDEO SELECT VOLUME DOWN/UP Rear panel Remote Control Features 14 15 16 17 1819 DVD TRAY MENU CHANNEL POWER SELECT DOWN/UP INDICATOR ANTENNA IN 22 23 24 9 10 11 DVD/TV SELECT OPEN/CLOSE PLAY/PAUSE...
Page 8
Instruction ManualManual Remote Control Features The keys marked with * have composite functions and the key in boldface type function for DVD only as shown below. Notes: 1. When in operation, please point your remote control directly to the infrared sensor. 2.Do not expose the remote control to impacts, water or disassemble it.
Instruction ManualManual INSTALLATION - Please read the safety instructions in this manual completely before installation. - Install your unit in an area where direct sunlight will not fall upon the screen. - Soft, indirect light is best for television viewing. - Allow enough space (at least 4 in.) between the TV and any walls or enclosures for proper ventilation.
Instruction ManualManual INSTALLATION (continued) Connecting A/V Equipment The following are diagrams showing basic instructions for attaching external equipment, like a VCR or DVD player, to your unit. Please refer to operation manuals of external audio/video equipment that will be connected to your set for additional instructions. PLEASE TURN OFF ALL POWER BEFORE CONNECTING DEVICES TOGETHER.
Page 11
Instruction ManualManual INSTALLATION (continued) Connecting A/V Equipment (continued) Enjoying Digital Stereo Sound (Digital Stereo) Enjoy the dynamic sound of Digital Stereo by connecting an amplifier equipped with a digital audio input and speaker system (right and left front speakers). Set "SPDIF Output" to "SPDIF/PCM"via the setup menu. •...
Instruction ManualManual FUNCTIONS & FEATURES Turn On/Off 1. Turn On Plug in the power cord, and the TV should enter into Standby mode. Pressing STANDBY key will turn on the TV and its power indicator light. 2. Standby While the TV is on, press the STANDBY key will put the TV in Standby or off mode. The power indicator light on the TV set will turn off.
Instruction Manual FUNCTIONS & FEATURES Tuner Menu Note: This menu is only accessible while the TV is in Tuner mode. Channel: This feature allows you to change the channel displaying on screen. Press or the numeric keypad to change the channel. Add/Erase: This feature allows you to add or remove the channel currently on display from the "active channel list"...
Page 14
Instruction ManualManual FUNCTIONS & FEATURES (continued) System Menu (continued) Parental Guide This feature allows parents to block certain programs from being viewed, based on the programs' rating. In order to access this menu, you must first enter a pass code. The factory default is 6688. Enter the pass code while the Parental Guide is highlighted.
Instruction ManualManual FUNCTIONS & FEATURES (continued) Useful Remote Control Features DISPLAY This key allows you to display the current information of the TV screen on the upper right hand corner of the screen. (channel, antenna mode, time, video, etc.) SCAN Press the SCAN key twice, and the TV will begin to scan through all active channels.
Instruction ManualManual DVD FUNCTIONS Playing Back a Disc 1. How to playback a disc 1) Press DVD/TV to enter the DVD mode. 2) Press OPEN/CLOSE to open the disc tray. 3) Place the disc on tray with graphics side up. Be sure the playback side is faced down.
Instruction ManualManual DVD FUNCTIONS(continued) Playing Back a Disc (continued) Note: The DVD Player may not playback sound during scan reverse or forward playback of DVD video discs. The DVD Player will play sound during fast forward or fast reverse playback of audio CDs. The speeds may vary slightly from disc to disc and the 2x, 4x, 8x, and 16x speeds are only approximate speeds.
Instruction ManualManual DVD FUNCTIONS(continued) Locating a Specific Title, Chapter or Track THE DVD VIDEO DISCS ARE NORMALLY DIVIDED INTO TITLES. THE TITLES ARE SUB-DIVIDED INTO CHAPTERS. MOREOVER, AUDIO CD ARE DIVIDED INTO TRACKS. YOU CAN CONVENIENTLY LOCATE ANY SPECIFIC TITLE, CHAPTER, OR TRACK WITH THIS UNIT. Chapter1 Chapter2 Chapter3 Chapter4 Chapter5...
Instruction ManualManual DVD FUNCTIONS(continued) Selecting Subtitles THIS UNIT ALLOWS YOU TO DISPLAY THE SUBTITLES FROM THOSE INCLUDED ON THE DISC, ON TO YOUR TV SCREEN. How to display subtitles You have the option to select a preferred subtitle from those included on the DVD video disc.
Instruction ManualManual DVD FUNCTIONS(continued) Playing Back a JPEG Picture CD 1. Normal When a JPEG Picture CD is inserted, an automated slide show is launched, each picture in the current directory will be displayed consecutively in a slide-show fashion and will be scaled to fit most of the TV screen.
Instruction ManualManual DVD FUNCTIONS(continued) Setting the Parental Lock YOU CAN USE THE PARENTAL LOCK FUNCTION ONLY WITH DVD VIDEO DISCS EQUIPPED WITH THE PARENTAL LOCK FEATURE. Setting the parental lock DVD video discs equipped with the parental lock function are rated according to their content. The contents allowed by a parental lock level and the way a DVD video disc can be controlled may vary from disc to disc.
Instruction ManualManual Customizing the Function Settings THIS UNIT ALLOWS YOU TO CUSTOMIZE THE PERFORMANCE TO YOUR PERSONAL PREFERENCES. Displaying the setup menu screen The SETUP MENU screen asks you to select a setting category from General Setup, Speaker Setup, Audio Setup, and Preferences. The selected category will provide you the setting details on-screen. 1.
Instruction ManualManual TROUBLESHOOTING GUIDE Check the following guide for a possible correction to a problem before contacting customer support.
Page 24
US call 1-866-289- 5168, in Canada call 1-866-301-7922 and in Mexico call 01- 800-400-2443. "Polaroid" is a registered trademark of Polaroid Corporation of Waltham, MA USA and licensed for use on the TTM-2003 to Petters Consumer Brands, LLC.
